i-ALERT® Gateway Installation Guide
2 System View
2.1 Gateway Interface
The gateway interface points are shown in Figure 1:
1. Plug 1 is an expansion plug allowing an additional gland or conduit fitting to be added
2. Plug 2 is the gland for the power input cable
3. Plug 3 is a water tight air exchange vent
4. Plug 4 is the Cellular SIM card access plug
3. IP67/IP68 Rated
Hole Plug
3. IP67/IP68 Rated
Gland
Figure 1: i-ALERT2® Gateway Interface Ports
4. SIM Card
3. IP67/IP68 Rated
Air Vent
5/13
