EHRET VOLETRONIC Operating Instructions Manual

Motorisation for sliding shutters

Advertisement

Quick Links

VOLETRONIC
Motorisation for sliding shutters
Operating instructions
INSTALLATION
SPECIALIST PERSONNEL
Valid from 09.2011
E 917.2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VOLETRONIC and is the answer not in the manual?

Questions and answers

Summary of Contents for EHRET VOLETRONIC

  • Page 1 VOLETRONIC Motorisation for sliding shutters Operating instructions INSTALLATION SPECIALIST PERSONNEL Valid from 09.2011 E 917.2...
  • Page 2: Notes

    Bore hole sizes and fastening material are re- commendations; these could vary because of the substrate! Sliding shutters Aluminium shutters Installation instructions INSTALLATION BY SPECIALIST PERSONNEL Valid from 09.2011 E 915.5  E 915 Installation instructions | EHRET Sliding shutters...
  • Page 3: Table Of Contents

    Group control ......... 28 VolEtroNiC Solar 12 V | wireless remote control Product description .
  • Page 4: Explanation Of Signs And Symbols

    Important notes Explanation of signs and symbols Safety notes Warning notes  only qualified specialist personnel may carry out installation and commission- ing! DANgEr  Designates an imminent danger that WArNiNg could lead to death or severe injuries if incorrect installation could lead to se- the respective precautionary measures vere injuries and/or damage to prop- are not implemented.
  • Page 5  Make sure that the shutters are locked be- be observed, as otherwise damage to the fore any wind load occurs. motor could occur. EHRET GmbH assumes  The shutters may not be operated at wind no liability for damage resulting from incor- speeds from 62 km/h (stormy wind).
  • Page 6: Electrical Installation

    Important notes Electrical installation  Other requirements may apply to the instal- DANgEr lation of the line safety switch, depending on the location. For example, it could be necessary to use a line safety switch with Electrical shock (230 V) additional separation of Phase N in order to switch off all poles.
  • Page 7: Incorrect Operation

    Important notes incorrect operation Behavior at power breakdown Correct operation can no longer be ensured if IMPORTANT the sliding shutter is moved by hand quickly and with great force in its position, and not by Deletion of reference position due to po- means of operation with the OPEN- or wer failure...
  • Page 8: Disposal

    Important notes Disposal IMPORTANT IMPORTANT Disposal Disposal • The following information must be strictly  Dispose of any machine parts in such a adhered to in order to prevent any environ- way that damage to human health and the mental damage. Even if the machine is dis- environment can be excluded.
  • Page 9: Ec Declaration Of Conformity

    D - 77972 Mahlberg erklärt für das Produkt: VolEtroNiC 230 V sliding shutter drive VolEtroNiC Solar 12 V sliding shutter drive to which this guideline refers, is in conformance with the stipulations of Radio equipment and telecommunications terminal equipment guideline 1999/05/EC...
  • Page 10: A Voletronic 230 V | Serial Push-Button Operation Product Description

    VOLETRONIC 230 V | serial push-button operation A VolEtroNiC 230 V | serial push-button operation Product description Connection cable with 5-pin Hirschmann plug Rail clamp Motor cover Rail connection technical data The EHRET VOLETRONIC 230 V sliding shutter Power supply 85 VAC–265 VAC,...
  • Page 11: Connection

    VOLETRONIC 230 V | serial push-button operation Connection Motor housing Connection cable with plug ca. 55 4 3 2 1 Motor 5-pin Hirschmann plug Motor cover Earth – protective conductor (green/yellow) Mains connection 230 V with Hirschmann Mains connection, L -Phase (230 V) coupling, 5-pin.
  • Page 12: Commissioning

    VOLETRONIC 230 V | serial push-button operation Commissioning NotE seRIAl Push-buTTON • The correct installation of the sliding shutter • In order to avoid an unwanted change of pa- drive may be carried out only by authorised rameters, the time (max. 2 sec.) between the specialist personnel;...
  • Page 13: Setting The Running Direction

    VOLETRONIC 230 V | serial push-button operation Setting the running direction Press and hold down the OPEN button and the CLOSE button together and simultaneously (approx. 3 sec.), until a brief signal tone is heard and then goes out. Release the buttons only briefly, then, within a maximum of 2 seconds, press and hold them down simultaneously again until the following 2 signal tones go out.
  • Page 14: Executing A Learning Run

