  • Page 1 Product Information Bulletin C79000-Z7076-C814-02...
  • Page 2 Trademarks SIMATIC , SIMATIC NET and SIMATIC HMI are registered trademarks of SIEMENS AG. The reproduction, transmission or use of this document or its contents is We have checked the contents of this manual for agreement with the not permitted without express written authority.

  • Page 3: Table Of Contents

    Contents Safety Instructions ........... . . General Notes .
  • Page 4 Contents Error Diagnostics ............The PC Does not React to the ON/OFF Switch .

  • Page 5: Safety Instructions

    Safety Instructions Chapter This chapter provides you with mandatory safety instructions which you must Overview follow when you operate your PC and its components. This device corresponds to the relevant safety measures according to IEC, EN, VDE, UL, and CSA. If you have questions about the permissibility of the installation in the designated environment, please contact our service representative.

  • Page 6: General Notes

    Safety Instructions General Notes Transport We recommend that you transport the device only in the original packaging (protection against shock and impact). Installation Condensation can occur if the device is transported from a cold environment into the operating area. The device must be dry prior to startup. You must allow for an acclimatization time of at least two hours.
  • Page 7 Safety Instructions Repairs Only authorized personnel are permitted to repair the device. Unauthorized opening and improper repairs on the device can result in significant danger to the user. Before you open the device, first switch it off and then disconnect the power plug.

  • Page 8: Notes On The Ce Symbol

    EN 60950. Declaration of The EU declarations of conformity and the relevant documentation are held Conformity at the disposal of the competent authorities at the address below: Siemens Aktiengesellschaft Bereich Automatisierungs- und Antriebstechnik A&D AS E 4 Postfach 1963 D-92209 Amberg...

  • Page 9: Approvals For The Usa And Canada (Ri45 Pii)

    Safety Instructions ISO 9001 The quality assurance system for the whole product process (development, Certificate production, and marketing) fulfils the requirements of ISO 9001 (corresponds to EN29001: 1987). This has been certified by the German society for the certification of quality management systems (DQS).

  • Page 10: Fcc Approval For Usa And Canada (Ri45 Pii)

    Safety Instructions 1.3.1 FCC Approval for USA and Canada (RI45 PII) Federal Communications Commission Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 11: Unpacking And Installing The Ri45 Pii

    Unpacking and Installing the RI45 PII Chapter Overview This chapter describes how to install the RI45 PII and contains all the information you need to know about its most important components: Device models Installing and transporting Hardware components/interfaces Keyboard Installing your PC in a 19” cabinet or rack (RI45 PII 19” operation) Drives.

  • Page 12: Device Models

    Unpacking and Installing the RI45 PII Device Models The SIMATIC PC RI45 PII is available in the following three models: Rack This model is designed to be installed in a 19” cabinet or mounting rack; it is equipped with a module retainer and an air filter. Tower This model is designed for office use;...

  • Page 13: Installing And Transporting The Ri45 Pii

    Unpacking and Installing the RI45 PII Installing and Transporting the RI45 PII Unpacking the Unpack your RI45 PII as follows: RI45 PII 1. Remove the packing. 2. Do not throw the original packing away. Keep it in case you have to transport the unit again sometime in the future.

  • Page 14: Hardware Components Of The Ri45 Pii

    Unpacking and Installing the RI45 PII Hardware components of the RI45 PII Front All important operator controls and displays are located behind the drive cover on the front of the unit. Tower Rack PC RI45 PII PC RI45 PII 1 LED displays Power Power LED Hard disk access...
  • Page 15 Unpacking and Installing the RI45 PII Rear Panel All the power supply connectors and interface ports for connecting to (Connectors) external devices are located on the rear panel of the RI45 PII. Supply voltage selector switch On/Off switch Power supply Power supply connector connector...
  • Page 16 Unpacking and Installing the RI45 PII Ports and Connectors Function Power supply connector Input Connection for power supply (120/240V AC) Power supply connector Output Connection for external monitor (120/240V AC) PS/2 keyboard Connection for keyboard (trackball supported) PS/2 mouse Connection for PS/2 mouse LPT 1 printer Connection for printer with parallel Parallel interface...

  • Page 17: Installing Your Pc In A 19" Cabinet Or Rack (Ri45 Pii 19" Operation)

    (without rack slide rails). Use the respective manufacturer ’s cabinet or rack slide rails or L-sections. Contact your cabinet supplier directly regarding cabinet or rack installation. (18,31) SIEMENS (19,02) (17,64) Figure 2-4 SIMATIC PC RI45 PII Installation Dimensions Warning Avoid extreme ambient conditions as far as possible.

