Sensorless Vector Inverter
HF-520 series
No.D2301E-1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HF-520 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Sumitomo HF-520 Series

Summary of Contents for Sumitomo HF-520 Series

  • Page 1 U.S.A France Singapore Sumitomo Machinery Corporation of America SM-Cyclo France SAS (SMFR) Sumitomo (SHI) Cyclo Drive Asia Pacific Pte. (SMA) Ltd. (SCA) 8 Avenue Christian Doppler, 77700 Serris, France 4200 Holland Blvd. Chesapeake, VA 23323, U.S.A. 15 Kwong Min Road, Singapore 628718...

  • Page 2: Table Of Contents

    HF-520 series : The user friendly Sensorless Vector Control Drive! Powerful Inverter suitable for SUMITOMO Gearmotor Sensorless vector control allows for high starting torque. Deceleration time can be shortened by the overexcitation operation of braking function. This inverter is ideal for SUMITOMO Gearmotor operation.

  • Page 3: Note

    Power supply Output power 2 : 3-phase 200V A20 : 0.2kW 1A5 : 1.5kW 5A5 : 5.5kW HF520 : HF-520 series 4 : 3-phase 400V A40 : 0.4kW 2A2 : 2.2kW 7A5 : 7.5kW S : 1-phase 200V A75 : 0.75kW 3A7 : 3.7kW Gearmotor Product Lineup CYCLO®...

  • Page 4: Operation

    Operation Data Display Area LED Display (5-digit) Displays frequency, parameter number, and other data. LO/RE Selection Key Switch drive control between the LO/RE Lamp operator (LOCAL) and Light to indicate that the the control terminals (REMOTE). operator is set to LOCAL. ENTER Key ESC Key Select all modes, parameters,...
  • Page 5 Operation LED Operator Screen Structure Structure for LED Operator Drive Mode : Monitor the operation status of the drive (Frequency reference, Output frequency, Output current, Output voltage, etc.). < Frequency Reference Setting > Step Key Operation Display Step Key Operation Display Frequency Reference Tum the power on...

  • Page 6: Standard And Common Specifications

    Standard and Common Specifications Standard Specifications Item Specifications Input Voltage Class 3-phase 200V / 3-phase 400V / 1-phase 200V Applicable Motor (kW) 0.75 Input Voltage Class Model No. HF520 - 3-phase 200V HF5202- 3-phase 400V HF5204- 1-phase 200V HF520S- 200V class 12.6 Rated Output Capacity (kVA) 400V class...

  • Page 7: Standerd Connection Diagram

    Standard Connection Diagram Regenerative Braking Resistor DC Reactor (Option) (Option) Jumper Thermal Relay – B1B2 AC Reactor R/L1 U/T1 3 Phase Power Supply HF-520 S/L2 V/T2 200~240V 50/60Hz T/L3 W/T3 Fuse Forward Run/Stop 10Ω or less (400V class) 100Ω or less (200V class) Option Card Reverse Run/Stop Connector...

  • Page 8: Terminal Functions

    Terminal Functions Main Terminals Terminal Name Function R/L1 Connects line power to the drive. S/L2 Main circuit power supply input Drives with single-phase 200 V input power use terminals R/ L1 and S/L2 only. T/L3 must not be used. T/L3 U/T1 V/T2 Drive output...

  • Page 9: Applied Connection Diagram

    Applied Connection Diagram Operation by Current Signal (4-20mA) When terminal S5 is used as a current/Voltage signal (Frequency reference setting potentiometer) Changeover signal input. R/L1 U/T1 Power S/L2 V/T2 Supply T/L3 W/T3 (Note2) HF-520 Manual (Frequency setting) Current signal Ground Auto (Current signal) Stop Forword...

  • Page 10: Table Of Parameters

    Table of Parameters “S” in the “Control Mode” column indicates that the parameter is available in the Set up and Parameter mode. “ ” in the “Control Mode” column indicates that the parametr is available in the Parametr mode. “×” in the “Control Mode” column indicates that the parameter is not available in the Set up and Parameter mode . Control Mode Control Mode Function...
  • Page 11 Table of Parameters Control Mode Control Mode Function Name Range Def. * Function Name Range Def. * C6-01 Drive Duty Selection E1-09 Minimum Output Frequency 0.0 ~ E1-04 1.5 Hz C6-02 Carrier Frequency Selection 1 ~ B,F E1-10 Minimum Output Frequency Voltage 0.0 ~ 255.0 C6-03 Carrier Frequency Upper Limit 1.0 ~ 15.0...
  • Page 12 Table of Parameters Control Mode Control Mode Function Name Range Def. * Function Name Range Def. * F1-10 Excessive Speed Deviation Detection Level 0 ~ 50 × H3-16 Terminal A1 Offset -500 ~ 500 H3-17 Terminal A2 Offset -500 ~ 500 Excessive Speed Deviation F1-11 0.0 ~ 10.0...
  • Page 13 Table of Parameters Control Mode Control Mode Function Name Range Def. * Function Name Range Def. * L3-11 Ov Suppression Function Selection Speed Feedback Detection Control n2-01 0.00 ~ 10.00 × (AFR) Gain Overvoltage Suppression and Stall L3-17* 150 ~ 400 375 V Prevention Desired DC Bus Voltage Speed Feedback Detection Control...

