Aluminium folding sliding shutters
FSL-light
Installation instructions
InStALLAtIon by
SpecIALISt perSonneL
Valid from 03.2016
E 619.2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FSL-light and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for EHRET FSL-light

  • Page 1 Aluminium folding sliding shutters FSL-light Installation instructions InStALLAtIon by SpecIALISt perSonneL Valid from 03.2016 E 619.2...
  • Page 2: Notes

    GmbH. these instructions are addressed to qualified specialist personnel.
  • Page 3: Table Of Contents

    Contents Notes ..........2 Explanation of signs and symbols .
  • Page 4: Explanation Of Signs And Symbols

    Important notes Explanation of signs and symbols Safety notes Warning notes  only qualified specialist personnel may carry out installation and commission- ing! DANgEr WArNINg  Designates an imminent danger that could lead to death or severe injuries if Incorrect installation could lead to se- the respective precautionary measures vere injuries and/or damage to property.
  • Page 5 Important notes  no personnel or obstacles are permitted to WArNINg be within the range of pivoting and/or travel- ling shutters while they are moving. Keep Danger of suffocation from packaging personnel and objects away until the shut- foil. ters have reached their final position. ...
  • Page 6: Ec Declaration Of Conformity

    GmbH Aluminium shutters bahnhofstrasse 14–18 77972 Mahlberg, Germany declares that the product: FSL-light folding sliding shutters Description of function: Sun/glare protection and screen to which this guideline refers, meets the requirements of the ec Directives specified above the following harmonised standards have been applied in full: EN 13659: 2015-05 Shutters and external venetian blinds –...
  • Page 7: Installation Faqs

    Important notes Installation FAQs Which parts have been delivered? •    I f there is an odd number of sashes, the side- hung sash must be fastened in its open posi- •    G uide rail, cut to measure tion using an additional locking part. •  Guides left and right •    S ash  packets,  each  containing  two  folding  WArNINg sliding sashes • ...
  • Page 8: Product Description

    1 product description Scope of delivery FSL-light folding sliding shutters Contained in the scope of delivery Sashes guide Hinges pre-installed Guide can be used left/ Guide rail right Hinges FSL-light hinge, right FSL-light hinge, left Accessories Ø 4 mm...
  • Page 9 1 product description Locking tools required* *not included in the scope of delivery Variant 1 Masonry drill barrel bolt FSL-light Drill Ø 4.2 mm Drill Ø 3.5 mm Shutter lock Left right WAF 3 4,2 × 16 INFo Fitting material to be provided by the customer!
  • Page 10: Installation Instructions

    2 Installation instructions 2 Installation instructions Preparation Pre-drilling the guide rail WARNING WARNING Danger of injury and property damage Danger of injury and property damage caused by unsuitable fitting materials caused by falling folding sliding sashes  Select the fastening material in accordance Fastening the guide rail inadequately can cause with the load capacity of the installation sub- the folding sliding sashes to fall.
  • Page 11: Mounting The Guide Rail

    2 Installation instructions Mounting the guide rail WALL InStALLAtIon NotES the guide bracket can also be installed on the Important: If the drilling dimension for the first outside. two chambers is to be larger than Ø 9.7 mm,  check whether the bracket can be installed the vertical dimension (15 mm) must be adap- on the inside before installation.
  • Page 12: Installing The Hinges On The Sashes

    2 Installation instructions Installing the hinges on the sashes  Keep a side projection of 56 mm on the  Keep the sashes, hinges, n1 rIVetS and hinge side. Ø 4.2 mm drill on hand.  Align and fasten the guide rail. Locking plate ...
  • Page 13: Installing The Accessories On The Hinge Sash

    2 Installation instructions Installing the accessories on the hinge sash  Determine the installation heights of the VArIANt 1+2 hinges.  Keep the shutter lock, pull handle, n1 rIV- etS and Ø 4.2 mm drill on hand. Sash upper edge Upper edge of top hinge ...
  • Page 14 2 Installation instructions  position the shutter lock and fasten using VArIANt 2 n1 rIVetS.  Determine the installation height of the Do not forget the supports for the shutter shutter holder lock! shutter holder movable Installation height: Lower edge of sash to centre of shutter holder ...
  • Page 15: Installing The Accessories On The Access Sash

    2 Installation instructions Installing the accessories on the access sash  position the barrel bolt and fasten using n1 VArIANt 1 rIVetS.  Keep the barrel bolt, n1 rIVetS and Ø 4.2 mm drill on hand. Access sash 2.10 barrel bolt ...
  • Page 16: Installing The Hinge Sash

    2 Installation instructions Installing the hinge sash VArIANt 2 NotES •    T he selection of the fastening method is de-  Determine the installation height of the shut- pendent on the base and is therefore exclu- ter holder sively your own responsibility. •    T he installation material is not included in the  scope of delivery.
  • Page 17 2 Installation instructions  position the hinge sash under the guide rail  check the gap (7 mm) between the hinge and align it using a spirit level. sash and the guide rail.  Hang the brackets on the hinge and screw onto the base.
  • Page 18: Setting The Locking Plate

    2 Installation instructions Setting the locking plate VArIANtE 1  Keep S1 ScreWS and Ø 3.5 mm drill on hand.  place the sash packet in the desired opening position.  Mark the locking plate. The marked distance dimension of 65 mm relates to an edge clearance of 56 mm and 2.14 applies exclusively to this measurement!
  • Page 19: Installing The Guide

    2 Installation instructions Installing the guide  position the guide bracket on the corner of NotES the frame and fasten using n1 rIVetS. the guide bracket can also be installed on the outside.  check whether the bracket can be installed on the inside before installation.
