Installation Instructions
Layout Details
Short twisted ladder
Low tower
3.4m single slide
General Installation Instructions
1 Read instructions thoroughly before commencing installation of unit. For additional instruction
on each unit see appropriate sheets attached.
2 Note:- In accordance with 6.1.3 EN1176-1:2008 we recommend that slides do not face south
or near due south due to heat build up.
3 Excavate foundations as shown in the foundation plan.
Note:- 1. Ensure all installation aids are removed before first use.
2. Lifting Equipment or sufficient manpower should be used throughout installation.
Issue Date:
801-ESCL REV 2 07/05/15
Castle Range
Esclabor
PROD. CODE
SIZE
AGE RANGE
F/ FALL HEIGHT
HEAVIEST PART
TOTAL WEIGHT
Low Scramble Net
Low fireman's pole
Climbing bridge
801-ESCL
3610x4400x2515
8 Years to Adult
1110mm
See Attached
See Attached
Low tower
Page 1 of 3
