- Page 1 Personal OPERATING INSTRUCTIONS REFERENCE NUMBER: 00949 GB COPYRIGHT© PHYSIOMED ELEKTROMEDIZIN AG...
- Page 2 Distribution, reproduction and translation of the software and its documentation (or excerpts thereof) are prohibited without the prior written consent of PHYSIOMED ELEKTROMEDIZIN AG. PHYSIOMED ELEKTROMEDIZIN AG reserves the right to change the software and associated data as well as the documentation without notice. All other rights reserved.
-
Page 3: Table Of Contents
Table of Contents PHYSIOMED ELEKTROMEDIZIN AG Table of Contents Chapter 1 Introduction ........1 1.1 Conventions Used . - Page 4 Table of Contents PHYSIOMED ELEKTROMEDIZIN AG Appendix A Appendix ........18 A.1 Service, Repairs, Maintenance .
-
Page 5: Chapter 1 Introduction
1 Introduction PHYSIOMED ELEKTROMEDIZIN AG Chapter 1 Introduction ® With DEEP OSCILLATION Personal you have acquired an extremely versatile deep oscillation system. The instrument will only show its true potential, however, if you are well informed about its functions. For this reason, carefully read these Operating Instructions and familiarise yourself with the use of the instrument. -
Page 6: Instrument Overview
1 Introduction PHYSIOMED ELEKTROMEDIZIN AG 1.3 Instrument Overview Front Panel Rear Face (Back Cover removed) Legend Display Card Reader Data Selector Battery Compartment Ports Control Light Charger Socket ® DEEP OSCILLATION Personal... - Page 7 1 Introduction PHYSIOMED ELEKTROMEDIZIN AG Rear Face (with Back Cover) Carrying Case (Front and Rear Face) Bottom ® DEEP OSCILLATION Personal...
-
Page 8: Symbols In The Display
1 Introduction PHYSIOMED ELEKTROMEDIZIN AG 1.4 Symbols in the Display You find the following symbols in the Display <1>: Battery Indicator (refer to Battery Operation on page 8) Setup Menu (refer to Basic Settings on page 19) Confirm Settings Contrast of the Display <1> (refer to... -
Page 9: Contraindications
1 Introduction PHYSIOMED ELEKTROMEDIZIN AG • muscle relaxation • pain reduction • edema reduction • inhibition of inflammations • enhancement of wound healing 1.7 Contraindications ® Therapy with DEEP OSCILLATION Personal is not indicated in the following cases: • acute infections •... -
Page 10: Chapter 2 Controls And Indicators
2 Controls and Indicators PHYSIOMED ELEKTROMEDIZIN AG Chapter 2 Controls and Indicators ® The design of DEEP OSCILLATION Personal allows for easy operation, in combination with a variety of functions. Because of its small size, the instrument is very easy to transport. It has been designed for oper- ation also outside of therapy rooms, and is fed by rechargeable batteries for that reason. -
Page 11: Ports <3
2 Controls and Indicators PHYSIOMED ELEKTROMEDIZIN AG 2.1.3 Ports <3> The Ports <3> serve to connect the supplied cables for the hand applic- ator and the adhesive or neutral electrode with the instrument. You can find instructions on how to connect the cables in section to Prepare Treatment on page 15. -
Page 12: Chapter 3 Instrument Operation
3 Instrument Operation PHYSIOMED ELEKTROMEDIZIN AG Chapter 3 Instrument Operation 3.1 Battery Operation ® DEEP OSCILLATION Personal uses rechargeable 1.2 V AA NiMH batteries for power supply, which allow for operation independently from the mains. In order to ensure a long life, the battery must be charged completely when first charged. The first char- ging procedure should not be interrupted. -
Page 13: Battery Charger
3 Instrument Operation PHYSIOMED ELEKTROMEDIZIN AG If the unit is not used for a longer period of time, please fully charge the battery at least once every two months. This will help to avoid exhaustive discharge, which may permanently affect the battery life, not enabling it to be recharged;... -
Page 14: Economy Mode
3 Instrument Operation PHYSIOMED ELEKTROMEDIZIN AG Mode Green Maintenance charge mode Flickering orange - green alternately Error The Instrument Should not Be Stored with the Charger Plugged in If the instrument is stored with a plugged in charger, the battery discharges faster, since a dis- charge current also flows through the charger. -
Page 15: Preparations And Start-Up
3 Instrument Operation PHYSIOMED ELEKTROMEDIZIN AG 3.2 Preparations and Start-Up How to Start up the Instrument Press the Data Selector <2> for one second. You will hear an acoustic signal and the Display <1> is illuminated. The message No CARD available in the unit! Please insert CARD. is displayed. -
Page 16: Cable Check