  • Page 18: Drives

    Unpacking and Installing the RI45 PII Drives Disk Drive Cover The disk drives of your RI45 PII are protected against dirt penetration by a sliding cover. PC RI45 PII PC RI45 PII 1 Lock for disk drive cover 2 Disk drive cover Figure 2-5 Disk Drive Cover Open the disk drive cover to gain access to the drives and the power switch.
  • Page 19 Unpacking and Installing the RI45 PII Handling Diskettes The diskette is inserted in the disk drive as shown below: 1 Access LED 2 Ejector Caution Risk of data loss! You must not remove the diskette while the access LED is lit. Otherwise you might lose the data on the diskette.
  • Page 20 Unpacking and Installing the RI45 PII CD Tray This tray prevents dust from getting inside the CD-ROM reader and should re- main closed. If your RI is not switched on you can manually push the tray and close the door of your CD-ROM drive. Emergency Use a paper clip or any other device to open the CD-ROM tray if the electrical Eject Hole...

  • Page 21: Setting Up And Operating The Ri45 Pii

    Setting Up and Operating the RI45 PII Chapter Overview This chapter describes all the actions that you must perform in order to set up your workplace successfully: Connecting the RI45 PII to the power supply Connecting I/O devices Information about the keyboard Using the electronic documentation Backing up hard disk data on diskettes.

  • Page 22: Connecting The Ri45 Pii To The Power Supply

    Setting Up and Operating the RI45 PII Connecting the RI45 PII to the Power Supply Connecting to the The RI45 PII can be operated at 120 V or 240 V. Voltage selection is carried Power Supply out via the supply voltage selector. Caution Risk of damage to the unit! Operating the RI45 PII with the incorrect supply voltage can damage the...
  • Page 23 Setting Up and Operating the RI45 PII Country-Specific Notes The power plug must be disconnected to isolate the unit completely from the supply. For operation in Canada and the USA, a CSA or UL-listed power supply cable must be used. For the United States and Canada: In the United States and Canada the cord must be UL-listed and CSA-labeled.

  • Page 24: Connecting I/O Devices

    Setting Up and Operating the RI45 PII Connecting I/O Devices Connecting a PS/2 Connect the keyboard as follows: Keyboard 1. Switch off your device. 2. Plug in the PS/2 keyboard connector. 3. On the RI45 PII rack you can secure the cable using the strain relief device.
  • Page 25 If the frequency is too high, this may damage the monitor. Recommended Siemens printers with a parallel interface and IBM character set are Printers recommended for use with the RI45 PII.

  • Page 26: Keyboard

    Setting Up and Operating the RI45 PII Caution Risk of damage to the unit! Switch off the unit before connecting the parallel printer to the LPT 1 port (the printer should also be switched off). Make sure that you use the right port, otherwise you may damage the printer or the RI.

  • Page 27: Starting Up Your Pc For The First Time

    Setting Up and Operating the RI45 PII Starting Up Your PC for the First Time Switching On Your PC is ready for system operation after you connect the I/O devices and the system unit. You can now switch the PC to the standby mode with the power switch located at the power supply.

  • Page 28: Electronic Manual

    Setting Up and Operating the RI45 PII Electronic Manual Overview Your PC is equipped with an electronic manual. This manual consists of two parts: – The Product Information Bulletin (the document you are reading now) in five languages (German, English, French, Italian and Spanish) and –...

  • Page 29: Installing Adobe Acrobat

    Setting Up and Operating the RI45 PII Installing Adobe Acrobat Installing the Before you install the Acrobat Reader, we recommend that you connect a Acrobat Reader mouse and install the mouse driver. To ensure that the mouse is installed correctly during startup, you must connect it while the PC is switched off. It is possible to operate the Acrobat Reader with the keyboard, but it is considerably easier to use the mouse.
  • Page 30 Setting Up and Operating the RI45 PII Product Information Bulletin RI45 PII 3-10 C79000-Z7076-C814-02...

  • Page 31: Expanding The Ri45 Pii

    Expanding the RI45 PII Chapter Overview This chapter describes how to expand your device: Opening the unit Components visible after opening the unit Installing a memory expansion card Changing the backup battery Options. Product Information Bulletin RI45 PII C79000-Z7076-C814-02...

