Command access VLP-M-KIT Installation Instructions page 5

• Replace push pad by placing over
activating arms & pushing down then
back towards end of device.
• Replace bracket & attach (2) screws with 5/16
nut drive or flat head screw driver.
Screws
• Replace head cover & (4) head
cover screws if present.
3
1
Head cover
2
Step 1
Press the device push pad to the desired setting. (this can be fully
-
depressed or less than fully depressed).
Step 2 While depressing the push pad, apply power. (i.e. presenting the
-
credential to the reader).
Step 3 Continue to keep pad depressed, the device will beep 6 times. After the
-
beeps have stopped, release the pad and now the adjustment is complete.
If not to your liking repeat the three steps. That's all there is to it.
Push pad
Bracket
4
S
etting
• Slide baseplate back into case being
careful of motor wires.
• Replace mounting bracket.
Bracket
• Depress push pad & set PTS adjustment.
PtS
Case
5
