  • Page 1 Control Panel User Manual Network Security Control Panel User Manual UD.6L0206D1044A02...
  • Page 2 BUSINESS INTERRUPTION, OR LOSS OF DATA OR DOCUMENTATION, IN CONNECTION WITH THE USE OF THIS PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT SHALL BE WHOLLY AT...
  • Page 3 SURVEILLANCE LAWS VARY BY JURISDICTION. PLEASE CHECK ALL RELEVANT LAWS IN YOUR JURISDICTION BEFORE USING THIS PRODUCT IN ORDER TO ENSURE THAT YOUR USE CONFORMS THE APPLICABLE LAW. HIKVISION SHALL NOT BE LIABLE IN THE EVENT THAT THIS PRODUCT IS USED WITH ILLEGITIMATE PURPOSES.
  • Page 4 Control Panel User Manual Regulatory Information FCC Information FCC compliance: This equipment has been tested and found to comply with the limits for a digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 5 Control Panel User Manual Safety Instruction These instructions are intended to ensure that the user can use the product correctly to avoid danger or property loss. The precaution measure is divided into ‘Warnings’ and ‘Cautions’: Warnings: Serious injury or death may be caused if any of these warnings are neglected. Cautions: Injury or equipment damage may be caused if any of these cautions are neglected.
  • Page 6 Control Panel User Manual Cautions:  Make sure the power supply voltage is correct before using the product.  Do not drop the product or subject it to physical shock. Do not install the product on vibratory surface or places. ...

  • Page 7: Table Of Contents

    Content Chapter 1 Introduction ______________________________________________ 10 1.1 Overview _________________________________________________________ 10 1.2 Feature ___________________________________________________________ 10 Chapter 2 Installation and Wiring _____________________________________ 10 2.1 Main Board Overview _______________________________________________ 13 2.2 Device Wiring ______________________________________________________ 14 2.2.1 Detector Wiring _______________________________________________________ 14 2.2.2 Alarm Output Wiring ___________________________________________________ 16 2.2.3 Keypad Wiring _________________________________________________________ 16 2.3 System Start-up ____________________________________________________ 17...
  • Page 8 Control Panel User Manual 3.1.20 Siren Linked Event Configuration __________________________________________ 45 3.1.21 Emergency Alarm Linkage Configuration ____________________________________ 46 3.1.22 Control Panel Tampering Alarm Configuration _______________________________ 47 3.1.23 Testing Report Configuration _____________________________________________ 47 3.1.24 Partition Configuration __________________________________________________ 49 3.1.25 Public Partition Settings _________________________________________________ 55 3.1.26 Fault Detection Configuration ____________________________________________ 55 3.1.27...
  • Page 9 Control Panel User Manual 4.1 Installing the iVMS-4200 _____________________________________________ 90 4.2 User Registration and Login ___________________________________________ 94 4.3 Network Security Control Panel Settings ________________________________ 95 4.3.1 Add/Edit/Delete the Device ______________________________________________ 95 4.4 Remote Configuration _______________________________________________ 96 4.4.2 System Information Configuration _________________________________________ 97 4.4.3 Network Configuration _________________________________________________ 103 4.4.4...

  • Page 10: Chapter 1 Introduction

    Control Panel User Manual Chapter 1 Introduction 1.1 Overview The DS-19A08-F/Kx(G) is a commercial control panel with 8 partitions supported. The panel uses embedded microcontroller technology for zones monitoring and system status detection. The alarm or status reports can be transmitted to the central alarm monitoring station through programming.
  • Page 11 Control Panel User Manual Up to 8 channel extension relay outputs; Relay outputs can be triggered by alarm events or system events; Partitioning 8 partitions, which can be controlled independently; 1 common partition (No.1 partition), that can be programmed to be linked with any other two partitions;...
  • Page 12 Control Panel User Manual Allows remote control operations with mobile client; Message control operations, such as arming, disarming, and clearing the alarm, via short messages sent from the bound phone number; Peripherals Devices Provides a half-duplex RS-485 device bus, which can interface with keypads and relay modules;...

  • Page 13: Chapter 2 Installation And Wiring

    Control Panel User Manual Chapter 2 Installation and Wiring 2.1 Main Board Overview...

  • Page 14: Device Wiring

    Control Panel User Manual Description Description Power Adapter Handset Interface Lead-acid Battery Incoming Telco Line Interface Alarm Bell Alarm Input Interface Alarm Output (Alarm SIM Card/2G Card Slot Lamp) RS-485 Terminals Buzzer Auxiliary Power Interface TAMPER Switch (DC Output） RS-485 TERMINATION RTC CLOCK Button Cell Resister LAN Interface...
  • Page 15 Control Panel User Manual The wiring of sensor is shown as follows. Alarm Host Peripheral Security Detector Alarm Host Peripheral Security Detector 2.2KΩ 2.2KΩ Normal Opened Detector Normal Closed Detector The Tamper-proof wiring is shown below. 2.2KΩ TAMPER ZONE DETECTOR...

  • Page 16: Alarm Output Wiring

    Control Panel User Manual 2.2.2 Alarm Output Wiring The alarm output interfaces of the control panel are show as follows. The wiring of alarm output is shown as follows: DC12V DC12V AC220V Relay NO/NC NO/NC Breaker Breaker External Device External Device External DC Load External AC Load The DC current supplied by the control panel is used for external devices.

  • Page 17: System Start-Up

    Control Panel User Manual 2.3 System Start-up For configuring the security control panel, you should restore the system of the control panel after start-up. 2.3.1 Control Panel Start-up The keypad registration will be completed in 10 seconds after the control panel being power on.
  • Page 18 Control Panel User Manual LED Alarm Keypad Network Indicator Working Status Indicator Status Proper Network Green (Flickering) Network Exception LED Alarm Keypad Status Indicator Working Status Indicator Status System Works Properly System Exception Red (Continuously Light) LED Alarm Keypad Partition Indicator Working Status Indicator Status Single Partition...
  • Page 19 Control Panel User Manual Working Status Indicator Status Remote Control Green (Flickering) Connecting Pacing Mode Red (Continuously Light) LED Alarm Keypad Ready Indicator Working Status Indicator Status Normal Green (Continuously Light) In Project Red (Flickering) Main Operator Green (Flickering) Password Editing Remote Control Red (Flickering) Connecting...

