ILLUSTRATED PARTS LIST
ALPHA FRESHTRAC - Main Chassis - Parts List
ITEM # PART # DESCRIPTION
a
1A WC-4213-P NUT, 5/8 LOCK PLATED
b
1B WC-4212-02 NUT, 5/8-18 JAM PLASTIC
VALVE, DUMP LEFT 120V 12W ALPHA'S/D1000/
2 WC-889
GEM-12/TLP
3 WC-3518 LEG, GLIDE 3/8"-16 STUD SCREW
a
4A WC-2962K KIT, FITTING SPRAYHEAD SS
b
4B WC-2962-101K KIT, FITTING SPRAYHEAD KYNAR
5 WC-1806 SEAT CUP, SILICONE USE ON WC-1809 FAUCET
KIT, VALVE REPAIR FOR DELTROL WC-
6 WC-37132-101
820WDR,WC-821WDR, WC-844WDR
CONTROL MODULE, UCM 120V ALPGT/D500GT/
7 WC-774
D60GT
LABEL, UCM OVERLAY ALPHA-3GT L/R CURTIS
8 WC-39345
LOGO
9 WC-29025 SPRAYHEAD, PURPLE ADVANCE FLOW
HEATSINK, ASSY DV ALPDS/D500AP TCTD/
10 WC-8556
PTTD
BREW CONE, W/HANDLE ASSY 7.1"D.W/WC-
11 WC-3316
3317 & WC-3323 ALP/AP
12 WC-5970 COVER, BACK CTR WRAP ALPGT
13 WC-2401-P ELBOW 3/8 NPT X 1/4 FLARE
14 WC-1412 CORD GRIP, 3/4" FOR METAL CORD TO .81"OD
WC-1200 2
15 CORD, 14/3 SJTO 6' BLK W/PLUG
HARNESS COMPLETE ALPHAGTN-15
WC-13315-101 1
16A
(INCLUDES POWER BLOCK)
HARNESS ASSY, CONTROL 120/220V W/POWER
WC-13315 2
16B BLOCK ALPHA-GT/GS (INCLUDES POWER
BLOCK)
1 ALP3GT15, 2 ALP3GT63,
a
b Older units.
ALPHA FRESHTRAC - Recommended Parts to Stock
ITEM # PART # DESCRIPTION
VALVE, DUMP LEFT 120V 12W ALPHA'S/D1000/
2 WC-889
GEM-12/TLP
KIT, VALVE REPAIR FOR DELTROL WC-
6 WC-37132-101
820WDR,WC-821WDR, WC-844WDR
CONTROL MODULE, UCM 120V ALPGT/D500GT/
7 WC-774
D60GT
9 WC-29025 SPRAYHEAD, PURPLE ADVANCE FLOW
18 WC-314 POWER BLOCK, 5 STATION
ALPHA FRESHTRAC, ILLUSTRATED PARTS/RECOMMENDED PARTS
ITEM # PART # DESCRIPTION
17 WC-29044-101 SLEEVE, OVERFLOW
18 WC-314 POWER BLOCK, 5 STATION
19 WC-826L VALVE, INLET 1 GPM 120V 9W
20 WC-5310 TUBE, 5/16 ID x 1/8W SILICONE GEN USE
21 WC-5231 COMPOUND, HEAT SINK 5OZ
SWITCH, TOGGLE NON-LIT DPST 25A
22 WC-103
125/250VAC RESISTIVE
23 WC-6812 WARMER, TOP ASSY 120V
24 WC-3503 LEG, 3/8"-16 STUD SCREW BUMPER
KIT, HOT WATER FAUCET REPLACEMENT
25 WC-37252
ALPGT/D60GT/D500GT
26 WC-972 WARMER, ASSY COMPLETE 100W 120V
TRANSMITTER ASSEMBLY, D-STYLE FRESH-
27 WC-10002D
TRAC
RECEIVER ASSEMBLY 1 LED FRESH TRAC
28 WC-10003
CURTIS DECANTER
HARNESS ASSY, WARMER ALPHA GT FOR
29 WC-13164
UPPER WARMER
30A 70580000303 CURTIS FRESH-TRAC BLK/WHT 3PK
30B 70580200403 DECAF FRESH-TRAC ORG/ORG 3PACK
O'RING, 0.487I.D.x 0.693OD x0.103CS BUNA-N
a
31A WC-4320
#112
GASKET, 1.00OD X .625 I.D. X .030 THK WHITE
b
31B WC-43089
EPDM 70 SHORE
ITEM # PART # DESCRIPTION
19 WC-826L VALVE, INLET 1 GPM 120V 9W
20 WC-5310 TUBE, 5/16 ID x 1/8W SILICONE GEN USE
21 WC-5231 COMPOUND, HEAT SINK 5OZ
SWITCH, TOGGLE NON-LIT DPST 25A
22 WC-103
125/250VAC RESISTIVE
