- Page 1 PROVENCE Folding shutter Installation instructions INSTALLATION BY SPECIALIST PERSONNEL Valid from 09.2011 E 911.5...
-
Page 2: Notes
These installation instructions are to be passed of commissioning and utilisation lead to the along in the event of the sale of this product. loss of any liability claims against EHRET These instructions are addressed to qualifi ed GmbH. specialist personnel. Qualifi ed specialist per-... -
Page 3: Table Of Contents
Installation steps ........10 B PROVENCE – with one-handed opener Scope of delivery . -
Page 4: Explanation Of Symbols And Characters
Important notes Explanation of signs and symbols Safety notes Warning notes Only qualifi ed specialist personnel may carry out installation and commissioning! DANGER WARNING Designates an imminent danger that Incorrect installation could lead to se- could lead to death or severe injuries if vere injuries and/or damage to property. - Page 5 Important notes No personnel or obstacles are permitted to WARNING be within the range of pivoting and/or travel- ling shutters while they are moving. Keep Danger of suffocation from packaging personnel and objects away until the shut- foil. ters have reached their fi nal position. ...
-
Page 6: Ec Declaration Of Conformity
Aluminium shutters Bahnhofstrasse 14 - 18 77972 Mahlberg, Germany hereby declares that the following product Product designation: Folding shutter PROVENCE Description of function: Sun/glare protection and screen meets all the applicable requirements of the EC Directives specified above. The following harmonised standards have been applied in full: EN 13659:2004+A1:2008 Shutters –... -
Page 7: Installation Faqs
Important notes Installation FAQs Which parts have been delivered? • Reinsert the dismounted guide rail half and screw it into place. • Frame profiles, loose • Position, drill and screw the fastening profile • Slat packages of the slat packages on to the lateral frame profiles. -
Page 8: A Provence - Without Opener
A PROVENCE – without opener A PROVENCE – without opener Scope of delivery... - Page 9 PROVENCE – without opener A Contained in the scope of delivery Tools required* *not included in the scope of delivery 4× Ø 4 12× Ø 4,2 12× Ø 4,2 6× M5 Size 3 Torx 20 1× 1× 2× 6× Drill Ø 4.2 mm Masonry drill 2×...
-
Page 10: Installation Steps
A PROVENCE – without opener Installation steps 1 Assembling the standard fastening frame ......11 2 Assembling the barrier-free fastening frame (optional). -
Page 11: Assembling The Standard Fastening Frame
PROVENCE – without opener A Assembling the standard fastening frame Sliding block Sliding block 12× S1 2× S3 6× 2× 2× sliding block Size: 3 2× sliding block... -
Page 12: Assembling The Barrier-Free Fastening Frame (Optional)
A PROVENCE – without opener Assembling the barrier-free fastening frame (optional) Sliding block 6× S1 4× S4 4× S5 2× 2× Size: 3... -
Page 13: Fastening In The Reveal
PROVENCE – without opener A Fastening in the reveal not included in the scope of delivery* *Installation material to be provided by the customer! -
Page 14: Dismounting The Guide Rail
A PROVENCE – without opener Dismounting the guide rail Dismount half of the guide rail. Hanging the slat packages in place Insert the slat package into the bottom guide (pay attention to whether it is the left or right pack- age). -
Page 15: Mounting The Guide Rail
PROVENCE – without opener A Mounting the guide rail Reinstall the guide profi le. Push the slat package up to the lateral frame profi les, then open the fastening profi les as illustrated in the diagram. Fastening profi le Fastening the slat packages ... -
Page 16: Mounting The Centre Lock
A PROVENCE – without opener Mounting the centre lock Fasten the centre lock in the existing drill holes. 4× N1 Mounting the plastic spring Screw the plastic spring into the pre-drilled fastening holes. 4× S2... -
Page 17: 10 Mounting The Top And Bottom Inlet Brackets
PROVENCE – without opener A 10 Mounting the top and bottom inlet brackets Position the inlet bracket in the middle (see image) in front of the compensation profi les and screw into place. Sliding block Inlet bracket M5 screw 11 Setting the locking blocks ... -
Page 18: 12 Setting The Retaining Brackets
A PROVENCE – without opener 12 Setting the retaining brackets Align the retaining bracket with the bolt rod. 13 Fastening the barrier-free retaining bracket (optional) Align the retaining bracket with the bolt rod, drill and fasten with rivets. -
Page 20: B Provence - With One-Handed Opener
B PROVENCE – with one-handed opener B PROVENCE – with one-handed opener Scope of delivery... - Page 21 PROVENCE – with one-handed opener B Contained in the scope of delivery 2× Ø 4 12× Ø 4,2 6× Ø 4,2 2× M5 4× M5 6× M5 Installation profi le 2 × washer for M4 4 × rubber buffer, small Hinge pin profi...
