Specifications - Lectrosonics QUADUHFD Operating Instructions And Troubleshooting Manual

RF/POWER DISTRIBUTION MODULE
RF Gain:
RF Output:
Filtering:
Third Order Intercept:
Power Input:
Power Consumption:
Connectors:
Short Circuit Protection:
MECHANICAL ASSEMBLY
Construction:
Dimensions:
Weight:
Batteries:
Operating Time per Charge:
This product meets the CE Compliance Standards - EN55022 and
EN50082-1:1998. A copy of the Declaration of Conformity may be
requested from your dealer or by contacting the factory directly:
Lectrosonics, Inc.
Marketing Department
581 Laser Rd. NE, Rio Rancho, NM 87124 USA
tel: 505-892-4501 fax: 505-892-6243 e-mail: marketing@lectrosonics.com
8

SPECIFICATIONS

0 to +1 dB
Four outputs, 50 Ohm, BNC
Ceramic resonators - 50MHz bandwidth
+27 dBm
• 9 to 16 V DC
Pins 1 (gnd) and 4 (+) on XLR power jack
• CH-80 adapter for AC operation, 15V @ 2.8 A
Pins 2 (gnd) and 3 (+) on XLR power jack
200 mA at 14V (distribution modules only)
Total draw is dependent on the receiver types involved and
can be as high as two amps total.
• RF: BNC
• POWER INPUT: 4 pin XLR (Switchcraft D4M)
• POWER OUTPUT: 2.1mm power jack
Auto-reset thermal fuses (6), 750mA to receivers, 5A to/from
battery and external DC supply.
Machined aluminum panels, housings, and mechanical parts.
6.75H x 10.75W x 8.5D inches (in carrying case)
22.25lbs. with 4 UCR205D receivers loaded
Two 6V, 12 Ah rechargeable gel-cells
Dependent on receivers installed,
8-9 hours with UDR205D's or UCR300's
5-6 hours with UCR200's
14-16 hours with UCR210's
12-14 hours with UCR195D/UCR195
Specifications subject to change without notice.
