- Page 1 INSTALLATION MANUAL AVANT Audiometry & Binaural REM/LSM in One System www.medrx-int.com...
-
Page 2: Table Of Contents
Contents Getting to Know Your AVANT ARC ......................Computer Requirements ..........................Transducers & Accessories ..........................Probe Mic Hanger Installation ........................Software Installation ............................Connecting the Device ..........................15 Loading Calibration Files ..........................18 EMC Precautions .............................. 19 Safety ..................................22 Cleaning ................................ -
Page 3: Getting To Know Your Avant Arc
ANSI S3.46-1997 and IEC 61669:2001. These standards specify the required precision that the Avant ARC does achieve. The AVANT ARC is an electronic instrument intended for the testing of human hearing using both tone and speech audiometry. This device meets the specifications and tolerances for... -
Page 4: Computer Requirements
Computer Requirements MedRx Minimum Computer Specs: Windows®-PC compatible computer Intel™ i5 Dual Core, 2.0 GHz or better 4 GB RAM 20 GB free hard drive space Available 2.0 USB port Windows 7, 8 or 10 Professional (32 or 64-bit) MedRx Recommended Computer Specs: Windows®-PC Computer... - Page 5 Avant ARC Bottom View Notice! The Red & Blue adapters are included and must be removed to attach 18 gage (1.0mm) Free Field speaker wires and then reinstalled. DC Power supply must be used when using passive Free Field speakers.
-
Page 6: Transducers & Accessories
Transducers and Accessories Use the accessories provided with your Avant ARC. Use of unapproved accessories is not recommended Supra-Aural IP30 Insert Earphones Bone Conductor Patient Response Headphones Optional (Standard) Switch Operator Mic & Talkback Microphone Client Headset 3A Insert Earphones... -
Page 7: Probe Mic Hanger Installation
Probe Mic Hanger Installation You will need the two Probe Mics, the Probe Install the hook on the Pull hook down to Mic Hanger and the Clip back side of probe mic seat on post Once Installed the large O-ring should be Gently press clip into place. - Page 8 Probe Mic Hanger installation assembly complete. D-0123006-B 05/2019...
-
Page 9: Software Installation
Software Installation 1. Insert the MedRx USB Flash Drive into USB port: • Launch My Computer • Locate USB Drive (E:) may vary depending on the USB port selected. Consult your computer’s documentation. 2. Double Click on Setup to launch: •... - Page 10 4. This is the Welcome screen. • To continue, click Next. 5. Read the Software License Agreement. This important document defines the acceptable usage of the ARC Audiometer software. • Select Accept. • Click Next. 6. This screen sets the language and location choice.
- Page 11 7. This screen indicates the location of the program files. The default location is recommended for most users. If necessary, this location can be changed. • To continue with the default settings, click Next. NOTE: To change the location of the files (advanced users or system administrators only), click Change.
- Page 12 10. When the installation is complete. Click Finish. Installing REM Software 1. On the Setup screen, choose Install Avant REM. 2. Wait for the program to setup the InstallShield Wizard. 3. This is the Welcome screen. • To continue, Click Next. D-0123006-B 05/2019...
- Page 13 4. Read the Software License Agreement. This important document defines the acceptable usage of the Avant REM Software. • Click I accept. • Click Next. 5. This screen indicates the location of the program files. The default location is recommended for most users. If necessary, this location can be changed.
- Page 14 7. Installation of Program is ready to start. • Install. To continue, Click To make changes, Click Back. • 8. Wait while the InstallShield Wizard installs the Avant program. • Click Next. 9. When the installation is complete, • Click Finish. D-0123006-B 05/2019...
-
Page 15: Connecting The Device
Connecting Device Your AVANT ARC is USB powered. Connect the USB cable from the AVANT ARC to your computer as shown below. Wait for the system to copy and install default Windows drivers. When this screen appears and all devices are “Ready to use”, Click Close. - Page 16 Output and Input Device Tab. 4. Click Audio Properties. In the Windows Sound control panel, make sure the MedRx Audio Device is not set as default. If its the default, change this by clicking on your system audio device (non-MedRx) and then choose Set Default.