  • Page 20: Keypad Address

    Control Panel User Manual No. Description No. Description Disconnection Receive Hands-shake Alarm Connecter On-hook Sound LED Alarm Keypad Channel Indicator Status in Status Mode No. Description No. Description AC Power Outages Keypad Disconnection Low Battery for Network Disconnection Accumulator Control Panel Tampering No SIM Card Alarm Enabled Telephone Line...

  • Page 21: Activating The Control Panel

    Control Panel User Manual Main User Password: 1234 Power Recovery Default Installer Password: No Arming/Disarming Report: Yes Control Panel Hijack Report: N/A CID Report： Account#1#2: No Dialing Type: DTMF Remote control Programming: No For Detailed CID code, Please refer to CID Report. Zone: Zone 1 to 8: Real-time zone Urgent Soft Zone: Buzzing prompt sound...
  • Page 22 Control Panel User Manual Get the SADP software from the supplied disk or the official website, and install the SADP according to the prompts. Follow the steps to activate the control panel. Steps: 1. Run the SADP software to search the online devices. 2.
  • Page 23 Control Panel User Manual STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product. And we recommend you reset your password regularly, especially in the high security system, resetting the password monthly or weekly can better protect your product.
  • Page 24 Control Panel User Manual  Activation via Client Software The client software is versatile video management software for multiple kinds of devices. Get the client software from the supplied disk or the official website, and install the software according to the prompts. Follow the steps to activate the control panel.
  • Page 25 Control Panel User Manual 3. Check the device status from the device list, and select an inactive device. 4. Click the Activate button to pop up the Activation interface. 5. Create a password and input the password in the password field, and confirm the password.
  • Page 26 Control Panel User Manual 6. Click OK button to start activation. 7. Click the Modify Netinfo button to pop up the Network Parameter Modification interface, as shown in the figure below. 8. Change the device IP address to the same subnet with your computer by either modifying the IP address manually or checking the checkbox of Enable DHCP.

  • Page 27: Chapter 3 Keypad Operation

    Control Panel User Manual Chapter 3 Keypad Operation (Local Operation） 3.1 Alarm Keypad Configuration You should access the programming mode (only installer can access the programming mode) before keypad configuration. The command is shown below: 012345 *0# {1} Installer password: 012345 {2} Command Key: *0 # The command for exiting programming mode is *#.

  • Page 28: Operator Configuration

    Control Panel User Manual {3} End the command. 3.1.2 Operator Configuration The programming command of operator configuration is shown below. 001 *2 1234 # {1} Operator Programming Address: 001～016. {2} User Permission: 12 permissions. For details, please refer to the following table.

  • Page 29: Zone Parameters Configuration

    Control Panel User Manual Disarming Report Arming/Disarming Report Bypass Bypass {3} Specified the username and password, the length of user name should be in the range of 2 to 5 characters. {4} End the command. The username and password cannot be empty. If the password is configured as 0, the user will be deleted.
  • Page 30 Control Panel User Manual Command Command Command Command Description Description 10 ms 250 ms 500 ms 750 ms {3} Zone Arming Type Command Command Command Description Command Description 24-hour voiced None zone Delay Zone Internal Delay Zone Key Arming/Disarming Real-time Zone Zone 24-hour non-voiced Fire Zone...
  • Page 31 Control Panel User Manual Command Command Command Command Description Description Alarm Output 1/2/4Alarm Output Linking Local 3/4 Linking Local 1/3/4 Alarm Output Alarm Output Linking Local 2/3/4 Linking Local 1/2/3/4 Alarm Output Alarm Output {5} Liked Alarm Output. Command Command Command Command Description...
  • Page 32 Control Panel User Manual The fire alarm zone do not support the configuration of zone loop type, and can only be set as 0,or an error value will be returned. {9} Tampering Prevention Linked Trigger Command Command Command Command Description Description Non-linked Local Linking Local 1 Alarm...

  • Page 33: Telco Line Communication Control

    Control Panel User Manual Description Description No Tampering With Tampering Prevention Prevention Recovery Recovery Report Report {12} End the command. 3.1.4 Telco Line Communication Control The communication control command is used for setting the phone connection mode of alarm center 1 and 2. The detailed command is shown below.

  • Page 34: Dialing Account Configuration

    Control Panel User Manual Command Command Command Command Description Description 4 Times 12 Times 5 Times 13 Times 6 Times 14 Times 7 Times 15 Times 8 Times {6} End the command. 3.1.5 Dialing Account Configuration The control panel supports phone dialing to upload alarm information. The dialing account command is shown below.

  • Page 35: Alarm Receiver Phone Number Settings

    Control Panel User Manual 3.1.6 Alarm Receiver Phone Number Settings The control panel supports two dialing accounts. The maximum length of dialing number of each account is 31 digits. The command is shown as follows. E0 ∙∙∙∙∙∙0 # {1} Programming Address of Phone Number of Alarm Connecter: 460~463 Command Command...

  • Page 36: Zone Associated Trigger Configuration

    Control Panel User Manual phone number via the keypad. Steps: 1. Enter 46017951FFF88075998# with the keypad. 2. Enter 461*4# to complete the settings. 3.1.7 Zone Associated Trigger Configuration The detailed programming command is shown below. 467 000 0 00 # {1} Trigger Configuration Programming Address: 467 {2} Zone No.
  • Page 37 Control Panel User Manual 468 00 0 00 00 # {1} The programming address of enabling trigger event linkage is 468～ 469. Command Function Description Command Function Description Enable Trigger Event Disable Trigger Event Linkage Linkage {2} Trigger No. {3} Add/ Delete Trigger Command Function Description Command Function Description Delete Trigger Add Trigger...

  • Page 38: Trigger Time Settings

    Control Panel User Manual Command Command Command Command Command Command Description Description Description Entering Exiting Arming Delay Delay Disarming Alarm Alarm Clearing Alarm Recovery {6} End the command. After successfully operating once, you can continuously do configuration with the command of {Project} + { Trigger No.} + {System Command.} + {Event Command} + {#}.