    VOLETRONIC 230 V | serial push-button operation Executing a learning run NotES Systems with double bars (a sash that is not connected with the drive cable) The double bars must be manually taught during the learning run:  Move sashes into the Open end position ...
  • Page 15: Setting The Speed

    VOLETRONIC 230 V | serial push-button operation Setting the speed Press and hold down the OPEN button and the CLOSE button together and simultaneously (approx. 3 sec.), until a brief signal tone is heard and then goes out. Release the buttons only briefly, then press and hold them down together again once more until the following 2 signal tones go out.
  • Page 16: Impulse/Dead Man Mode

    VOLETRONIC 230 V | serial push-button operation impulse/dead man mode Press and hold down the OPEN button and the CLOSE button together and simultaneously (approx. 3 sec.), until a brief signal tone is heard and then goes out. Release the buttons only briefly, then press and hold them down together again once more until the following 2 signal tones go out.
  • Page 18: B Voletronic 230 V | Wireless Remote Control Product Description

    VOLETRONIC 230 V | wireless remote control B VolEtroNiC 230 V | wireless remote control Product description Connection cable with 3-pin Hirschmann plug Rail clamp Motor cover Rail connection technical data The VOLETRONIC sliding shutter drive with Power supply 85 VAC–265 VAC, wireless remote control is a drive with integrat- 50/60 Hz, 30 W...
  • Page 19: Connection

    VOLETRONIC 230 V | wireless remote control Connection Motor housing Connection cable with plug ca. 55 Motor 3-pin Hirschmann-plug Motor cover Earth – protective conductor (green/yellow) 230 V mains connection with Hirschmann Mains connection L – Phase (230 V) coupling. The motor is equipped with a 3-pin Mains connection N –...
  • Page 20: Commissioning

    VOLETRONIC 230 V | wireless remote control Commissioning NotES wIReless ReMOTe cONTROl • The correct installation of the sliding shutter  In order to avoid an unwanted change of pa- drive may be carried out only by authorised rameters, the time (max. 2 sec.) between the specialist personnel;...
  • Page 21: Teaching Master Transmitter

    VOLETRONIC 230 V | wireless remote control teaching master transmitter NotES • The teaching of the master transmitter in the motor must take place at a short distance. All further settings can be undertaken from a greater distance. • Parameter modifications can be carried out only with the master transmitter. The parameter mod- ifications are transferred to the additionally taught transmitters as required.
  • Page 22: Checking/Changing The Running Direction

    VOLETRONIC 230 V | wireless remote control Checking/Changing the running direction If the running direction is correctly set, then the LED display on the drive will light up green during   ascent and red during descent. If this is not the case: Continue to hold the PROG button pressed down until the following signal tone has gone out.
  • Page 23: Performing A Learning Run

    VOLETRONIC 230 V | wireless remote control Performing a learning run NotES Systems with double bars (a sash that is not connected with the drive cable) The double bars must be manually taught during the learning run:  Move sashes into the Open end position ...
  • Page 24: Setting The Speed

    VOLETRONIC 230 V | wireless remote control Setting the speed Continue to hold the PROG button pressed down until the subsequent signal tone has gone out. Now release the PROG button and, within 2 sec., hold down the OPEN and the...
  • Page 25: Teaching An Additional Transmitter

    VOLETRONIC 230 V | wireless remote control teaching an additional transmitter Continue to hold the PROG button pressed down until the subsequent signal tone has gone out Release the PROG button and, within approx. 2 sec., briefly press the OPEN button on the master transmitter once.
  • Page 26: Clearing Of An Additionally Taught Transmitter

    VOLETRONIC 230 V | wireless remote control Clearing of an additionally taught transmitter Continue to hold the PROG button pressed down until the subsequent signal tone has gone out Now release the PROG button and, within approx. 2 sec., actuate the CLOSE button on the master transmitter.
  • Page 27: Global Clearing Of All Additionally Taught Transmitters

    VOLETRONIC 230 V | wireless remote control global clearing of all additionally taught transmitters Continue to hold the PROG button pressed down until the subsequent signal tone has gone out Now release the PROG button and, within approx. 2 sec., actuate the CLOSE button on the master transmitter.
  • Page 28: Group Control

