Comfort, Quality & Style Since 1998
Sedona Rectangular LPG Fire Pit
INSTALLATION PRECAUTION:
This fire pit requires a minimum 18 inches of cross
ventilation in all directions. Failure to provide proper
ventilation can void the warranty.
ATTACH YOUR RECEIPT HERE
Keep a copy of your proof of
which will be needed if you need to
contact us about warranty coverage.
Purchase Date:
Questions, problems, missing parts?
Before returning to your retailer, our exceptional customer service is available.
Call toll-free (866) 985-7877 9 a.m. – 9 p.m., EST.
Email us
Live chat
cservice@welltraveled.net
www.wtliving.com. 9 a.m. – 4 p.m., EST., Monday – Friday.
Item #: 61860
Burner #: ULC-PC75-H-E
WARNING
FOR YOUR SAFETY
1. Improper installation, adjustment,
alteration, service or maintenance can
cause injury or property damage.
2. Read the installation, operation, and
maintenance instructions thoroughly
before installing or servicing this
equipment.
3. Failure to follow these instructions
could cause property damage, personal
injury, or death.
WARNING
For Outdoor Use Only
WARNING
This product can expose you to chemicals including
Carbon Monoxide, Lead, Chromium (hexavalent
compounds), Di(2-ethylhexyl) phthalate (DEHP) and
Diisononyl phthalate (DINP), which are known to the
State of California to cause cancer and birth defects
or other reproductive harm. For more information,
go to www.P65Warnings.ca.gov.
09232019