3 Instrument Operation PHYSIOMED ELEKTROMEDIZIN AG 3.4 Cable Check If you should have the impression that a cable is defective during treatment, you can check it using the in- strument. How to Check a Cable Select a therapy and set the intensity to 100% using the Data Selector <2>. -
Page 17: Therapy Card
Caution The treatment card must not be copied, and any attempt to reproduce it or read out the data will invalidate it! PHYSIOMED ELEKTROMEDIZIN AG accepts no responsibility for damage in- curred in this way! ®... -
Page 18: Instrument Errors
3 Instrument Operation PHYSIOMED ELEKTROMEDIZIN AG 3.7 Instrument Errors If a functional error is detected during the automatic selftest routine or operation, one of the following er- ror codes is shown on the Display <1>: • ERROR_01 ... ERROR_05 In this case, treatment is automatically interrupted. Switch off the instrument by pressing the Data Select- or <2>... -
Page 19: Chapter 4 Treatment
4 Treatment PHYSIOMED ELEKTROMEDIZIN AG Chapter 4 Treatment ® With DEEP OSCILLATION Personal you can perform treatments according to preset indications which are stored together with the corresponding therapy parameters on the therapy card. For each displayed indic- ation you can refer to the recommended therapy instructions. Each indication features an image of a body region to be treated, which shows the preferable direction of treatment. - Page 20 4 Treatment PHYSIOMED ELEKTROMEDIZIN AG Therapy Instructions - Text Rotate the Data Selector <2> until the symbol flashes. An image showing a body area to be treated as well as the treatment direction is displayed. Therapy Instructions - Image Click the symbol.
- Page 21 4 Treatment PHYSIOMED ELEKTROMEDIZIN AG Important You have to choose the intensity according to the minimum dose principle, i.e. in the lower effective range! The hand applicator should stay in contact with the patient's skin and should be moved on the body surface without lifting or stopping.
-
Page 22: Appendix A Appendix
The manufacturer guarantees the safety of the instrument only in its original state. The instrument must be operated in accordance with the Operating Instructions. Repairs to the instrument may only be performed by parties duly authorised by PHYSIOMED ELEKTROMEDIZIN AG. Any repairs performed by an authorised agent must be accompanied by written certification, describing the nature and extent of the repairs undertaken, as applicable with details regard- ing changes to nominal operating values or the operational range. -
Page 23: Electromagnetic Compatibility
Appendix PHYSIOMED ELEKTROMEDIZIN AG A.4 Electromagnetic Compatibility Declaration in accordance with standard EN 60601-1-2: Electromagnetic compatibility Medical electrical devices are subject to particular precautions regarding electromagnetic compatibility and must be used in accordance with the instructions on electromagnetic com- patibility contained in the accompanying documents. -
Page 24: Technical Data
Appendix PHYSIOMED ELEKTROMEDIZIN AG A.6 Technical Data Treatment Protection Class according to IEC 60601-1 Internal Power Supply, Type BF Charging Protection Class according to IEC 60601-1 Input Voltage 7.2 VDC (4 cells) Input Current 1.3 ADC General Technical Data CE label acc. -
Page 25: Training
PHYSIOMED ELEKTROMEDIZIN AG A.7 Training As a manufacturer we have to offer trainings on the instrument. The operating instructions are used as training material. Please submit your requests for trainings to the manufacturer, PHYSIOMED ELEKTROMEDIZIN AG, Hutweide 10, 91220 Schnaittach/Laipersdorf (Germany). ®... -
Page 26: Appendix B Scope Of Delivery And Accessories
Scope of Delivery and Accessories PHYSIOMED ELEKTROMEDIZIN AG Appendix B Scope of Delivery and Accessories Important For safety reasons, the instrument is to be used exclusively with original accessories. The use of other manufacturers' accessories is at the user's risk! B.1 Scope of Delivery... - Page 27 Scope of Delivery and Accessories PHYSIOMED ELEKTROMEDIZIN AG Ref.-No. Designation ® 00261 Connection Cable DEEP OSCILLATION 00393 Membrane Set 1.5 cm 00391 Membrane Set 5 cm 00392 Membrane Set, 9.5 cm 00383 NiMH Rechargeable Battery, size AA, 1.2 V (Package, 4 Items) 00387 Oscillator Head 1.5 cm...
-
Page 28: Appendix C Supplementary Documents
Supplementary Documents PHYSIOMED ELEKTROMEDIZIN AG Appendix C Supplementary Documents C.1 Manufacturer's Recommendations ® DEEP OSCILLATION Personal... -