  • Page 32: Opening The Unit

    Please note that only qualified personnel should be allowed to work on the open unit, so that the warranty on the device is not affected. Authorized Siemens maintenance and repair centers offer you a specialist maintenance service. The addresses are listed at the end of the Product Information Bulletin.
  • Page 33 Expanding the RI45 PII Before Opening Please observe the following rules before opening the unit: the Unit Before you disconnect the power supply cable, discharge any electrostatic (ESD guidelines) charge on your body. You can do this by touching the metal mounting plate for the interfaces on the rear panel of the unit.

  • Page 34: Components Visible After Opening The Unit

    Expanding the RI45 PII Components Visible After Opening the Unit View Once you have removed the top cover of your unit, the components are visible. Floppy disk drive PCI graphics card PII CPU with heat sink Sound interface card VR submodule (for RI45 PII Tower only) DIMM memory ( max 3) Hard disk drive support...
  • Page 35 Expanding the RI45 PII Mother Board The mother board is the heart of the RI45 PII. Here, data are processed and stored, and interfaces and device I/Os are controlled and managed. X800 1 2 3 4 X502 X501 4 3 2 1 Ï...
  • Page 36 Expanding the RI45 PII Components on The following components are located on the mother board of the RI45 PII: the Mother Board Designa- Name Functions tion Slotbus ISA/PCI connector between basic module and bus module IDE secondary Secondary IDE interface, standard ribbon cable IDE primary Primary IDE interface, standard ribbon cable Keyboard connection MINI DIN keyboard plug (trackball supported)

  • Page 37: Installing Memory Expansion Cards

    Expanding the RI45 PII Installing Memory Expansion Cards Standard Memory There are three ECC-compatible slots for 72-bit DIMM memory expansion submodules on the mother board. The current memory configuration is 64 MB. You can extend it up to a maximum of 384 MB. The memory comes supplied with EDO RAM submodules.
  • Page 38 Expanding the RI45 PII Installing the Plug the DIMM cards in as follows: DIMM Cards 1. Turn off the unit and unplug the power cable. 2. Open the unit as described in Section 4.1. 3. Remove all inserted ISA modules. 4.

  • Page 39: Changing The Backup Battery

    Do not recharge the battery and do not open the battery by force. The correct lithium battery can only be ordered from Siemens (order no.: W79084-E1003-B1). Return used lithium batteries to the manufacturer or recycler or dispose of them as special waste according to local regulations.

  • Page 40: Options

    Risk of damage to the unit! Please note that only qualified personnel should be allowed to work on the open unit, so the warranty on the device is not affected. Authorized Siemens maintenance and repair centers offer you a specialist maintenance service.

  • Page 41: Technical Specifications

    Technical Specifications Chapter Overview In this chapter you will find the technical specifications. Product Information Bulletin RI45 PII C79000-Z7076-C814-02...

  • Page 42: Technical Specifications

    Technical Specifications Technical Specifications Order Number See cover sheet Safety Electromagnetic compatibility (EMC) Ambient conditions Mechanical specifications Product Information Bulletin RI45 PII C79000-Z7076-C814-02...
  • Page 43 Technical Specifications Mother Board Drives Graphics Interfaces MPI/DP interface, optically isolated * Product Information Bulletin RI45 PII C79000-Z7076-C814-02...
  • Page 44 Technical Specifications Function displays Optically isolated within the safety extra-low voltage circuit (SELV) 1) In sum 100W must not be exceeded 2) 12V can be loaded with 11 A for a maximum of 10 s 3) The order number and features of PCS7 devices can be found in the the publication “Supplement for Device Configuration”...

  • Page 45: Error Diagnostics

    Error Diagnostics Chapter This chapter provides you with tips on how to localize and troubleshoot Overview frequently occurring problems. Correcting malfunctions Error messages Self-test prior to booting Refer to your operating system documentation for operating system error messages. Product Information Bulletin RI45 PII C79000-Z7076-C814-02...

  • Page 46: Problems When Using Modules From Other Manufacturers

    – If the PC still crashes, you must contact your technical support team. – If the error no longer occurs, the module you used from another manufacturer was the cause of the fault. Replace this module with a Siemens module, or contact the module supplier. Product Information Bulletin RI45 PII C79000-Z7076-C814-02...

  • Page 47: The Monitor Remains Dark

    Error Diagnostics The Monitor Remains Dark Cause and The following causes are possible: Remedy The monitor has been switched off. Switch on the monitor. The monitor is in “powersave” mode. Press any key on the keyboard. The brightness button has been set to dark. Set the screen’s brightness button to obtain more light.