- Page 17 3. Open Audio–A tab. 4. When the audio properties are configured properly, during driver installation, the Audio Tab will appear like the image on the left. If not, use the pull-down lists to adjust the settings to match the image. 5.
-
Page 18: Loading Calibration Files
The final step before using your AVANT evaluate hearing is to load these device specific calibration files onto the computer used to operate the AVANT device. 1. With the MedRx USB Flash Drive connected, open the AVANT software and Click: • Function. • Calibrate. -
Page 19: Emc Precautions
• Guidance and manufacturer’s declaration – electromagnetic emissions The Avant ARC is intended for use in electromagnetic environment specific below. The customer or the user of the Avant ARC should assure that it is used in such an environment. Emission test... - Page 20 Guidance and manufacturer’s declaration – electromagnetic immunity The Avant ARC is intended for use in electromagnetic environment specific below. The customer or the user of the Avant ARC should assure that it is used in such an environment. IEC 60601...
- Page 21 If the measured field strength in the location in which the Avant ARC is used exceeds the applicable RF compliance level above, the Avant ARC should be observed to verify normal operation. If abnormal performance is observed, additional measures may be necessary, such as reorienting or relocating the Avant ARC.
-
Page 22: Safety
Proper disposal may require that it be sent to collection facilities for recovery and recycling. • All repairs should be sent to MedRx for evaluation and / or repair. However, necessary diagrams and repair instruction will upon request be provided to authorized repair personnel. -
Page 23: Cleaning
Symbols that may be used: or SN Read the instruction manuals Indicates that the device serial Type B applied part. (Type B Manufacturer (MedRx) for safe usage of the device. number will follow equipment) (operating instructions) Authorized Representative in Non-ionizing electromagnetic... -
Page 24: Permissions (Optional)
The default user settings are typically sufficient for regulatory bodies. These settings can be also adjusted if needed to comply with country requirements. MedRx Avant software does not store private information. Data control is performed by the office management system or patient management system (i.e. Noah, Blueprint, Sycle). - Page 25 Adjusting log out time period Create user settings to lock the computer when not in use. Navigate to local security policy and adjust the Amount of idle time required before suspending session. Adjusting this setting will prevent unintended access to the computer and health records. Setting maximum password age Local Security Policy will also identify the required password expiration timeframe.
-
Page 26: Technical Information
Technical Information The Avant ARC Audiometer/REM Combination is an active, diagnostic Class IIa Medical Device according to the EU medical directive 93/42/EEC. Standards: Modulation: IEC 60601-1 class II, protection class B Pulse tone: 0.25/0.5 s on time IEC 60645-1 -2 Warble tone: 5% sinus frequency modulation, ANSI S3.6-2010 : Type 2 AE... - Page 27 Calibration values and Max Levels: Calibration values and Max Levels: Headphone DD45 Headphone TDH39 NBS-9A acoustic coupler NBS-9A acoustic coupler Force 4-5 N, ANSI and IEC Force 4-5 N, ANSI and IEC DD45 RETSPL Values RETSPL dB re RETSPL dB re 20μPa 20μPa 125=45.0...
- Page 28 Calibration values: Calibration values: Bone conductor Sound field (0 degree incidence) Radioear B71 Force: 4.9 ... 5.9 N Reference equivalent threshold sound pressure level Mastoid placement – ANSI S3.13 coupler RETSPL dB Air Radiation mean /maximum 125=22.1 250=11.4 RETFL dB re1 N 500=4.4 125=82.5 750=2.4...
-
Page 29: Limited Warranty
Congratulations Your MedRx system is now set up and ready for use. Please consult the Training Manual and the Interactive Help Files within the software for instructions and procedures. The Training Manual is available in PDF format on a USB flash drive and at www.medrx-int.com in our Download Section.