  • Page 14: Outline Drawing

    Outline Drawing 4-M4 2-M4 Fig.A Fig.B Dimensions (mm) Input voltage Inverter model Drawing Approx.weight (kg) HF520S-A20 1-phase 200V class HF520S-A40 38.5 HF5202-A20 3-phase HF5202-A40 38.5 200V class HF5202-A75 58.5 Dimensions (mm) Input voltage Inverter model Drawing Approx.weight (kg) HF520S-A75 137.5 1-phase HF520S-1A5 200V class...

  • Page 15: Applicable Wiring For Accessories And Options

    Applicable Wiring for Accessories and Options Standard Accessories...

  • Page 16: Peripheral Equipment

    Peripheral Equipment Caution in Selecting Peripheral Equipment 1. Be sure to connect the power supply to RST (input terminals) and the motor to U, V, W (output terminals). Wiring and connection 2. Be sure to connect the grounding terminal. ( mark) Inverters generate high frequency, increasing leakage current.

  • Page 17: External Options

    External Options Frequency Reference Setting Unit No. VR07 ø3 ø9.5 Panel cut Bakelite plate (0.8t) Potentiometer 1kΩ,2W Panel Unit : mm Cable for Engineering Tool (Model No. WV103) Connection Method RJ45 Connector • Engineering Tool for PC (SDWP001) WV103(3 m) Note) 1.
  • Page 18 External Options LED Operator ICS-1 , 3 Dimensions for the panel cut JVOP-182-H M3 × 2 depth5 12.2 Model Cable length L(m) Unit : mm ICS-1 ICS-3 Unit : mm Regenerative Braking Resistor Braking resistor Rated Voltage Capacity Thermal relay Dimensions (mm) Weight Rated...
  • Page 19 External Options % Speed Meter: DCF-12NB Unit : mm 0-100% 50 divisions Part No. X525AA014 1mA F.S. X525AA048 10V F.S. AC Ammeter: ACF-12NB The CT directly detects the current of the secondary side of the inverter. ACF-12NB COMA-15 COM-15-26 Table of combination of AC ammeter (ACF-12NB) and current transformer 200V class 400V class Motor...
  • Page 20 External Options DC Reactor for Power Factor Improvement and Harmonics Suppression The DC reactor is available for improvement of the power factor of the inverter, ensuring power line impedance, and control of higher harmonics. Unit : mm Applicable Specification Part No. Connection Weight capacity...
  • Page 21 External Options Noise Filter 3-phase 200V class 3-phase 400V class Input side Output side Input side Output side Applicable motor Applicable motor (kW) (kW) Type Part No. Type Part No. Type Part No. Type Part No. 0.2, 0.4 CC3005C-P X480AC163 0.2 to 1.5 CC3005C-P X480AC163...
  • Page 22 External Options Zero-phase Reactor (Inductive Filter) Unit : mm Common to 200 V and 400 V classes, as well as input and output sides · 3.7 kW or less · 5.5 kW or more Part No. X480AC188 Part No. X480AC192 Type RC5078 Type...

  • Page 23: Notes To Inverter Users

    Notes to Inverter Users Measures to Take When Proximity Switch/photoelectric Switch, etc. Malfunction Take possible measures among the following in the order of 1 to 12. Each 5. Install a zero-phase reactor on the output side of the inverter. (Type: RC5078, RC9129) measure will improve noise reduction.
  • Page 24 Notes to Inverter Users Precautions for Application of Inverter Power supply 1. When the inverter is connected directly to a large-capacity power supply (especially in a 400 V line), excessively large peak will flow in, breaking the inverter unit. In such a case, install an AC reactor (option) on the input side of the inverter unit. 2.
  • Page 25 Notes to Inverter Users The inverter described in this brochure is used for variable-speed operation of 3-phase induction motors for general industry use. CAUTION The inverter described in this brochure is not designed and manufactured for use in equipment or a system used under the following conditions that will directly lead to death or injury : atomic energy control, aerospace equipment, trafic equipment, medical instrument and all kinds of safety devices.

  • Page 26: Selection Guide

    Selection Guide Selecting the Capacity (Model) of the Starting Characteristics When a motor is driven by an inverter, its operation is restricted by the Inverter inverter’s overload current rating, so the starting characteristic is different Selection from those obtained from commercial power supply operation. Capacity Although the starting torque is smaller with an inverter than with the Refer to the applicable motor capacities listed in the standard specifications.

  • Page 27: Warranty

    Warranty Warranty Policy on Inverter Warranty The warranty shall be 18 months from date of shipment or 12 months after intial operation, whichever is shorter. period In the event that any problem or damage to the Product arises during the "Warranty Period" from defects in the Product whenever the Product is properly installed and combined with the Buyer's equipment or machines maintained as specified in the maintenance manual, and properly operated under the conditions described in the catalog or as otherwise agreed upon in writing between the Seller and the Buyer or its customers;...
