PERSIENNE
Aluminium folding shutters
Installation instructions
INStAllAtIoN by
SPEcIAlISt PERSoNNEl
Valid from 06.2017
E 634.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PERSIENNE and is the answer not in the manual?

Questions and answers

Summary of Contents for EHRET PERSIENNE

  • Page 1 PERSIENNE Aluminium folding shutters Installation instructions INStAllAtIoN by SPEcIAlISt PERSoNNEl Valid from 06.2017 E 634.1...
  • Page 2: Notes

    For this reason, observe the following notes. loss of any liability claims against EHREt Should any of the information in these installa- GmbH. Installation and/or operation in full or...
  • Page 3: Table Of Contents

    Contents Notes..........2 Explanation of signs and symbols .
  • Page 4: Explanation Of Signs And Symbols

    Important notes Explanation of signs and symbols Safety notes Warning notes  only qualified specialist personnel may carry out installation and commissioning! DaNgEr WarNINg  Designates an imminent danger that Incorrect installation could lead to se- could lead to death or severe injuries if vere injuries and/or damage to prop- the respective precautionary measures erty.
  • Page 5 Important notes  No personnel or obstacles are permitted to WarNINg be within the range of pivoting and/or travel- ling shutters while they are moving. Keep Danger of suffocation from packaging personnel and objects away until the shut- foil. ters have reached their final position. ...
  • Page 6: Ec Declaration Of Conformity

    EHREt GmbH Aluminium shutters bahnhofstrasse 14 - 18 77972 Mahlberg, Germany declares that the product: PErSIENNE folding shutter Description of function: Sun/glare protection and screen to which this guideline refers, meets the requirements of the Ec Directives specified above.
  • Page 7: Installation Faqs

    Important notes Installation FaQs Which parts have been delivered? What must be observed during on-site per- formance? •    S ash  packet  per  stop  diagram,  complete,  with pre-installed hinge profile and espagno- •    T he  connection  profile  must  be  aligned  per- lette closure pendicularly on-site prior to installation.
  • Page 8: Product Description

    1 Product description Scope of delivery PErSIENNE Contained in the scope of delivery Example view of 3l–3R Sash packets Ex. 5l Ex. 5R Espagnolette closure, pre-installed Shutter catch, loose Stop angle, loose...
  • Page 9: Tools Required

    1 Product description accessories tools required locking not included in the scope of delivery Espagnolette closure pre-installed per sash packet 1× shutter catch left 1× shutter catch Drill Ø 5.1 mm right Drill for wall mounting 1× supporting block not included in the scope of delivery 2×...
  • Page 10: Operating Principle

    1 Product description operating principle opening the PErSIENNE Example 5l Closed PERSIENNE   Wrong way to open   Right way to open (winding)
  • Page 11 1 Product description...
  • Page 12: Installation Instrucions

     Select the number of fastening holes as well as connecting elements  Pre-drill the hinge profile EHRET recommends fastenings with a dis- tance of max. 70  mm to the top/bottom frame edges and max. 150 mm between the other fastenings.
  • Page 13: Fastening Sash Packet 2 To The Connection Profile (For Double-Sided Diagrams)

    2 Installation instructions Fastening sash packet 2 to the con- nection profile for double-sided diagrams)  Fasten the sash packet with a suitable fitting material in the connection profile  First pre-drill and fasten the hinge profile at two locations at the top/bottom Pre-drilling sash packet 2 ...
  • Page 14: Mounting The Shutter Catch

    2 Installation instructions Mounting the shutter catch Mounting the stop angle  Determine the operating height NotE  Mark the holes the selection of the fastening method is de- pendent on the substrate and is therefore ex- clusively your own responsibility. ...
  • Page 15 2 Installation instructions  Maintain a minimum distance from the win-  Position additional stop angles for joint pro- dow frame to the back of the stop angle (at files PE-G60/-G80/-G100 in the middle of the least 26  mm) or to the stop angle hole (at joint profiles (see Fig.