-
Page 22: Installation Steps
Installation steps 2–11 see installation instructions “A PROVENCE – without opener” , page 12–17 2 Assembling the barrier-free fastening frame (optional)....12 3 Fastening in the reveal . -
Page 23: Assembling The Standard Fastening Frame
PROVENCE – with one-handed opener B Assembling the standard fastening frame Sliding block Insert the hinge profi le! Insert the hinge profi le! 12× S1 2× S5 Inside Outside 10× 2× 2× sliding block inside 2× sliding block inside 2× sliding block outside 2×... -
Page 24: Fastening The Hinge Profi Le
B PROVENCE – with one-handed opener Fastening the hinge profi le Align the hinge profi le so that it is laterally Insert 3 sliding blocks on both the left and fl ush, drill and fasten with rivets. right side. -
Page 25: Mounting In The Reveal
PROVENCE – with one-handed opener B Mounting in the reveal Position and align the profi le with a spirit Spirit level level, drill and fasten in place. Hanging the folding shutter frame in place Hang the folding shutter frame in place in the ... -
Page 26: Assembling The One-Handed Opener
B PROVENCE – with one-handed opener Assembling the one-handed opener Push all the opener parts on to the hexagonal bar (as in the diagram). Stick the small rubber buffers on to the brackets. 4 × Size 4 Rubber buffer,... -
Page 27: Mounting The Opener On The Fastening Frame
PROVENCE – with one-handed opener B Mounting the opener on the fastening frame Mark the position of the opener bracket on the frame. Using the sliding blocks, fasten the opener bracket in the vertical profi le. Align the opener bracket at the right height on the left and right side. -
Page 28: Mounting The Lock, Standard
B PROVENCE – with one-handed opener Mounting the lock Mount the bolt at a distance (4 mm) with the sliding block. View from inside Bolt Sliding block Bolt Bolt 4×... -
Page 29: Mounting The Lock, Asymmetrical
PROVENCE – with one-handed opener B Mounting the lock, asymmetrical Mount the bolt and bolt guide at a distance (4 mm) with sliding blocks. View from inside Bolt Sliding block Bolt Bolt guide Bolt rod Determine dimension on site! Determine dimension on site! 4×... -
Page 30: Marking The Opener Scissor On The Window Frame
Depending on the window type (wood, alu- minium, PVC), use holes or screws to mount the opener scissor. not included in the scope of delivery Installation steps 2–11 : see installation instructions “A PROVENCE – without opener” , page 12–17... - Page 31 PROVENCE – with one-handed opener B CAUTION Risk of crushing and injury Due to the size and weight of the folding shutter, hands may be crushed and injured when ope- ning and closing the opener. When opening and closing the opener, use your other hand to support it.
-
Page 32: C Provence - With Two-Handed Opener
C PROVENCE – with two-handed opener C PROVENCE – with two-handed opener Scope of delivery... - Page 33 PROVENCE – with two-handed opener C Contained in the scope of delivery Tools required* *not included in the scope of delivery 2× 6× 4× 6× Size: 3 2× M4 4 × sliding block Torx 20 Metal drill Ø 4.2 mm...
