- Page 1 Technical Documentation PORTEO reddot design award geprüfte achieved for: Sicherheit winner 2005 Ease of Use www.dorma.com/porteo...
- Page 2 PORTEO –the door assistant Applications that adds convenience to doors Interior doors, single-leaf ≤1100 mm Door leaf width The PORTEO offers an inno- The PORTEO can be further Door leaf weight, max. 80 kg vative and convenient way to functionalised with original...
- Page 3 PowerLess Position Push&Go – Standard lock Once door opened manually 3°, automatic – Lever handle door opening function initiated. PORTEO then closes the door again automatically after pre-set hold-open time. Opening and closing time adjustable. PowerMotion...
- Page 4 PORTEO Application and installation Transom-fixed, pull side (Example refers to left-hand (ISO 6) door; mirror image applies to right-hand (ISO 5) door) max. 3 Transom-fixed, push side (Example refers to left-hand (ISO 6) door; mirror image applies to right-hand (ISO 5) door) max.
- Page 5 Type 500 flexible cable conduit 4 x 0,8 mm NYM 3 x 1,5 mm PORTEO 10 A The safe and reliable solution from DORMA for protecting the cables required for door-leaf fixing. 1 Power feeder, permanent connection 2 2-pole-and-earth socket...
- Page 6 PORTEO Accessories Mounting backplate 30 mm or 40 mm For fixing the slide channel to door frames for which direct installation is not possible. Ø 5,5 Angle bracket For fixing the slide channel to door frames with a deep top jamb, for push-side transom fixing.
- Page 7 15180224 19144701170 16562101170 16562301170 Colour Silver White (sim. to RAL 9016) 11 Specification text for the DORMA PORTEO Door Assistant Electro-mechanical door Door parameters Model particulars Tested according to the 2 Single-leaf interior doors, Y Complete package inclu- assistant operating in low- “Guidelines for Powered...
- Page 8 DORMA worldwide Central Europe Gulf DORMA GmbH + Co. KG DORMA Gulf Door Controls FZE Jebel Ali Free Zone South Breckerfelder Str. 42– 48 D-58256 Ennepetal Plot No. S 20135 Phone +49 2333 793-0 Road No. SW 301 G +49 2333 793-495 P.O.
