3.1 BOOSTXL-SENSORS_SensorGUI_MSP432P401R
This section describes the functionality and structure of the BOOSTXL-
SENSORS_SensorGUI_MSP432P401R demo that is included in the
Examples, or more easily accessible through the SimpleLink MSP432™ SDK (see
3.1.1 Source File Structure
The project is split into multiple files (see
for other projects.
Name
msp432_startup_ccs.c
Library: driverlib
src/bme280.c
src/bme280_support.c
src/bmi160.c
src/bmi160_support.c
src/demo_sysctl.c
src/i2c_driver.c
src/main.c
src/opt3001.c
src/tmp007.c
src/uart_driver.c
3.1.2 Working With the GUI
The Sensor GUI allows for quick visualizations of the sensors data and testing of applications.
3.1.2.1 Getting Started
1. Download the BOOSTXL-SENSORS_GUI+ET zip
2. Launch BOOSTXL-SENSORS_GUI+ET.
3. Plug your MSP432P401R LaunchPad development kit with Sensors BoosterPack plug-in module into a
USB port. And click the
• If needed, go to "Options" and select the proper COM Port for the Application UART and the baud
rate as 115200 (see
NOTE: For Windows, you can find the port number by opening Device Manager and looking for
"XDS110 Class Application/User UART" under "Ports (COM & LPT)". It will be listed as
COMnn, where nn is the number of the port.
SLAU666B – June 2016 – Revised May 2018
Submit Documentation Feedback
Table 10). This makes it easier to navigate and reuse parts of it
Table 10. Source File and Folders
SimpleLink MSP432 MCU family interrupt vector table for CGT
Device driver library (MSP432DRIVERLIB)
Driver for communicating with the environmental sensor
Support driver for communicating with the environmental sensor
Driver for communicating with the IMU and magnetometer sensors
Support driver for communicating with the IMU and magnetometer sensors
Delay function for MSP432 MCU
2
Driver for I C communication with the sensors
The main function of the demo, interrupt service routines, global variables, and more
Driver for communicating with the ambient light sensor
Driver for communicating with the infrared temperature sensor
Driver for UART communication with the PC GUI
icon in the lower left corner of the GUI.
Figure 4).
BOOSTXL-SENSORS Sensors BoosterPack Plug-in Module
Copyright © 2016–2018, Texas Instruments Incorporated
MSP-EXP432P401R Software
Description
file, and extract its contents.
Software Examples
Section 4.6).