  • Page 39: Siren Configuration

    Control Panel User Manual 3.1.10 Siren Configuration For siren configuration, please refer to the command below. 471 1 # {1} Siren Configuration Programming Address: 471 {2} Enable/Disable Siren Command Command Command Command Command Description Description Disable Enable {3} End the Command. 3.1.11 Control Panel Time Settings For control panel time settings, please refer to the command below.

  • Page 40: Control Panel Ip Configuration

    Control Panel User Manual 3.1.12 Control Panel IP Configuration For control panel IP configuration, please refer to the command below. 473 192 000 000 064 # {1} Control Panel IP Configuration Programming Address: 473. {2} Unit 1 {3} Unit 2 {4} Unit 3 {5} Unit 4.

  • Page 41: Subnet Mask Configuration

    Control Panel User Manual {7} End the command. Corresponding port number must be 5 digits. When the place is not sufficient, fill it up with 0. For example: When the port number is 6000, the programming command is: 474 06000#. 3.1.13 Subnet Mask Configuration The programming command of control panel subnet mask setting is shown below:...

  • Page 42: Gprs Configuration

    Control Panel User Manual {3} The Second Unit; {4} The Third Unit; {5} The Fourth Unit; {6} End the command. 3.1.15 GPRS Configuration The programming command of GPRS settings is shown below: {1} The programming command address of GPRS setting are: 477 {2} Name of APN;...

  • Page 43: Uploading Center Ip Configuration

    Control Panel User Manual 478 0 0 0 0 0 0 0 0 0 0 0 # 9 10 11 12 13 {1} The programming command address of SIM card No. settings is 478. {2}~{12} SIM card No. {13} End the command. 3.1.17 Uploading Center IP Configuration The programming command of uploading center IP setting is shown below: 485 000 000 000 000 #...

  • Page 44: Uploading Center Port Configuration

    Control Panel User Manual 3.1.18 Uploading Center Port Configuration The programming command of uploading center port setting is shown below: 486 00000 # {1} The programming command addresses of uploading center port setting are: 486, 489, 492, 495; Command Description Command Description Programming...

  • Page 45: Siren Linked Event Configuration

    Control Panel User Manual Network Center 1 Network Center 2 Protocol and Protocol and Programming Programming Address Address of Account of Account Settings Settings GPRS Center 1 GPRS Center 2 Protocol and Protocol and Programming Programming Address Address of Account of Account Settings Settings {2} Protocol Type:...

  • Page 46: Emergency Alarm Linkage Configuration

    Control Panel User Manual Command Description Command Description Command Description Null Control Global Panel Keypad Tampering Emergency Alarm Alarm Telco Line Disconnected Battery Disconnected Voltage Wired Wireless Keypad /485 Network Network Device Exception Exception Disconnected The partition event types are shown below. Command Description Command...

  • Page 47: Control Panel Tampering Alarm Configuration

    Control Panel User Manual 510 00 0 # {1} The programming command address of emergency alarm linkage setting is: 510; {2} Partition Number, 00 indicate the global keypad, 01~08 indicate partitions No.1~No.8; {3} Whether to link the siren or not; Command Description Command...
  • Page 48 Control Panel User Manual alarm center. The detailed operation is show as follows. 513 0 1 5 # {1} The testing report programming address is 513. {2} Enable/Disable the Testing Report Command Command Command Command Description Description Disable Enable {3} Timer of the Testing Report. Command Command Command...

  • Page 49: Partition Configuration

    Control Panel User Manual {5} End the command. 3.1.24 Partition Configuration Partition Start-up Configuration The programming command of the partition start-up configuration is shown below. 531 1 1 # The programming of partition start-up configuration is: 531～538. The configuration item of 1 indicates the start-up configuration of the partition.
  • Page 50 Control Panel User Manual 531 2 0 000 # The programming command address of keypad user configuration is 531～538. The configuration item of 2 indicates the keypad user configuration. Add/Delete the user. Command Command Command Command Description Description Delete The user No. End the command ...
  • Page 51 Control Panel User Manual 531 3 0 000 # The programming command addressof zone configuration is 531～538. The configuration item of 3 indicates zone configuration of the partition. Add/Delete Zone. Command Command Command Command Description Description Delete Zone No. End the command. There are three mode to add/delete zone for the partition, adding/deleting separately,...
  • Page 52 Control Panel User Manual 538. {2} The configuration item of 4 indicates keypad configuration. Add/Delete Command Command Command KeypadCommand Description Description Delete {3} Keypad No. {4} End the command. There are three mode to add/delete zone for the partition, adding/deleting separately, Adding/ Deleting...
  • Page 53 Control Panel User Manual {4} Exiting Delay Command Command Command Command Command Command Description Description Description 10sec 60sec 110sec 20sec 70sec 120sec 30sec 80sec 130sec 40sec 90sec 140sec 50sec 100sec 150sec {5} Siren Working Duration Command Command Command Command Command Command Description Description...
  • Page 54 Control Panel User Manual {1} system report and arming prompt sound programming address: 531 {2} Classification Option of Report and Arming Prompt Sound: 6 {3} Arming/disarming Report Ending Prompt Sound {4} Manual Testing Report Sending Prompt Sound. {5} Prompting sound of arming succeeded. {6} Prompting sound of disarming succeeded {3}～{6} Command...

