Danfoss Air Installation Manual page 11

C
5.0 Unit dimensions
- a unit
2
Right view
580
15
Discharge air
5.0 Unit dimensions
- a unit
3
780
15
Outdoor air
Discharge air
5.0 A-units in detail
(front panel removed)
Unit installation
325
Exhaust air
Outdoor air
Supply air
540
330
Filter, exhaust air
Diff. pressure
exhaust air
Flow chart
(for balancing)
Diff. pressure
supply air
VIEWA102
Front view
1180
Weight of unit: 52 kg
Exhaust air
Supply air
Weight of unit: 66 kg
Front view (without front panel)
Filter reset button
Diff. pressure
supply air
Diff. pressure
exhaust air
Outdoor air
Discharge air
1180
Outdoor air
Discharge air
Filter, supply air
11
