7. Error messages on the handswitch display
Code
Overheating has caused it to stop the
HOT control unit
00 Internal Error Channel 1
01 Internal Error Channel 2
02 Internal Error Channel 3
12 Defect Channel 1
13 Defect Channel 2
14 Defect Channel 3
24 Overcurrent Motor M1
25 Overcurrent Motor M2
26 Overcurrent Motor M3
48 Overcurrent Motor Group 1
49 Overcurrent Motor Group 2
60 Collision protection
62 Overcurrent Control Unit
36 Plug detection in Motor socket M1
37 Plug detection in Motor socket M2
38 Plug detection in Motor socket M3
61 Actuator changed
Synchronization lost motor group 1
55
Synchronization lost motor group 2
56
High voltage
67
Motor configuration changed
70
Anti-Pinch configuration changed
71
Internal error
81
Connection error in the cascaded
network
(The error appears on the display for
93
15 seconds and then the control unit
goes into reset mode with the display
flashing 000)
You can find the original operation manual of the control unit Compact-e-EU on the producers homepage:
http://www.logicdata.at/
Description Remedy
•
Wait until the control unit has cooled down
and HOT is no longer displayed
•
Unplug the power cord and contact your RK
contact person
•
Unplug the control unit.
•
Fix the external short circuit or plug in the
correct motor to the motor socket that shows
the error.
•
Start the control unit again.
•
Remove jammed objects from the driving area.
•
Desk might be overloaded Remove load from
desk.
•
Contact your RK contact person
•
Plug in the correct motor to the motor socket
that shows the error.
•
Reset all motors.
•
Remove load from desktop.
•
Reset all motors.
•
If error occurs after reset again, contact your
RK contact person
•
Unplug the power cord and contact the
customer service
•
See chapter 4
•
See the operation manual of the control unit
Compact-e-EU on the producers homepage:
http://www.logicdata.at/
•
Make a manual reset
•
Unplug the power cord and plug it in again
after a few seconds.
•
If this error occurs frequently, unplug the
power cord and contact your RK contact
person.
•
Check all the cable connections and try to reset
the motors.
•
If you cannot reset the motors, disconnect all
the control units from the power supply. Wait
for at least 5 seconds and then reconnect all
the control units to the power supply. Try to
reset the motors again.
•
If you still cannot reset the motors, please
contact your RK contact person
Bestell-Nr. 99425 Ausgabe 11.2014 Version 1-0
