GB
KULINARISK

Advertisement

Table of Contents
loading

Related Manuals for IKEA KULINARISK

Summary of Contents for IKEA KULINARISK

  • Page 1 KULINARISK...
  • Page 2 ENGLISH Please refer to the last page of this manual for the full list of IKEA appointed After Sales Service Provider and relative national phone numbers.
  • Page 3 ENGLISH...

  • Page 4: Table Of Contents

    Daily use Energy efficiency Clock functions Environmental concerns Automatic programmes IKEA guarantee Subject to change without notice. Safety information Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible if an incorrect installation and use causes injuries and damage.

  • Page 5: General Safety

    ENGLISH Keep children and pets away from the appliance when it • operates or when it cools down. Accessible parts may become hot during use. If the appliance has a child safety device, it should be • activated. Children shall not carry out cleaning and user maintenance of •...

  • Page 6: Safety Instructions

    ENGLISH Use only the food sensor (core temperature sensor) • recommended for this appliance. Safety instructions • Do not let mains cables touch or come Installation near the appliance door or the niche Warning! Only a qualified below the appliance, especially when it person must install this operates or the door is hot.
  • Page 7 ENGLISH • Do not let the appliance stay unattended • If the appliance is installed behind a during operation. furniture panel (e.g. a door) make sure • Deactivate the appliance after each use. the door is never closed when the •...

  • Page 8: Installation

    ENGLISH • Keep children away from the appliance infants or persons with medical while the Pyrolytic cleaning is in conditions. operation. Internal lighting The appliance becomes very hot and hot air is released from the front cooling Warning! Risk of electric shock. vents.

  • Page 9: Product Description

    ENGLISH For the section of the cable refer to the total Electrical installation power on the rating plate. You can also Warning! Only a qualified refer to the table: person must do the electrical installation. Total power (W) Section of the cable (mm²) The manufacturer is not maximum 1380...

  • Page 10: Control Panel

    ENGLISH Control panel Electronic programmer 9 10 Symbol Function Comment ON / OFF To turn on and off the oven. Heating Functions Press once to enter to the Heating Functions Menu. or Assisted Cook- Press again to switch to Assisted Cooking. To turn on or off the light, press for 3 seconds.
  • Page 11 ENGLISH Symbol Function Comment Minute Minder To set the function: Minute Minder. To confirm the selection or setting. Display A. Heating function B. Time of day C. Heat-up indicator D. Temperature E. Duration time or end time of a function Other indicators of the display: Symbol Function...

  • Page 12: Before First Use

    ENGLISH Symbol Function Weight Automatic The display shows that the automatic weight system works or that weight can be changed. Heat + Hold The function works. Before first use Accessories can become hotter than usual. Warning! Refer to Safety The oven can emit an odour and smoke chapters.

  • Page 13: Daily Use

    ENGLISH Screw back the screw into the hole after removing the child lock. Warning! Be careful not to scratch the control panel. Daily use Warning! Refer to Safety Symbol / Menu Application chapters. item Navigating the menus Pyrolytic cleaning. Cleaning 1.
  • Page 14 ENGLISH Symbol / Menu Description Symbol / Menu Description item item When ON, the display Activates and deacti- shows the current time vates the alarm tones. Time Indication Alarm/Error when you deactivate Tones the appliance. Reminds you when to When ON, the function clean the appliance.
  • Page 15 ENGLISH Heating Application Heating Application function function To prepare tender, succulent To grill flat food and to toast roasts. bread. Slow Grill Cooking To grill flat food in large To bake cakes with crispy quantities and to toast bottom and to preserve food. bread.

  • Page 16: Clock Functions

    ENGLISH 6. Set the temperature. Heating function Application 7. Press to confirm. To dry sliced fruit, veg- Heat-up indicator etables and mush- rooms. Drying When you turn on a heating function, the bar on the display comes on. The bar shows To keep food warm.

  • Page 17: Automatic Programmes

    ENGLISH • The set temperature is more than 80 °C. If you use the clock functions: • The function: Duration is set. Duration, End Time, the oven turns off the heating elements The function: Heat + Hold keeps prepared after 90 % of the set time. The food warm at 80 °C for 30 minutes.

  • Page 18: Using The Accessories

    3. Select the category and dish. Press for this oven on the website to confirm. www.ikea.com. To find the 4. Select a recipe. Press to confirm. proper Recipe Book check the article number on the rating plate on the front frame of the oven cavity.
  • Page 19 ENGLISH Small indentation at the top increase safety. The indentations 3. Turn on the oven. are also anti-tip devices. The The display shows the core temperature high rim around the shelf sensor symbol. prevents cookware from slipping 4. Press in less than 5 seconds to set of the shelf.

  • Page 20: Additional Functions

    ENGLISH Make sure you push back the telescopic Using the telescopic runners runners fully in the oven before you close Keep the installation instructions the oven door. for the telescopic runners for Warning! Refer to "Product future use. description" chapter. With telescopic runners you can put in and remove wire shelves and trays easily.
  • Page 21 ENGLISH If the Pyrolysis function works, the memory position, press and press door is locked and the symbol of to overwrite an existing programme. a key comes on in the display. You can change the name of a programme in the menu: Edit Programme Name. To turn off the function, press .

