Sputnik Engineering SolarMax MaxVisio Instruction Manual page 12

Instruction Manual
This instruction manual is part of the scope of supply and must be read thoroughly
before using the device for the first time. No work other than the tasks described in
this manual may be carried out on the device or any connected components. Sputnik
Engineering AG declines any liability in the event of non-observance of the instal-
lation instructions.
Safety instructions
■ MaxVisio may only be operated with the enclosed power supply unit plugged
into a 230 V socket.
AC
■ MaxVisio may only be installed in dry, clean areas (protection class IP 20).
■ Only SolarMax devices with an RS-485 interface may be connected to the
MaxVisio RS-485 interface. The interface carries active signals!
