8.5 Voltage sensing connectors
OMZB1_ OTM160-250E_C_, OTM200U_C_
OMZB2_ OTM315-400E_C_, OTM400U_C_
1
OMZB3_
1
b
OTM1000-2500E_C_
OMZB4_
OTM800U_C_
OTM3200E_C_
1
Figure 8.12
Mounting of the voltage sensing connectors, type OMZB_
38 l 1SCC303002M0206 l ABB Installation and operating instructions, 34OTM_C rev. F
