4. Installation
4.4 Mounting positions
The recommended mounting positions for motorized change-over switches are horizontal, wall
mounted or table mounted.
Figure 4.18
Mounting positions
Do not install the motorized change-over switches in any other position than those
described above.
4.5 Labelling
M
M
M
M
M an .
M an .
M an .
Figure 4.19
Labelling of the motorized change-over switches
18 l 1SCC303002M0206 l ABB Installation and operating instructions, 34OTM_C rev. F
