- Page 1 6302 8646 – 03/2003 GB For heating engineers Installation instructions xM10 function modules for Wall-mounted and floor-standing boilers, and wall mounting Please read carefully prior to installation.
- Page 2 Please let us know if you have any suggestions which would improve our documentation or if you have noticed any errors. We reserve the right to make any changes due to technical modifications. Buderus Heiztechnik GmbH • http://www.heiztechnik.buderus.de Installation instructions xM10 function modules • Issue 03/2003...
-
Page 3: Table Of Contents
........17 We reserve the right to make any changes due to technical modifications. Buderus Heiztechnik GmbH • http://www.heiztechnik.buderus.de Installation instructions xM10 function modules • Issue 03/2003... -
Page 4: Safety
Correct use The xM10 function modules must only be used in combination with the energy management system (EMS) from Buderus and components thereof. The wall-mounted version of the function module has protection class IP 40, which means that it must not be installed in any area where there is risk of water spray. -
Page 5: Please Observe These Notes
! The relevant legal requirements must always be observed WARNING! when working on electrical installations. PLEASE NOTE Only use original Buderus spare parts. Losses caused by the use of spare parts not supplied by Buderus are excluded from the Buderus warranty. Disposal Dispose of defunct function modules in an environmentally acceptable manner, through an approved organisation. -
Page 6: Product Description
(Fig. 1, Item 5) the rotary encoder is set to position 2 (corresponding to heating circuit 2). We reserve the right to make any changes due to technical modifications. Buderus Heiztechnik GmbH • http://www.heiztechnik.buderus.de Installation instructions xM10 function modules • Issue 03/2003... -
Page 7: Wall-Mounted Boilers
(Fig. 2, Item 3. We reserve the right to make any changes due to technical modifications. Buderus Heiztechnik GmbH • http://www.heiztechnik.buderus.de Installation instructions xM10 function modules • Issue 03/2003... - Page 8 Low-voltage terminals (e. g. for bus system or temperature sensors) Item 5: Bus cable (in cable harness) We reserve the right to make any changes due to technical modifications. Buderus Heiztechnik GmbH • http://www.heiztechnik.buderus.de Installation instructions xM10 function modules • Issue 03/2003...
- Page 9 We reserve the right to make any changes due to technical modifications. Buderus Heiztechnik GmbH • http://www.heiztechnik.buderus.de Installation instructions xM10 function modules • Issue 03/2003...
- Page 10 ! Tighten the cross-head screws (Fig. 4, Item 3) either with a cross-head screwdriver or with a bleed key. ! Close the boiler casing. We reserve the right to make any changes due to technical modifications. Buderus Heiztechnik GmbH • http://www.heiztechnik.buderus.de Installation instructions xM10 function modules • Issue 03/2003...
- Page 11 ! You should also check that the system conditions are set correctly in the control unit. We reserve the right to make any changes due to technical modifications. Buderus Heiztechnik GmbH • http://www.heiztechnik.buderus.de Installation instructions xM10 function modules • Issue 03/2003...
-
Page 12: Floor-Standing Boilers
! Remove the cover by pulling it upwards in the direction indicated by the arrow. We reserve the right to make any changes due to technical modifications. Buderus Heiztechnik GmbH • http://www.heiztechnik.buderus.de Installation instructions xM10 function modules • Issue 03/2003... - Page 13 ! Isolate the heating system from the mains supply using the WARNING! emergency stop switch or by extracting the mains fuse. We reserve the right to make any changes due to technical modifications. Buderus Heiztechnik GmbH • http://www.heiztechnik.buderus.de Installation instructions xM10 function modules • Issue 03/2003...
- Page 14 ! Carefully connect other components to terminals (Fig. 7, Item 3 and 4) on the function module in accordance with the connection diagram. We reserve the right to make any changes due to technical modifications. Buderus Heiztechnik GmbH • http://www.heiztechnik.buderus.de Installation instructions xM10 function modules • Issue 03/2003...
- Page 15 ! Carefully connect other components to the terminals on the function module in accordance with the connection diagram. We reserve the right to make any changes due to technical modifications. Buderus Heiztechnik GmbH • http://www.heiztechnik.buderus.de Installation instructions xM10 function modules • Issue 03/2003...
- Page 16 ! You should also check that the system conditions are set correctly in the control unit. We reserve the right to make any changes due to technical modifications. Buderus Heiztechnik GmbH • http://www.heiztechnik.buderus.de Installation instructions xM10 function modules • Issue 03/2003...
-
Page 17: Wall Mounting
! Insert wall plugs in the holes and screw in the screws provided (Fig. 9, Item 2) until their heads are 5 mm proud of the wall. We reserve the right to make any changes due to technical modifications. Buderus Heiztechnik GmbH • http://www.heiztechnik.buderus.de Installation instructions xM10 function modules • Issue 03/2003... - Page 18 ! First fit the bottom of the function module (Fig. 10, Item 1 in the wall holder and get it to engage on the lock (Fig. 10, Item 2). We reserve the right to make any changes due to technical modifications. Buderus Heiztechnik GmbH • http://www.heiztechnik.buderus.de Installation instructions xM10 function modules • Issue 03/2003...
- Page 19 Item 5: Low-voltage terminals (e. g. for bus system or temperature sensors) Item 6: Bus cable We reserve the right to make any changes due to technical modifications. Buderus Heiztechnik GmbH • http://www.heiztechnik.buderus.de Installation instructions xM10 function modules • Issue 03/2003...
- Page 20 A mains connection via a plug with an earth conductor is not permissible. We reserve the right to make any changes due to technical modifications. Buderus Heiztechnik GmbH • http://www.heiztechnik.buderus.de Installation instructions xM10 function modules • Issue 03/2003...
- Page 21 ! Tighten the cross-head screw (Fig. 12, Item 2 either with a cross-head screwdriver or with a bleed key (Fig. 12, Item 1). We reserve the right to make any changes due to technical modifications. Buderus Heiztechnik GmbH • http://www.heiztechnik.buderus.de Installation instructions xM10 function modules • Issue 03/2003...
- Page 22 ! You should also check that the system conditions are set correctly in the control unit. We reserve the right to make any changes due to technical modifications. Buderus Heiztechnik GmbH • http://www.heiztechnik.buderus.de Installation instructions xM10 function modules • Issue 03/2003...
- Page 23 Notes We reserve the right to make any changes due to technical modifications. Buderus Heiztechnik GmbH • http://www.heiztechnik.buderus.de Installation instructions xM10 function modules • Issue 03/2003...