  • Page 55: Public Partition Settings

    Control Panel User Manual 3.1.25 Public Partition Settings The programming commands of public partition settings are as below: 563 0 0 0 # {1} The public partition settings address is 563. {2} Enable/Disable public partition. Command Command Command Command Description Description Disable Enable...
  • Page 56 Control Panel User Manual {7} Neywork Exception {8} Wireless Network Exception Command Command Command Command Description Description Disable Enable {9} End the command. If the fault detection is disabled, the control panel will not detect or report this sort of fault. Keypad Fault Display Configuration To configure the system fault display, please refer to the command below.
  • Page 57 Control Panel User Manual Keypad Fault Prompt Sound Configuration To configure the keypad fault prompt sound, please see the command below. 566 1 1 1 1 1 1 1 # {1} Keypad fault prompt sound configuration programming address: 566. {2} Ac Power Down {3} Low Battery {4} Control Panel Tampering Alarm {5} Phone Line Disconnection...
  • Page 58 Control Panel User Manual {2} The Tens’ Digit of the Partition No. {3} The Units’ Digit of the Partition No. {4} Ac Power Down {5} Low Battery {6} Control Panel Tampering Alarm {7} Phone Line Disconnection {8} Main keypad Disconnection {9} Neywork Exception {10} GPRS Exception Command...

  • Page 59: Center Group Configuration

    Control Panel User Manual {11} End the command. 3.1.27 Center Group Configuration Center Group Enabling Configuration To enable the center group, please see the command below. 611 0 {1} Center Group Enabling Programming Address: 611, 615, 619, 623, 627and 631. Command Command Command...
  • Page 60 Control Panel User Manual {3} End the command. Center Group Uploading Mode Configuration To configure the center group uploading mode, please see the command below. 612 0 0 0 0 # {1} Center Group Uploading Mode Programming Address: 612, 616, 620, 624, 628 and 632.
  • Page 61 Control Panel User Manual Command Command Command Command Description Description {6} End the command. There are 6 channels (T1, T2, N1, N2, G1 and G2) of the network security control panel. Each channel can be only used once during the center group uploading configuration, no matter it is served as the main channel or backup channel, Center Group Zone Alarm Report Configuration...
  • Page 62 Control Panel User Manual Command Command Command Command Description Description Programming Address Programming Address Center Group 5 Zone Center Group 6 Alarm Report Zone Alarm Report Programming Address Programming Address {2} Delete/Add {3} Zone No. {4} End the command. The operation of adding/ deleting is just for current center group sending/not sending report, and will not impact other center groups.

  • Page 63: Whitelist Parameters Configuration

    Control Panel User Manual Non-zone Alarm Non-zone Alarm Report Programming Report Programming Address Address Center Group 5 Center Group 6 Non-zone Alarm Non-zone Alarm Report Programming Report Programming Address Address {2} Soft Zone Report {3} System Status Report {4} Alarm Clearing Report {5} Testing Report {6} Arming Report {7} Disarming Report...
  • Page 64 Control Panel User Manual {1} Non-zone Alarm Report Configuration Command Address: 680. {2} White List Number. 01~08 indicate white list No.1~No.8. {3} Enable/Disable the Non-zone Alarm Report Command Command Command Command Description Description Disable Enable {4} Soft Zone Report {5} System Status Report {6} Alarm Clearing Report {7} Testing Report {8} Arming Report...
  • Page 65 Control Panel User Manual {1} Partition Arming Permission Configuration Command Address: 681 {2} White List Number. 01~08 indicate white list No.1~No.8. {3} The Arming Permission of Partition 1 {4} The Arming Permission of Partition 2 {5} The Arming Permission of Partition 3 {6} The Arming Permission of Partition 4 {7} The Arming Permission of Partition 5 {8} The Arming Permission of Partition 6...
  • Page 66 Control Panel User Manual {3}~{10} Enable/Disable the Permission of Partition Disarming Command Command Command Command Description Description Disable Enable {11} Completing Partition Alarm Clearing Permission Configuration To configure the permission of partition alarm clearing, please refer to the command below. 683 00 0 0 0 0 0 0 0 0 # 9 10 11 {1} Partition Alarm Clearing Permission Configuration Command...
  • Page 67 Control Panel User Manual The Interval Time of Whitelist Configuration To configure the interval time of white list, please refer to the command below. 684 01 0 0 0 0 0 # {1} The interval time of White List Configuration Command Address: 684.
  • Page 68 Control Panel User Manual {3} Handset No. Segment Command Command Command Command Description Description The first 16 The last 16 characters of the 32 characters of the characters 32 characters {4} The dialing number is 16 digits.  The letter E at the beginning of {5} can be set as A, indicating “+”.

  • Page 69: Schedule Configuration

    Control Panel User Manual  When the Zone No. has no hundreds’ digit, {4} can be omitted. Example: When you want to send report of Zone No.16. The command is 68601116#.  When the Zone No. has no hundreds’ digit and tens’ digit, {4} and {5} can be omitted.
  • Page 70 Control Panel User Manual Disable Enable {5} End the command. Weekly Schedule Time Parameter Configuration To configure the time parameters of the weekly schedule, please refer to the command below. 691 01 1 1 0 0 0 0 0 0 0 0 E # 9 10 11 12 13 14 {1} Weekly Schedule Time Parameter Configuration Command Address: 691.
  • Page 71 Control Panel User Manual  When you set the start and end time as non-zero, end time must be greater than start time in every time bucket.  When you set the start and end time as non-zero, the start time must be 5min greater than the end time of the previous time bucket.
  • Page 72 Control Panel User Manual {4} It indicates the value range of the day (l). Command Description Command Description Command Description Monday Tuesday Wednesday Thursday Friday Saturday Sunday {5} Completing Copy Weekly Schedule of Partition To copy the settings of partition (m) to partition (n), please refer to the command below.
  • Page 73 Control Panel User Manual {3} It indicates to enable/disable the mandatory arming/disarming. Command Command Command Command Description Description Disable Enable {4} It indicates to enable/disable the prior schedule. Command Command Command Command Description Description Disable Enable {5}~{12} It indicates the start date and end date. Start Date: {5}{6}/{7}{8}.
  • Page 74 Control Panel User Manual No.1~No.8. Command Command Command Command Description Description Disable Enable {11} End the command. Prior Schedule Time Parameter Configuration To configure the time parameters of the prior schedule, please refer to the command below. 696 00 0 0 0 0 0 0 0 0 0 E # 9 10 11 12 13 {1} Prior Schedule Time Parameter Configuration Command Address: 696.
  • Page 75 Control Panel User Manual  When you set the start and end time as non-zero, the start time must be 5min greater than the end time of the previous time bucket.  When you set the start and end time as non-zero, if the time bucket is overlapped with the latter ones, or the difference between them is less than 5min, all the settings of the latter ones will be cleared.
  • Page 76 Control Panel User Manual 698 0 0 0 0 # {1} Trigger Schedule Trigger Parameter Configuration Command Address: 698. {2} It indicates to delete/add the trigger schedule. Command Command Command Command Description Description Delete {3} Trigger No.: Hundreds’ Digit {4} Trigger No.: Tens’ Digit {5} Trigger No.: Digit {6} End the command.

