HBA Features and Specifications

The Sun StorageTek 8 Gb FC PCI-Express HBA, Emulex (single port: SG-XPCIE1FC-
EM8-Z, dual port: SG-XPCIE2FC-EM8-Z) consists of a single-wide, FC bus expansion
board. The board interfaces a four- or eight-lane PCI-Express bus, with the four or
eight lanes supporting one or two Fibre Channel (FC) optical media ports. Each
independent FC port operates at 8 Gbit/sec and features 8/4/2 autonegotiation.
See
TABLE 1-1
HBA Features and Specifications
TABLE 1-1
Feature
PCIconnector
PCI signaling environment
PCI lane usage
PCItransfer rate
(maximum)
Number of FC ports
Number of devices
supported
FC bus type (external)
FC transfer rate
FC topologies
RAM
BIOS ROM (FC)
NVRAM
External connectors
2 Sun StorageTek 8 Gb FC PCI-Express HBA, Emulex Installation Guide • December 2008
for a list of the HBA features.
Description
x8
PCI Express x8 (8 active lanes)
x8 lanes
PCI Express Generation One (GT/s) x8
PCI Express Generation Two (5.0 GT/s) x8
One (single port) or Two (dual port)
126 devices per FC loop; 510 devices in Fabric mode
Fiber-optic media, short-wave, multi-mode fiber (400-M5- SN-S)
400 MBps per port maximum, half-duplex
800 MBps per port maximum, full-duplex
Switched fabric (N-Port), arbitrated loop (NL-Port), and point-to-point (N-Port)
1.5 MB, parity protected, per port
One 4-MB (dual-port) or 2-MB (single-port) flash ROM
One 2-KB EEPROM per port
One Small-Form Factor Pluggable (SFP) multimode optic with LC-style
connectors per port