-
Page 34: Installation Steps
Installation steps 2–11 see installation instructions “A PROVENCE – without opener” , page 12–17 2 Assembling the barrier-free fastening frame (optional)....12 3 Fastening in the reveal . -
Page 35: Assembling The Standard Fastening Frame
PROVENCE – with two-handed opener C Assembling the standard fastening frame Sliding block Insert the hinge profi le! Insert the hinge profi le! 12× 6× Inside Outside 6× 2× Sliding block outside Size 3 Sliding block... -
Page 36: Fastening The Hinge Profi Le
C PROVENCE – with two-handed opener Fastening the hinge profi le Align the hinge profi le so that it is laterally Insert 2 sliding blocks on both the left and fl ush, drill and fasten with rivets. right side. -
Page 37: Mounting In The Reveal
PROVENCE – with two-handed opener C Mounting in the reveal Position and align the profi le with a spirit level, drill and fasten in place. Spirit level Hanging the folding shutter frame in place Hang the folding shutter frame in place in ... -
Page 38: Assembling The One-Handed Opener
C PROVENCE – with two-handed opener Mounting the opener on the fastening frame Mark the position of the opener bracket on the frame. Using the sliding blocks, fasten the opener bracket in the vertical profi le. Align the opener bracket at the right height on the left and right side. -
Page 39: Fastening The Opener Scissor On To The Window Frame
When the frame is open, depending on the window type (wood, aluminium, PVC), use holes or screws to mount the opener scis- sor. not included in the scope of delivery* Installation steps 2–11 : see installation instructions “A PROVENCE – without opener” , page 12–17... -
Page 40: D Provence - With Rod Lock
D PROVENCE – with rod lock D PROVENCE – with rod lock Scope of delivery... - Page 41 PROVENCE – with rod lock D Contained in the scope of delivery Tools required* *not included in the scope of delivery 2× Ø 4 Drill Ø 4.2 mm Drill Ø 3.5 mm 7× M5 2× Ø4.2 Size: 3 2× Ø4.2 12×...
-
Page 42: Installation Steps
Installation step 9 see chapter A “PROVENCE – without opener” ..... . p. 16 9 Mounting the plastic spring ....... . . 16 D 3 Mounting the top and bottom inlet brackets . -
Page 43: D 1 Assembling Fastening Frame A) With Rod Lock
2× sliding block Torx 20 7× S1 12× S4 2× 10× Size 3 2× Frame bottom Locking block Rod lock 3× sliding block 2× sliding block Installation steps 3–7: see chapter A “PROVENCE – without opener” , p. 13–15... -
Page 44: B) Barrier-Free Version With Rod Lock (Optional)
Inlet bracket for rod lock Inlet bracket 46 – 50 Locking bracket for rod lock Locking bracket Locking bracket for slat package for slat package Installation steps 3–7: see chapter A “PROVENCE – without opener” , p. 13–15... -
Page 45: D 2 Mounting The Rod Lock Centre Closure
PROVENCE – with rod lock D D 2 Mounting the rod lock centre closure Determine the height of the rod lock centre closure Place the spacer tube with the bevel facing inside fl ush with the frame and fasten with S3 screws. -
Page 46: Installation Step 9 See Chapter A "Provence - Without Opener
Adjust the length of the rod lock centre closure and use the lug to align it horizontally. Then drill and fasten the hook-in lug with rivets. Hook-in lug Installation step 9: see chapter A “PROVENCE – without opener” , p. 16... -
Page 47: D 3 Mounting The Top And Bottom Inlet Brackets
PROVENCE – with rod lock D D 3 Mounting the top and bottom inlet brackets Position the inlet brackets so that the locking slat can still be opened and closed. Sliding block S1 screw Locking slat Inlet bracket Slat package... - Page 48 © 11.2018 EHRET GmbH | E 911.5 | This technical document includes information that is protected by copyright. All rights are reserved. We reserve the right to make changes, including technical changes, in this document. This document has been prepared with great...