  • Page 77: Wireless User Permission Configuration

    Control Panel User Manual  When you set the start and end time as 00:00 and 00:00, all the settings from the present time bucket to the maximum time bucket will be cleared.  When you set the start and end time as non-zero, the previous time bucket must be non-zero.

  • Page 78: Keypad Alarm Operation Code

    Control Panel User Manual {6} Alarm Clearing {2}~{6} Command Command Command Command Description Description Supported Unsupported {7} End the command. 3.2 Keypad Alarm Operation Code 3.2.1 Device Initialization Control panel can be recovered through the alarm keypad initialization; see the command below. {Installer Code} + {*} + {8} + {9} + {#} ...

  • Page 79: Stay Arming

    Control Panel User Manual disarming (current status) into arming immediately. The exiting delay of partition is 0. 3.2.3 Stay Arming Operation Method: {User password} + {*} + {4} + {#}.Take the password 1234 as an example, and the operation is shown as follows: {1} + {2} + {3} + {4} + {*} + {4} + {#} After the operation is completed, the partition will change the status of disarming (current status) into arming immediately.

  • Page 80: Group Bypass Recovery

    Control Panel User Manual 3.2.6 Group Bypass Recovery After recovering the group bypass of a partition, all the alarm devices in group-bypass supported zone of the partition will be revalidated. See the command below. {User Password} + {*} + {4} + {2} + {#} 3.2.7 Keypad Cancel Alarm When the alarm is trigged, it can be canceled by keypad.

  • Page 81: System Status Query

    Control Panel User Manual 3.2.10 System Status Query In query mode, there are special meanings (see the table below) for the 8 indicators on alarm keypad. Press the {Status} key for current system information Query. Serial Meaning Serial Meaning Number Number AC Power Keypad...

  • Page 82: Deleting All The Connected Wireless Device

    Control Panel User Manual 3.2.13 Deleting all the Connected Wireless Device Follow the command below to delete all the connected wireless devices. {password} + {*} + {92} + {#} 3.2.14 Main Operator Password Changing The user password can be changed by main operator. The operations are divided into following steps: Steps: 1.

  • Page 83: Alarm Center Test

    Control Panel User Manual 3.2.17 Alarm Center Test Partition keypad operation is used to test the communication between control panel and the alarm center; see the command below: {password} + {*} + {6} + {1} + {#} One operation generates one test report. It is used to test the communication between the control panel and center after installing the system or during the inspection.

  • Page 84: Lcd Backlight Off

    Control Panel User Manual 3.2.21 LCD Backlight off For Disabling the LCD backlight, see the command below: {*} +{8} + {#} 3.2.22 Pacing The pacing function is used for debugging; see the command below: {password} + {*} + {6} + {0} + {#} ...

  • Page 85: Control Panel Soft Recovery

    Control Panel User Manual 3.2.24 Control Panel Soft Recovery For control panel soft recovery; see the command below: {master code} + {*} + {6} + {8} + {#}  All unissued CID logs will not be reissued. Newly generated report will be issued after system recovery.

  • Page 86: System Status Display Demonstration

    SYS5R SYS6R SYS7R SYS8R The system status description is shown below. System Status Description SYS1D Partition1 Disarmed SYS2R Partition2 Ready SYS3A Partition3 Armed SYS4R Partition4 Ready SYS5R Partition5 Ready SYS6R Partition6 Ready SYS7R Partition7 Ready SYS8R Partition8 Ready Partition Keypad HIKVISION System Fault...
  • Page 87 Control Panel User Manual Keypad Standby Status Display Demonstration The standby status display demonstration is shown below. SYS1D SYS2R SYS3A SYS4R SYS5R SYS6R SYS7R SYS8R V1.2.1 build 131211 2014.04.18 19:24:26 The LCD keypad displays the version of the control panel and the time of operation.
  • Page 88 Control Panel User Manual SYS1D SYS2R SYS3A SYS4R SYS5R SYS6R SYS7R SYS8R Partition Keypad The system exception display of the partition keypad includes interfaces of alarm, fault and bypass.  Zone Alarm Zone Alarm 001 002 003 004 005 006 ...
  • Page 89 Control Panel User Manual Display Demonstration in Project Mode The demonstration is shown below. Network1: Connecting… Network1: Connected Network1: Sending Report… Network1: Sending report succeeded.

  • Page 90: Chapter 4 Accessing By Client Software

    Control Panel User Manual Chapter 4 Accessing by Client Software Check the package contents and make sure that the device in the package is in good condition and all the assembly parts are included. 4.1 Installing the iVMS-4200 Insert the installation media of iVMS-4200 into the appropriate computer. Perform the following steps to install the iVMS-4200 client software.
  • Page 91 Control Panel User Manual If you accept the terms of the license agreement, click I accept the terms of license agreement. Click Next to continue. Otherwise click I do not accept the terms of the license agreement, and then click Cancel to cancel the installation On the next panel , you are prompted to select the function module to install.
  • Page 92 Control Panel User Manual Click Next to continue. Install the WinpCap plug-in according to the prompts to detect the online devices when running the client software. Read the pre-install information and click Install to begin the installation. A panel indicating progress of the installation is displayed. A percentage completion bar is updated as the installation progresses.
  • Page 93 Control Panel User Manual Select the setup type according to your need. You can check the checkbox of Create Desktop for Client to create a shortcut icon on the desktop for the client software. Read the post-install information and click Finish.

  • Page 94: User Registration And Login

    Control Panel User Manual 4.2 User Registration and Login For the first time to use iVMS-4200 software, you need to register a super user for login. Steps: 1. Input the super user name and password. 2. Confirm the password. 3. Optionally, check the checkbox of Enable Auto-login to log in the software automatically. 4.

