Bradley TouchTime 1C Installation

Individual built-in wall shower with concealed supplies

Make sure that all water supply lines have been flushed and then completely turned off before beginning

installation. Debris in the supply lines can cause valves to malfunction.

Water supply requires a flowing pressure of at least 20 psi, but no greater than 80 psi.

Read this entire installation manual to ensure proper installation. When finished with the installation, file

this manual with the owner or maintenance department. Compliance and conformity to local codes and

ordinances is the responsibility of the installer.

Separate parts from packaging and make sure all parts are accounted for before discarding packaging

material. If any parts are missing, do not begin installation until you obtain the missing parts.

Product warranties may be found under "Products" on our website at www.bradleycorp.com.

215-1855 Rev. A; ECN 17-03-011

Page 1 of 5 8/23/2017

Installation

Bradley 1C TouchTime

Individual Built-In Wall

Shower with Concealed

Supplies

Pre-Installation Information . . . . . . . . . . . . . . . . . . . . . . . 2

Rough-In . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Make Electrical Connections . . . . . . . . . . . . . . . . . . . . . . 4

Adjusting the TouchTime Module . . . . . . . . . . . . . . . . . . 4

Complete Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

TouchTime Valve Parts List . . . . . . . . . . . . . . . . . . . . . . 5

WARNING

NOTICE

IMPORTANT

P.O. Box 309

Menomonee Falls, WI 53052 USA

800 BRADLEY (800 272 3539)

+1 262 251 6000

bradleycorp.com

Table of Contents

Need help?

Do you have a question about the TouchTime 1C and is the answer not in the manual?

Page 1 Product warranties may be found under “Products” on our website at www.bradleycorp.com. P.O. Box 309 215-1855 Rev. A; ECN 17-03-011 Menomonee Falls, WI 53052 USA © 2017 Bradley 800 BRADLEY (800 272 3539) +1 262 251 6000 Page 1 of 5 8/23/2017 bradleycorp.com...
Page 2 • 110 VAC power source for 12V DC plug in adapter (available from Bradley as an option) • OPTIONAL: Bradley recommends installing an electrical cut-off switch to the unit . This feature allows no accidental water delivery during regular maintenance and service .
Page 3 Install two #10 wall Escutcheon anchors (supplied by installer) to secure pushbutton assembly . 2-1/4" (2) #10-24 Screw (57mm) (supplied by Bradley) and (2)#10 wall 4-1/4" anchors (supplied (108mm) by installer) 5-7/8" (149mm) Bradley • 215-1855 Rev. A; ECN 17-03-011 8/23/2017...
Page 4 (4 through 9 for no flush, A though F for 24 hours flush) as indicated on the module label . Bradley • 215-1855 Rev. A; ECN 17-03-011 8/23/2017...
Page 5 . Many products named are regional in distribution, and can be found in local supermarkets, department and hardware stores, or through your cleaning service . It is emphasized that all products should be used in strict accordance with package instructions . Bradley • 215-1855 Rev. A; ECN 17-03-011 8/23/2017...
