Weil-McLain 2 Series Manual
  1. Manuals
  2. Brands
  3. Weil-McLain Manuals
  4. Boiler
  5. HE (Series 2)
  6. Manual

Weil-McLain 2 Series Manual

Commercial condensing gas-fired water boilers
Hide thumbs Also See for 2 Series:

Advertisement

Quick Links

Download this manual See also: User's Information Manual, Manual
Boiler Manual
This manual must only be used by a qualified heating installer/service technician. Read all instructions, including this manual and all other
information shipped with the boiler, before installing. Perform steps in the order given. Failure to comply could result in severe personal injury,
death or substantial property damage.
DO NOT operate the boiler during construction
free area. The boiler can be severely damaged by drywall dust or other combustion air contaminants.
Models 1000 - 2000 MBH
Commercial Condensing
Gas-fired water boilers
• Installation
• Startup
unless combustion air is piped to the boiler air inlet from a dust-free and contaminant-
Series 2
• Maintenance
• Parts
Part number 550-100-180/0917
®