  • Page 95: Network Security Control Panel Settings

    Control Panel User Manual When opening iVMS-4200 after registration, you can log in the software with the registered user name and password. Steps: 1. Input the user name and password you registered. 2. Optionally, check the checkbox of Enable Auto-login to log in the software automatically. 3.

  • Page 96: Remote Configuration

    Control Panel User Manual address and port number. Steps: 1. On the Device Management interface, click and select a control panel in the device list. 2. Click on the Modify button on the upper side of the list to enter the device modify interface.

  • Page 97: System Information Configuration

    Control Panel User Manual System Information Configuration 4.4.2 Purpose: In this section, you can configure the system parameters (such as time, log, user, security, system maintenance and so on) for the device.
  • Page 98 Control Panel User Manual Timing Configuration Before You Start: Before you start configuring the security control panel, you need to do timing for the device first. Enter Remote Configuration>System->Time to get the configuration page. Click the Synchronization button to complete the settings.
  • Page 99 Control Panel User Manual User Configuration Purpose: You can add, edit, or delete the network operator and keypad operator in this section.  Network User Add a Network User Steps: 1. Enter the user configuration interface. Remote Configuration->System->User...
  • Page 100 Control Panel User Manual 2. Click to enter the interface of adding a network user.
  • Page 101 Control Panel User Manual 3. Enter the corresponding user information including the user type, user name, password, IP address, and MAC address. 4. Select the permission of the user. 5. Click OK to finish the settings. Edit a User Steps: 1.
  • Page 102 Control Panel User Manual 2. Edit the corresponding user information including the user type, user name, password, IP address, and MAC address 3. Edit the permission of the user. 4. Click OK to finish the settings. Delete a user Steps: 1.

  • Page 103: Network Configuration

    Control Panel User Manual Steps: 1. Select the user type. Operator and installer can be selected. 2. Select the index number of the keypad user, up to 16 numbers can be selected. 3. Enter the name of the keypad operator. 4.
  • Page 104 Control Panel User Manual 2. Configure the NIC settings, including the IPv4(IPv6) Address, IPv4(IPv6) Subnet Mask and IPv4(IPv6) Default Gateway. 3. Click Apply to save the above settings.  The valid value range of Maximum Transmission Unit (MTU) is 500 ~ 9676. The default value is 1500.
  • Page 105 Control Panel User Manual Before you start: Registration on the DDNS server is required before configuring the DDNS settings of the control panel. Steps: 1. Enter the DDNS Settings interface: Remote Configuration> Network > DDNS 2. Check the Enable DDNS checkbox to enable this feature. 3.
  • Page 106 Control Panel User Manual Uploading Mode Configuration Purpose: You can select to send Zone report, alarm report and configure the uploading mode of the selected center group in this section. Steps: 1. Enter the uploading mode configuration page. Remote Configuration->Uploading Mode Settings 2.
  • Page 107 Control Panel User Manual 6. Click each dropdown menu to configure the uploading channel. 7. Click Apply to save the settings. The alarm channel of each center group should be configured in order. Network Center Configuration Purpose: In this section, you can configure the parameters(such as server type, IP address, port No.,and so on)of the network center.
  • Page 108 Control Panel User Manual receiving center. 5. Enter the port No. for communicating with the alarm-receiving center. 6. Click the dropdown menu to select the protocol type. 7. Enter the username that is applying for displaying in the alarm-receiving center. The length of the username should be 6 characters.
  • Page 109 Control Panel User Manual 2. Check the checkbox to enable report uploading. 3. Enter the report-uploading period (unit: hour). The report-uploading period represents the time interval between uploading the first report and the next report. 4. Enter the first report uploading time interval (unit: minute). The first report uploading time interval represents the time interval between enabling the report uploading function and sending the first report.
  • Page 110 Control Panel User Manual 2. Click the dropdown menu to select the net center. 3. Enter the device ID which is applying for displaying in the alarm receiving center.  The length of the username should be 6 characters.  Only numeric (0~9), and letter (A~F&a~f) are valid for this username. 4.
  • Page 111 Control Panel User Manual 2. Enter the corresponding DNS sever address. 3. Enter the IP address and port No. of the control panel. 4. Click Apply to save the settings. Whitelist Configuration Purpose: The whitelist is the list of phone numbers which are authorized to interact with the control panel.

