YOUNG EXPLORER
600 RALEIGH
PROD. CODE
RALEI06
SIZE
L:3.89M W:2.8M H:2.2M
FFH
0.6M
AGE RANGE
3-7 YEARS OLD
INSTALLATION DETAILS
1. READ INSTALLATION INSTRUCTIONS THROUGHLY BEFORE COMMENCING INSTALLATION OF UNIT
2. EXCAVATE FOUNDATIONS USING THE DETAIL AS SHOWN ON PAGE 2 OF THIS DOCUMENT
3. ENSURE TO CHECK AND TIGHTEN ALL FIXINGS USING PROTECTIVE CAPS WHERE NECESSARY
4. BACKFILL FOUNDATIONS WITH
5. REMOVE ALL ASSEMBLY AIDS BEFORE THE EQUIPMENT IS USED
THIS PRODUCT CONFORMS WITH BS EN1176- :2008
Wicksteed Leisure Ltd, Digby Street, Kettering, Northants NN16 8YJ Tel: 01536 517028 Fax: 01536 410633
0.064
CUBIC M CONCRETE ALLOWING TO SET FOR 48 HOURS
1
& BS EN1176-3:2008
www.wicksteed.co.uk E:sales@wicksteed.co.uk
No part of this document may be copied or used without the express written permission of WICKSTEED LEISURE LTD (c) 2014
TECHNICAL DATA
MINIMUM SPACE REQUIRED
SUPERVISED PLAY
EQUIPMENT TYPE
LARGEST PART
HEAVIEST PART
6.9M X 5.48M
RECOMMENDED
LOW LEVEL
2.8M X 0.125M (FRTB01340)
45KG (DECK ASSY)
Version:
B
Date:
12/05/15
PAGE
1
OF
3
Advertisement
Table of Contents
Related Manuals for Wicksteed 600 RALEIGH
Summary of Contents for Wicksteed 600 RALEIGH
- Page 1 Wicksteed Leisure Ltd, Digby Street, Kettering, Northants NN16 8YJ Tel: 01536 517028 Fax: 01536 410633 www.wicksteed.co.uk E:sales@wicksteed.co.uk Version: No part of this document may be copied or used without the express written permission of WICKSTEED LEISURE LTD (c) 2014 Date: 12/05/15...
- Page 2 850.0 600.0 1836.0 FOUNDATION 900 X 300 X 400 DEEP 1317.0 425.0 425.0 1834.5 665.0 600 X 300 X 400 DEEP ALL FOUNDATIONS 400 X 400 X 600 DEEP UNLESS OTHERWISE SPECIFIED SCRAMBLE NET STAIRS STRAIGHT BRIDGE ROPE LADDER POLY SLIDE PAGE...
- Page 3 6453.3 1546.5 1049.0 26.8 SQ METRES 40mm WETPOUR SURFACING 19.72 LINEAR METRES WETPOUR EDGING 7000.0 1286.5 23 GRASS SAVER TILES (1.5M X 1.0M) SCALE 1:50@A4 PAGE...
