Summit STC6 Owner's Manual

Freestanding countertop wine cooler
Hide thumbs
Table of Contents

Advertisement

Quick Links

Freestanding Countertop Wine Cooler
STC6
Models:
STC12
Owner's Manual
BEFORE USE, PLEASE READ AND FOLLOW
ALL SAFETY RULES AND OPERATING INSTRUCTIONS
Felix Storch, Inc.
An ISO 9001:2015 registered company
Write Serial Number here:
Summit Appliance Division
________________________
770 Garrison Avenue
Bronx, NY 10474
www.summitappliance.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the STC6 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Summit STC6

Summary of Contents for Summit STC6

  • Page 1 STC6 Models: STC12 Owner’s Manual BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS Felix Storch, Inc. An ISO 9001:2015 registered company Write Serial Number here: Summit Appliance Division ________________________ 770 Garrison Avenue Bronx, NY 10474 www.summitappliance.com...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Important Safeguards ............3 – 5 Installation Instructions ............6 Before using your appliance ..........6 Installation of your appliance ........... 6 Storage ................6 Installation of drainage pipes .......... 6 Operating Your Appliance ..........7 – 9 Recommended temperatures for chilling wine ....

  • Page 3: Important Safeguards

    IMPORTANT SAFEGUARDS  Read all instructions before using the appliance.  This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
  • Page 4 any other appliance. The fumes can create a fire hazard or explosion.  Use two or more people to move/install the refrigerator. Failure to do so can result in back or other injury.  The appliance should not be located next to ovens, grills or other sources of high heat. ...

  • Page 5: Save These Instructions

     Replacing component parts and servicing shall be done by factory authorized service personnel so as to minimize the risk of possible ignition due to incorrect parts or improper service.  DANGER! Risk of child entrapment! When you dispose of the appliance, take off the door and leave the shelves in place so that children may not easily climb inside.

  • Page 6: Installation Instructions

    Storage  For Model: STC6 This appliance can load 6 bottles whose diameter is less than 105mm.  For Model: STC12 This appliance can load 12 bottles whose diameter is less than 81mm.

  • Page 7: Operating Your Appliance

    OPERATING YOUR APPLIANCE Recommended temperatures for chilling wine Red Wines: 15 ~ 18°C (59 ~ 64.4°F) Dry / White Wines: 9 ~ 14°C (48.2 ~ 57.2°F) Sparkling Wines: 5 ~ 8°C (41 ~ 46.4°F)  The appliance should be placed where the ambient temperature is between 18 and 32°C (65 and 90°F).

  • Page 8: Demo Mode

    Light / Lock  LED lamp brightness mode: with Memory IC (when unit restarts after power failure unit, will auto recover to last setting), the default brightness is 100%. Each time the button is pressed, the brightness of the LED will be cycled through the four positions (100%, 75%, 50%, OFF) ...

  • Page 9: Temperature Alarm Function

     When you use the appliance for the first time, or restart it after it has been shut off for a long time, there could be a few degrees variance between the temperature you select and the one indicated on the display. This is normal and due to the length of inactivation time. Once the appliance has been running for a few hours, everything will be back to normal.

  • Page 10: Care And Maintenance

    CARE AND MAINTENANCE Cleaning Your Appliance 1. Turn off the power, unplug the appliance, and remove all items. 2. Wash the inside surfaces with a warm water and baking soda solution. The solution should consist of about 2 tablespoons of baking soda to a quart of water. 3.

  • Page 11: Problems With Your Appliance (Troubleshooting)

    PROBLEMS WITH YOUR APPLIANCE You can solve many common problems easily, saving you the cost of a possible service call. Try the suggestions below to see if you can solve the problem before calling the servicer. TROUBLESHOOTING GUIDE PROBLEM POSSIBLE CAUSE REMEDY ...

  • Page 12: Limited Warranty

    LIMITED WARRANTY ONE-YEAR LIMITED WARRANTY Within the 48 contiguous United States, for one year from the date of purchase, when this appliance is operated and maintained according to instructions attached to or furnished with the product, warrantor will pay for factory-specified parts and repair labor to correct defects in materials or workmanship.

This manual is also suitable for:

Stc12
