e-Keying Ports

The AMC.1-HDD SAS disk connects up to two SAS ports on the AMC connector.
These ports are defined by the AMC.3 specification for serial storage. The module
designates four PCI Express ports, per AMC.1 specification. The link type and link
type extension are defined in the following table.
TABLE 0-1
Port # Port Name
0
1
2
3
4-7
4
8-20
AMC e-Keying Port Assignments
Unused
Unused
Channel 0
Channel 1
Channel 2
Channel 3
Unused
Link Type
Link type 7 = AMC.3
storage,
Link type extension = 2
(SAS and SATA)
AMC asymmetric match =
00b (SAS)
Link type 7 = AMC.3
storage,
Link type extension = 2
(SAS and SATA)
AMC asymmetric match =
00b (SAS)
Link type 2 = AMC.1 PCI
Express typ e = 4
Like type 2 = AMC.1 PCI
Express type 1
Appendix A
AMC Port Map Region
Common options
Common options
Common options
Connectors and Ports A-5
