e-Keying as described in the AMC.0 specification
■
FRU information
■
LED indicators for hot-swap and OOS (out of service)
■
2.2.6

Port Connectors

The AMC includes connectors to communicate with the host board and take its
interfaces outside the ATCA chassis. Refer to
descriptions and pin-outs.
2.2.7

LEDs

The AMC.1-HDD SAS disk has three LEDs. See the next section for a detailed
description of the LEDs.
2.3

Faceplate and LEDs

The faceplate of the AMC.1-HDD SAS disk has three LED indicators, which are
described in the table following the faceplate illustration.
Note – The AMC is available in different capacities (in gigabytes). The illustration
shows a generic faceplate. For your product's faceplate, the xxx denotes the capacity.
FIGURE 2-2
Faceplate
Appendix A for complete connector
Chapter 2 Overview 2-5