    VOLETRONIC 230 V | wireless remote control group control Application example 1 Drive 1 Drive 2 Drive 3 Drive 4 Black Pearl Black Pearl Black Pearl Black Pearl 1-channel 1-channel 1-channel 1-channel Black Pearl 1-channel  Every drive with wireless actuation is assigned its own 1-channel wireless hand-held transmitter as master transmitter.
  • Page 29 VOLETRONIC 230 V | wireless remote control Application example 2 Drive 1 Drive 2 Drive 3 Drive 4 CHANNEL 2 CHANNEL 3 CHANNEL 1 CHANNEL 4 CHANNEL 5 CHANNEL 5 CHANNEL 5 CHANNEL 5 Black Pearl 5-channel  Every drive with wireless actuation has a wireless channel reserved for its use on the multi- channel wireless hand-held transmitter.
  • Page 30: C Voletronic Solar 12 V | Wireless Remote Control Product Description

    VOLETRONIC Solar 12 V | wireless remote control C VolEtroNiC Solar 12 V | wireless remote control Product description Minifit plug Rod battery (1×4) Rail clamping component Rail connection Solar panel 12 V technical data The EHRET VOLETRONIC Solar sliding shutter...
  • Page 31: Connection

    VOLETRONIC Solar 12 V | wireless remote control Connection Motor housing Battery connection | Minifit (F) ca. 55 Solar panel connection | Minifit (M) Motor Battery Minifit plug (F); Motor cover Connection for connecting the battery Minifit cable outlet Monitoring LED on the side of the motor...
  • Page 32: Attach Solar Panel On The Cover

    VOLETRONIC Solar 12 V | wireless remote control Attach solar panel on the cover CAutioN • Because of the mounting holes in the cover, no later modification is possible! • When installing the solar panel, take care to ensure that the cables and minifit plugs are not ex-...
  • Page 33: Attaching The Rechargeable Battery

    VOLETRONIC Solar 12 V | wireless remote control Attaching the rechargeable battery CAutioN The rechargeable batteries are a delicate structural component that may not be damaged. Take this fact into account for handling and during installation.  Do not expose the rechargeable batteries to direct moisture or sunlight.
  • Page 34: Commissioning

    VOLETRONIC Solar 12 V | wireless remote control Commissioning NotES wIReless ReMOTe cONTROl • The correct installation of the slide shutter  In order to avoid an unwanted change of para- drive may be carried out only by authorised meters, the time (max. 2 sec.) between the specialist personnel;...
  • Page 35 VOLETRONIC Solar 12 V | wireless remote control INITIAl cOMMIssIONINg 2. Monitoring solar panel and rechargeable battery • Initial commissioning can be carried out once the motor has been correctly installed  Place the cover on the carrier profile and con- in the sliding shutter system.
  • Page 36: Teaching Master Transmitter

    VOLETRONIC Solar 12 V | wireless remote control teaching master transmitter NotES • The teaching of the master transmitter in the motor must take place at a short distance. All further settings can be undertaken from a greater distance. • Parameter modifications can be carried out only with the master transmitter. The parameter modi- fications are transferred to the additionally taught transmitter as required.
  • Page 37: Monitoring/Modification Of The Direction Of Travel

    VOLETRONIC Solar 12 V | wireless remote control Monitoring/modification of the direction of travel If the direction of travel is correctly set, the LED on the drive will light up green during  upward travel and red during downward travel. If this is not the case: Press and hold the  PROG but- ton down until the subsequent signal tone ceases.
  • Page 38: Further Settings

    NotES The VOLETRONIC Solar 12 V sliding shutter drive with wireless remote control is operated and programmed in the same way as the VOLETRONIC 230 V sliding shutter drive with wireless remote control:  Further configuration options for your wireless remote control, e.g. BlackPearl, can be found in chapter ...
  • Page 39: Troubleshooting

    Maintenance troubleshooting Problem Possible cause(s) Solution(s) Sashes not moving, Cable tension too low  Increase cable tension cable slipping Spring hitting the motor or the Spring is not in the right position  Position the spring on the motor side return pulley (see ...