  • Page 112: Alarm Configuration

    Control Panel User Manual 2. Select the index of the whitelist. 3. Check the Enable checkbox to enable the configuration. 4. Enter the phone number of the whitelist into the SIM Card Number text box. 5. Select the identical message time interval that represents the interval of sending message triggered by the same event.
  • Page 113 Control Panel User Manual Steps: 1. Enter the partition alarm triggering configuration interface. Remote Configuration->Alarm->Partition 2. Click the partition dropdown menu to select a partition. 3. Click the Linkage button to add required Zone, keypad, or keypad user to the partition.
  • Page 114 Control Panel User Manual 8. Select an alarm type.  Hostage Report: Enable uploading the hijack report of control panel.  Arming/Disarming Report Uploading Sound: Enable the prompt sound when uploading the arming/disarming report.  Alarm Sound Uploading Manual Test: Enable the prompt sound when successfully uploading the manual test report.
  • Page 115 Control Panel User Manual 2. Click the Partition dropdown menu to select a partition. 3. In the Alarm Input list, select an alarm input channel and click the icon enter Zone configuration page.
  • Page 116 Control Panel User Manual 4. Edit the general information of the Zone, including name, probe type, arming Zone type, sensitivity, entering delay, and existing delay and so on. Probe Type: Select the type of the detector. Arming Zone Type: Select the type of Zone in the partition Sensitivity: Select the response time of the Zone.
  • Page 117 Control Panel User Manual 2. In the Alarm Output list, select an alarm input channel and double click the trigger to enter zone configuration page.
  • Page 118 Control Panel User Manual 3. Edit the general information of the zone, including name, output delay and so Output Delay (0~5999s): Configure the alarm output time after the alarm being triggered. 4. Click the dropdown menu to enable/disable the event-linked trigger. 5.
  • Page 119 Control Panel User Manual 2. Click the Siren dropdown menu to select a siren needs to be configured. 3. Check the Enable box to enable the configuration. 4. Edit the siren name. 5. Select the detailed operation after the alarm being triggered on the partition event panel.
  • Page 120 Control Panel User Manual 2. In the relay list, select an alarm input channel and click the icon to enter the Zone configuration page.
  • Page 121 Control Panel User Manual 3. Check the Enable checkbox to enable the configuration. 4. Click the icon , click and drag the mouse on the time bar (the time bar is divided into 24 segments which represent 24 hours) to draw the required schedule.
  • Page 122 Control Panel User Manual 2. Select a partition needs to be configured. 3. Check the Enable Normal Schedule checkbox to enable daily schedule for the partition. You can select to enable the mandatory arming function. 4. Click the icon of the Template box to enter the schedule configuration interface.
  • Page 123 Control Panel User Manual Copy Schedule: Click the drawn color bar and click the icon to copy this arming schedule to other day of the week. 9. Click Save to save the settings and click Cancel to exit the page. 10.
  • Page 124 Control Panel User Manual 4. Click the button to select an arming type. 5. Click and drag the mouse on the time bar to draw the daily schedule. 6. Click Save to save the settings and click Cancel to exit the page. 7.
  • Page 125 Control Panel User Manual 2. Click and select the external device from the module type dropdown menu. 3. View the information about the selected device. Zone Tampering-proof Configuration Steps: 1. Enter the Zone tampering configuration interface. Remote Configuration->Alarm->Zone Tampering Proof...
  • Page 126 Control Panel User Manual 2. Click dropdown menu to select a Zone needs to be configured. 3. Select a tampering type. 4. Check the Upload Alarm Recovery Report checkbox to enable the function of uploading alarm recovery report. 5. Select the linked siren on the Linked Siren panel. 6.

  • Page 127: Fault Handling

    Control Panel User Manual 2. Click the icon to enter the remote control permission configuration page. 3. Check the Enable checkbox to enable the configuration 4. Enter the serial number of the remote control. 5. Select the partition No. needs to be controlled. 6.

  • Page 128: Operation

    Control Panel User Manual Steps: 1. Enter the fault handling interface. Remote Configuration->Others->Fault Handling 2. Select the fault detection type. 3. Click the Source of Fault dropdown menu to select the linked keypad. 4. Select the alarm output mode and corresponded fault detection type. The alarm output mode can be selected as Linked Indicative Light and Linked Keypad Sound.

  • Page 129: Status

    Control Panel User Manual Partition: you can arm/disarm the partition, clear alarm, bypass, and recover bypass of the system. Zone: you can bypass or recover bypass of the selected zone. Tigger: you can select to turn on/off the selected trigger. Siren: you can enable/disable the specified siren.
  • Page 130 Control Panel User Manual...

  • Page 131: Chapter 5 Trouble Shooting

    Control Panel User Manual Chapter 5 Trouble Shooting Q: What is the function of Project button of LCD keypad? A: Project button has button switch function besides normal instruction button, such as: When sensor or module is abnormal, press and hold the Project button to switch to other interfaces manually.
  • Page 132 Control Panel User Manual A: LCD system keypad indicator: The meaning of Arm/Disarm indicator (Red and Green) is shown below: Working Status Indicator Status Working Status Indicator Status Enter Green, Blink Parameters Green, Blink programming Initialization System Arming Red, Normally On System Disarming Green, Normally The meaning of Operate indicator (Green) is shown below:...
  • Page 133 Control Panel User Manual parameters needed, you can operate according to program command once again. 4. Exit program mode, the program command is: {*} + {#}. Q: What is the meaning of LED keypad Arm/Disarm, Operate, Camera indicators? LED alarm keypad Arm/Disarm indicator: Working Status Indicator Status Working Status...
  • Page 134 Control Panel User Manual Disconnection Receive the Hand-shack Alarm Connector On-hook Sound LED keypad Camera indicator under Status Mode: Description Description AC Power off Keypad Off-line Battery Low Voltage Network Cable Off-line Control Panel Tamper-proof No SIM Card ADSL Cable Off-line Reserved Q: What is the meaning of LED keypad alert sound? A: The meaning of LED keypad alert sound is as follows:...
  • Page 135 Control Panel User Manual 1) Under disarming mode: Press {*} + {1} + {#} or {Password} + {*} + {1} + {#}. 2) Under arming mode: Press {Password} + {*} + {1} + {#}. Q: How to input hexadecimal number? A: Input hexadecimal number with {*} button and number button {0} ~ {5}.
  • Page 136 Control Panel User Manual Q: Why is it needed to input E at the end of keypad configured phone number? A: Control panel can process phone number with 31 characters. Input number with 16 characters in each command address so that 2 addresses are needed for storage phone number.
  • Page 137 Control Panel User Manual Command Address 460 0 5 7 1 8 8 0 7 5 9 9 8 E For example: The first alarm connecter phone number is 17951-88075998, user can input the following command: Command Address 460 1 7 9 5 1 F F F 8 8 0 7 5 9 9 8 Command Address 461 For example: The first alarm connecter phone number is 0571-88075998-8888, user can input the following command:...
  • Page 138 Control Panel User Manual For example: Valid Password: 1239, Duress Code: 1230 and 1238. 3. Please take the following notes while using duress code: While using duress code, it is needed to enable duress report firstly, as to program the control panel age report and delay. The programming command to enable Control Panel Hijack Report is as follow: Command Address {4}{6}{4}...
  • Page 139 Control Panel User Manual + {*} + {8} + {9} + {#}. This method is not recommended because it will initialize all programming contents. Q: How to do the hardware initialization? A: Control panel hardware initialization only initializes operator password: 012345 and main operator password: 1234, main operator permission is arm/disarm.
  • Page 140 Control Panel User Manual A： 1) Please check if the network status indicator of the board is normal on; 2) If the network status indicator is not normal on, please check if the network cable connection is normal. Q: What if the client cannot log in the device? A: Troubleshoot according to the prompt.
  • Page 141 Control Panel User Manual 1. Center uploading mode supports at most 6 center groups, each center group divides in main channel and 3 backup channels; 2. If the center group is enabled. Enable the center group before the use. 3. For example: The control panel needs to upload report to network alarm center 1 and dialing alarm center1 and network alarm center 1 needs to upload report to network alarm center 2 when it fails to upload it.

