SWIMMING POOL
& SPA HEAT PUMPS
INSTALLATION MANUAL
Model
Specifications may change without notice.
© 2008 Aquatherm Heat Pumps, A Division of Calorex USA LLC
AT550
w/Titanium Heat
Exchanger
HEAT PUMP
NOTICE:
HEAT PUMPS
a Division of Calorex USA L.L.C.
2213 Andrea Lane Ft. Myers FL 33912
888-297-3826 239-482-0606
www.aquathermheatpumps.com
WATER
FILTER
PUMP
Jandy™
3-Way Valve
VERTICAL
CHLORINATOR
LOOP
SPA
POOL
SPA
POOL
TO
SPA JETS
FROM
TO SPA
SPA
SPILLOVER
SUCTION
FROM
CHLORINATOR
POOL
FLOOR
TO POOL
SUCTION
RETURN
FROM
POOL
SKIMMER
SUCTION
M E M B E R
NATIONAL SPA &
POOL INSTITUTE
