8.3 Terminal shrouds

G
OTS250 1S
T
G
OTS400 1S
T
G
OTS800 1S
T
1
2
G
OTS250 1L
T
G
OTS400 1L
T
G
OTS800 1L
T
1
2
Figure 8.6 Mounting of the terminal shrouds (type OTS_ ) to the motorized change-over switches
OTM160-800E_C_
1SCC303002M0206 l ABB Installation and operating instructions, 34OTM_C rev. F l 33
OTM160-250_C_
OTM315-400_C_
OTM600-800_C_
G
OTS_ 1S
T
4
M
OTS250_ M8 15...22Nm 5/6DIA IN. 133-195LB.IN.
OTS400_ M10 30...44Nm 266-390LB.IN.
OTS800_ M12 50...75Nm 433-664LB.IN.
G
OTS_ 1L
T
3
8. Accessories