  • Page 48: The Screen Display Does Not Appear Or Drifts

    Error Diagnostics The Screen Display Does not Appear or Drifts Cause and Either the incorrect line frequency and/or the incorrect resolution is set for Remedy the screen or for the user program. Stop the user program. If the error still occurs after you have ended the program, switch off the monitor.

  • Page 49: The Clock Time And/Or The Date In Your Pc Is Incorrect

    Error Diagnostics The Clock Time and/or the Date in Your PC Is Incorrect Remedy Set the clock time and the date in the setup menu. Press <F2> to call setup when booting the computer. Note The battery is dead if the clock time and the date are still incorrect after you switch off your PC and switch it back on again.

  • Page 50: An Error Message Appears On The Screen

    Error Diagnostics An Error Message Appears on the Screen Error Messages The following table describes the error messages that the BIOS system outputs. Error messages the operating system or program outputs are described in the manuals for these programs. Press <F2> to call Setup when booting the computer.

  • Page 51: Ri45 Pii Self-Test Prior To Booting

    Error Diagnostics RI45 PII Self-Test Prior to Booting When the RI45 PII is powered up, it runs a self–test (POST = Power On Self Test). If the POST detects a fault, it outputs the sequence of beeps (beep code) assigned for the fault. Each beep code consists of 2 x 2 sequences. In addition, the individual self-test steps are output at I/O port 80h.
  • Page 52 Error Diagnostics The POST codes in order of occurrence: Display (hex) Meaning Description TP_VERIFY_REAL Test whether the CPU is in real mode TP_RESET_PIC Reset the interrupt controller TP_RESTORE_CRO Restore the controller register TP_PCI_BM_RESET Reset the PCI bus master TP_CHK_SUTDOWN Check the shutdown code TP_SET_HUGE_ES Switch the ES to special mode TP_DISABLE_NMI...
  • Page 53 Error Diagnostics Display (hex) Meaning Description TP_VID_SHADOW Copy the video BIOS to RAM TP_SET_HUGE_ES Switch the ES to special mode TP_8742_TEST Test circuit 8742 TP_KB_TEST Keyboard available? TP_KEY_CLICK Switch the keyboard click on/off TP_KEYBOARD Check the keyboard TP_HOT_INT Test for unexpected interrupts TP_QUIETBOOT_START Switch off any boot messages TP_CR_DISPLAY...
  • Page 54 Error Diagnostics Display (hex) Meaning Description TP_KEYLOCK_TEST Preset the keylock TP_PEM_LOCK Stop the error manager TP_PEM_DISPLAY Display any possible errors TP_ERASE_F2 Delete the F2 message TP_SCAN_FOR_F2 Check whether to activate setup TP_SETUP_CHEK Output any F1/F2 message TP_CLEAR_BOOT Cancel the self-test flag TP_ERROR_CHECK Check for any possible errors TP_POST_DONE...

  • Page 55: Service Representatives

    Service Representatives Chapter Overview Please contact the authorized regional service department or authorized repair centers for all of your service needs. The relevant addresses can be found at the end of this chapter. For further support, contact the SIMATIC Customer Support Hotline. Product Information Bulletin RI45 PII C79000-Z7076-C814-02...
  • Page 56 SIMATIC products via its online services: Services General current information can be obtained from: – the Internet under http://www.ad.siemens.de/simatic-cs – the Fax-Polling number 08765-93 02 77 95 00 Current product information leaflets and downloads which you may find useful are available: –...

  • Page 57: Regional Repair Centers

    Service Representatives Regional Repair Centers Region Phone Augsburg +49 (821)2595 599 +49 (821)2595 546 Berlin +49 (30)386 34926 +49 (30)386 34933 Bielefeld +49 (521)291 323 +49 (521)291 538 Bremen +49 (421)364 2093 +49 (421)364 2107 Chemnitz +49 (371)475 3860 +49 (371)475 3888 Cologne Ossendorf +49 (221)576 6633 +49 (221)576 6630...
  • Page 58 Service Representatives Country Phone Argentina +54 (1) 3408400 +54 (1) 3408400 3163 Australia +61 (3) 9420 7274 +54 (3) 9420 7500 Austria +43 (1) 1707 29886 +43 (1) 1707 53730 Belgium +32 (2) 536 2905 +32 (2) 536 2880 Brazil +55 (11) 7947 1999 ext.
  • Page 60 Siemens AG Bereich Automatisierungs- und Antriebstechnik Geschaeftsgebiet Industrie-Automatisierungssysteme Postfach 4848, D-90327 Nuernberg Subject to change without prior notice. C79000-Z7076-C814...
