Grace Q'nique 19 Manual

For thread
Hide thumbs Also See for Q'nique 19:
1
2
3
4
Table of Contents

Advertisement

Quick Links

Download this manual

Thread Guide

8

Troubleshooting

If your thread is breaking...
• Replace your needle if it
is bent or burred. Use the
needle magnet to install and
align the needle (see page
56).
• Follow the "Top Thread
Tension" guide on the back
to correct your thread
tension.
• Check that your machine is
threaded correctly using the
"Thread Guide" above.
• Follow the "Bobbin Guide"
on the back for threading,
tensioning, and installing the
bobbin case.
2
1
3
4
6
5
9
7
• Check the hopping foot
height (see page 59).
• Adjust the height of the
take-up rail on your quilting
frame to be 1/4 inch above
the needle plate.
• For more help call
1(800) 264-0644 or e-mail
support@graceframe.com.
If your machine is skipping
stitches...
• Replace your needle if it
is bent or burred. Use the
needle magnet to align and
install your needle straight
(see page 56).
10
11
1
1.
Thread Cone
2
2.
Thread Mast
3
3.
Dual Thread Guide
4
4.
Small Tensioner
5
5.
Large Tensioner
6.
6
Check Spring
7.
Thread Guide
7
8.
8
Take-up Lever
9.
Bottom Thread Guide
9
1.
Needle Bar Eyelet
10
2.
Eye of Needle
11
• Follow the "Top Thread
Tension" guide on the back
to correct your thread
tension.
• Check the hopping foot
height (see page 59).
• Adjust the height of the
take-up rail on your quilting
frame to be 1/4 inch above
the needle plate.
• For more help call
1(800) 264-0644 or e-mail
support@graceframe.com.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Q'nique 19 and is the answer not in the manual?

Questions and answers

Related Manuals for Grace Q'nique 19

Summary of Contents for Grace Q'nique 19

  • Page 1: Thread Guide

    Thread Cone Thread Mast Thread Guide Dual Thread Guide Small Tensioner Large Tensioner Check Spring Thread Guide Take-up Lever Bottom Thread Guide Needle Bar Eyelet Eye of Needle Troubleshooting If your thread is breaking... • Check the hopping foot • Follow the “Top Thread height (see page 59).

  • Page 2: Needle Information

    If the top thread is pulled through the bottom layer of fabric, increase tension. Bobbin Thread Top Thread If the bobbin thread is pulled through the top layer of fabric, decrease tension. Bobbin Thread Copyright October 7, 2019 Grace Company Version 1.1...

  • Page 3: Sewing Screen

    Sewing Button Controls Move Needle Up/Down Increase Change Single Stitch Speed Sewing Mode (change in Settings) Decrease Settings Start/Stop Speed Stitching *These buttons may be reversed in Settings for left-handed quilters. Sewing Screen Regulated Regulated Regulated Manual Baste Cruise Precise Cruise Short Min Speed...

  • Page 4: Settings Screen

    Total hours will SPI to SPC on the Sewing not reset. Screen. Reverse Handle Buttons Reverse the left and right handle button controls. This is useful for left-handed quilters. System Information Screen Settings Copyright October 7, 2019 Version 1.1 Grace Company...