  • Page 142: Appendix1：Specifications

    Control Panel User Manual Appendix1：Specifications Model DS-19A08-F/Kx DS-19A08-F/KxG Alarm Input 8 Zones Alarm Input Alarm Output Local 1-ch+8-ch expandable, 1A/30VDC Siren Power Supply DC12V/300mA Telephone Line 1-ch PSTN Keypad K1: LED Keypad; K2: LCD Keypad Supported Keypads (LCD/LED) Security Support Tamper-proof and Movement Prevention...

  • Page 143: Appendix2：Cid Report

    Control Panel User Manual Appendix2：CID Report Description Description Code Code 1103 Real-time Zone 3103 Real-time Zone Alarm Alarm Recovery 1110 Fire Zone Alarm 3110 Fire Zone Alarm Recovery 1122 24-hour Non-voiced 3122 24-hour Non-voiced Zone Zone Alarm Alarm Recovery 1123 24-hour Voiced 3123 24-hour Voiced Zone...
  • Page 144 Control Panel User Manual Description Description Code Code Zone Fault Recovery 1401 Disarming 3401 Arming 1406 Alarm Clearing 1810 Soft Zone Emergency Memory Canceling Alarm 1570 Zone Bypass 3570 Zone Bypass Recovery 1574 Group Bypass 3574 Group Bypass Recovery 1601 Manual Testing 1602 Regular Testing Report...
  • Page 145 Control Panel User Manual Description Description Code Code Enabling Disabling 1943 Unmatched Input/ 3943 Input/ Output Format Output Format Recovery 1944 Video Input 3944 Video Input Recovery Exception 1945 3945 HDD Recovery (For HDD HDD Full Alarm Full) 1946 3946 HDD Recovery (For HDD HDD Fault Alarm Fault)

  • Page 146: Appendix3：Led Keypad Prompt Sound

    Control Panel User Manual Appendix3：LED Keypad Prompt Sound Keypad Prompt Description Sound 1 Sound Keypad Prompt, Error Operating Prompt 2 Sound Correctly answered, report uploading succeeded 5 Sound Incorrectly answered, report uploading failed in 60s Last for 2s Error Prompt Intermittent Slow Enter/Exit Delay Sound, Continuously...
  • Page 147 Control Panel User Manual Control Panel Command Table Installer Password 1#Password 2#Password User Name: User Name： 3#Password 4#Password User Name： User Name： 6#PasswordPa 5#Password ssword User Name： User Name： 7#Password 8#Password User Name： User Name： 9#Password 10#Password User Name： User Name： 11#Password 12#Password User Name：...
  • Page 148 Control Panel User Manual 51#Password 52#Password User Name： User Name： 53#Password 54#Password User Name： User Name： 55#Password 56#Password User Name： User Name： 57#Password 58#Password User Name： User Name： 59#Password 60#Password User Name： User Name： 61#Password 62#Password User Name： User Name： 63#Password 64#Password User Name：...
  • Page 149 Control Panel User Manual 101#Password 102#Password User Name： User Name： 103#Password 104#Password User Name： User Name： 105#Password 106#Password User Name： User Name： 107#Password 108#Password User Name： User Name： 109#Password 110#Password User Name： User Name： 111#Password 112#Password User Name： User Name： 113#Password 114#Password User Name：...
  • Page 150 Control Panel User Manual 151#Password 152#Password User Name： User Name： 153#Password 154#Password User Name： User Name： 155#Password 156#Password User Name： User Name： 157#Password 158#Password User Name： User Name： 159#Password 160#Password User Name： User Name： 161#Password 162#Password User Name： User Name： 163#Password 164#Password User Name：...
  • Page 151 Control Panel User Manual Region1 Region2 Parameters Parameters Configuration Configuration Region3 Region4 Parameters Parameters Configuration Configuration Region5 Region6 Parameters Parameters Configuration Configuration Region7 Region8 Parameters Parameters Configuration Configuration Region9 Region10 Parameters Parameters Configuration Configuration Region11 Region12 Parameters Parameters Configuration Configuration Region13 Region14 Parameters...
  • Page 152 Control Panel User Manual Region Linked Trigger Configuration Enable Trigger Event Linkage Configuration Disable Trigger Event Linkage Configuration Trigger Time Settings Siren Settings Host Time Settings Host IP Address Settings Host Port Number Settings Subnet Mask Settings Gateway Settings Network Center 1 IP Configuration Programming Address Network Center 1 Port...
  • Page 153 Control Panel User Manual Wireless Center 1 IP Configuration Programming Address Wireless Center 1 Port Configuration Programming Address Wireless Center 1 Protocol and Account Configuration Programming Address Wireless Center 2 IP Configuration Programming Address Wireless Center 2 Port Configuration Programming Address Wireless Center 2 Protocol and Account Configuration...
  • Page 154 Control Panel User Manual System Time and Hostage Report Configuration System Report and Arming/Disarming Prompt Configuration System Key User Permission Configuration Host System Fault Detection Configuration System Fault Display Configuration System Keyboard Fault Prompt Sound Configuration Center Group 1 Enabling Configuration Center Group 1 Uploading Mode Configuration Center Group 1 Region...
  • Page 155 Control Panel User Manual Center Group 3 Enabling Configuration Center Group 3 Uploading Mode Configuration Center Group 3 Region Alarm Report Configuration Center Group 3 Non-region Alarm Report Configuration Center Group 4 Enabling Configuration Center Group 4 Uploading Mode Configuration Center Group 4 Region Alarm Report Configuration...
  • Page 156 Control Panel User Manual...
  • Page 157 First Choice for Security Professionals...

This manual is also suitable for:

Ds-19a08-f/kxg

Table of Contents
