Quick Start Guide
iE4P
Xiamen Hanin Electronic Technology Co.,Ltd.
ADD： 5F, 8#, Aide Airport Industrial Park, Huli District, Xiamen, China.
TEL： 400-806-9290
WEB： www.idprt.com
Packing List
Printer(eg:iD4P)
Label Roll
CD
USB Cable
Note: The packing materials are actually based on the order.
！
iE4S
AC Adapter
Power Cord
Quick Start Guide
Quick Start Guide
RibboRn
Appearance and Components
Front View(eg.:iE4P)
Display
Power Bu�on
Opera�on Keys
Printer Cover
Rear View
USB Port (Type A)
USB Port (Type B)
Note: The views above are for your reference. Ports vary by
！
your choice.
Inside View
Ribbon Supply Wheel
Moveable Roll Holders
Locking Tab
Moveable Label Guides
USB Connec�on
1.Connect the AC adapter to power receptacle.
2.Connect the power cord to AC adapter.
3.Connect the other end of power cord to the outlet.
1
Status Indicator
Feed Bu�on
Cover Open Levers
Serial Port
Power Receptacle
Ethernet Port
Printhead Module
Ribbon Supply Pin
Kick-stand Cover Lock
Label Sensor
Platen
2
3
Varies by regions
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for iDPRT iE4P
Summary of Contents for iDPRT iE4P
-
Page 1: Appearance And Components
Appearance and Components Front View(eg.:iE4P) Display Status Indicator Quick Start Guide Power Bu�on Feed Bu�on Opera�on Keys Cover Open Levers Printer Cover iE4P iE4S Rear View Serial Port USB Port (Type A) Power Receptacle USB Port (Type B) Ethernet Port Note: The views above are for your reference. -
Page 2: Loading The Media
Loading the Media 2.Pull the roll holders open and place the 3.Pass the labels through label guides 1.Pull and li� the cover. (eg:iE4P) roll between them, then press down the and adjust label guides to adapt to locking tab. the label width.
