6.0 ELECTRICAL CONNECTIONS

The NWB-DC+ Series dryers come from the factory
with all control circuits wired and a 10' power cord.
A quick-connect plug should be installed if moving
the NWB-DC+ to other process machines is antici-
pated.
CAUTION
• All electrical connections must be made by qualified
electricians, per national and local electrical codes.
• Disconnect and lock out the main power source before
making the electrical connection.
Turn the Main Disconnect on the electrical panel door to
the "OFF" position, lock out the main power source and
open the electrical enclosure. Per the electrical diagram,
install the main power wire to the main disconnect switch
holder and install the ground wire.
Total connected
Model
power KVA/AMPS
-25
-50
-75
-100
-150
-200
-300
Pro Motor
Hp/AMPS
9.0/10.8 .025/0.4
11.9/14.7 0.67/1.2
14.2/17.8 1.1/1.8
16.7/20.9 1.1/1.8
16.7/20.9 1.1/1.8
24.0/30.1 2.5/3.5
38.3/48.0 3.5/5.4
Full size electrical drawings are included with this
Instruction package for the voltage of the dryer you
ordered
NOTE: 3 Phase detection is included on this model. If
the connection is not correct, a pop-up alarm will appear
on the touch screen upon startup. You should immediate-
ly correct this condition.
NOTE: Please make sure all electrical connections are
tight. It is not common but a loose connection is possible
after a long truck ride.
Regular Motor
Hp/AMPS
.025/0.4
.025/0.4
.025/0.4
.025/0.4
.025/0.4
0.67/1.3
0.67/1.3
10
Regular Heater Pro Heater
Kw/AMPS Kw/AMPS
3.0/3.8 3.0/3.8
3.0/3.8 5.5/6.9
3.0/3.8 7.5/9.4
5.5/6.9 7.5/9.4
5.5/6.9 7.5/9.4
5.5/6.9 13.0/16.3
10.0/12.6 22.5/28.2