  • Page 22: Hints And Tips

    ENGLISH – when the oven is turned on. – if you touch a symbol during the night brightness (apart from ON / (°C) OFF), the display goes back to the 30 - 115 12.5 day brightness mode for the next 10 seconds.
  • Page 23 ENGLISH condensation, add water each time after it Moist Fan Baking dries up. For the best results follow suggestions listed in the table below. Food Accessories Temperature Shelf posi- Time (min) (°C) tion Sweet rolls, 12 baking tray or dripping 20 - 30 pieces Rolls, 9 pieces...
  • Page 24 ENGLISH Food Accessories Temperature Shelf posi- Time (min) (°C) tion Macaroons, 20 baking tray or dripping 25 - 35 pieces Muffins, 12 baking tray or dripping 30 - 40 pieces Savory pastry, baking tray or dripping 25 - 30 16 pieces Short crust bis- baking tray or dripping 25 - 35...
  • Page 25 ENGLISH Accessories Size Picture Ramekins, ceramic 8 cm diameter, 5 cm height Flan base tin, dark, non- 28 cm diameter reflective Information for test institutes Tests according to IEC 60350-1. Food Function Accesso- Shelf Tem- Time (min) Comments ries posi- pera- tion ture (°C)
  • Page 26 Recipe Book check the article number on the rating plate on the front For additional cooking tables please refer frame of the oven cavity. to the Recipe Book which you can find on the website www.ikea.com. To find the...

  • Page 27: Care And Cleaning

    ENGLISH Care and cleaning Warning! Refer to Safety chapters. Notes on cleaning Clean the front of the oven with a soft cloth with warm water and a mild cleaning agent. To clean metal surfaces, use a dedicated cleaning agent. Cleaning Clean stubborn stains with a special oven cleaner.
  • Page 28 ENGLISH Intense For a thorough cleaning: 2 h 30 min. 6. Press When the cleaning starts, the oven door is locked and the lamp does not work. To stop the cleaning before it is completed, Install the removed accessories in the turn off the oven.
  • Page 29 ENGLISH 3. Close the oven door halfway to the first 8. Clean the glass panels with water and opening position. Then lift and pull soap. Dry the glass panels carefully. Do forward and remove the door from its not clean the glass panels in the seat.

  • Page 30: Troubleshooting

    ENGLISH Warning! Danger of electrocution! Disconnect the fuse before you replace the lamp. The lamp and the lamp glass cover can be hot. Caution! Always hold the halogen lamp with a cloth to prevent grease residue from burning on the lamp. 1.
  • Page 31 ENGLISH Problem Possible cause Remedy The oven does not heat up. The automatic switch-off is Refer to "Automatic switch- off". The oven does not heat up. The Child Lock is on. Refer to "Using the Child Lock". The oven does not heat up. The door is not closed cor- Fully close the door.

  • Page 32: Technical Data

    Frequency 50 - 60 Hz Number of functions Energy efficiency Product information according to EU 66/2014 Model identification KULINARISK 904.430.55 Energy Efficiency Index 81.2 Energy consumption with a standard load, conven- 0.93 kWh/cycle tional mode Energy consumption with a standard load, fan-forced 0.69 kWh/cycle...
  • Page 33 ENGLISH Number of cavities Heat source Electricity Volume 72 l Type of oven Built-In Oven Mass 36.1 kg Cooking with fan EN 60350-1 - Household electric cooking When possible, use the cooking functions appliances - Part 1: Ranges, ovens, steam with fan to save energy.

  • Page 34: Environmental Concerns

    LAGAN or TILLREDA - from the original provided that the appliance is accessible date of purchase of your appliance at IKEA for repair without special expenditure. or from the installation date with maximum...
  • Page 35 IKEA appliance in the dedicated IKEA product to the customer’s delivery kitchen furniture; address, then damage to the product • ask for clarification on functions of IKEA that occurs during this delivery will be appliances. covered by IKEA. To ensure that we provide you with the best •...
  • Page 36 Manual before contacting us. How to reach us if You need our service Please refer to the last page of this manual for the full list of IKEA appointed contacts and relative national phone numbers. In order to provide You with a...
  • Page 37 UNITED ARAB EMIRATES : ‫رﻗﻢ ﻣﺠﺎﻧﻲ‬ Toll free: 8 004 532 : ‫ﻣﻮﻗﻊ اﻹﻧﺘﺮﻧﺖ‬ Web: www.IKEA.com QATAR : ‫رﻗﻢ ﻣﺠﺎﻧﻲ‬ Toll free: 8 004 532 : ‫ﻣﻮﻗﻊ اﻹﻧﺘﺮﻧﺖ‬ Web: www.IKEA.qa : ‫اﻟﺒﺮﻳﺪ اﻹﻟﻜﺘﺮوﻧﻲ‬ e-mail: Ikea_qatar@alfuttaim.com EGYPT : ‫اﻟﺨﻂ اﻟﺴﺎﺧﻦ‬ Hotline: 16576 : ‫ﻣﻮﻗﻊ...
  • Page 40 21552 © Inter IKEA Systems B.V. 2019 AA-2118277-1...
