- Page 1 Montage- und Kurzanleitung Mounting and Brief Operating Instructions Dialock Zylinder DC Dialock Cylinder DC...
-
Page 2: Table Of Contents
RESET ..........27 Dialock Cylinder DC - Status: 09.2003 - 732.29.140... -
Page 3: Scope Of Delivery
Allen key 2 mm and 0.9 mm Front cover O-ring Knob screw ( Allen screw) Outer knob Connection wire Cylinder Grub screws Batteries Contact bridge 10 Inner knob 11 Forend 12 Mortise lock Dialock Cylinder DC - Status: 09.2003 - 732.29.140... -
Page 4: Area Of Application
B = inner dimension (mm): distance between the outer edge of the inner rosette and the centre of the hole for the forend. Dialock Cylinder DC - Status: 09.2003 - 732.29.140... -
Page 5: Instructions For Installation
3. From the inside of the door, push the connection wire (5) through the lock (12). Push the cylinder (6) into the lock (12) until the forend (11) can be screwed in from the edge of the door. Dialock Cylinder DC - Status: 09.2003 - 732.29.140... - Page 6 When pushing into position, the outer knob (4) must not be twisted, otherwise the connection wire (5) may be damaged. 7. Push the O-ring (2) into the groove on the front cover (1). Dialock Cylinder DC - Status: 09.2003 - 732.29.140...
- Page 7 If the locking is closed, it is not possi- facturer's setting) ble to insert the connecting cable. In this case, the locking device must first The connection wire (5) can be ins- be pulled carefully out. erted. Dialock Cylinder DC - Status: 09.2003 - 732.29.140...
- Page 8 Mounting and Brief Operating Instructions silvery Dialock Cylinder DC - Status: 09.2003 - 732.29.140...
- Page 9 9. Press the front cover (1) onto the outer knob (4). Important: observe the correct position of the groove (twist guard). Take care not to kink or damage the connection wire. The outer knob is now fully installed. Dialock Cylinder DC - Status: 09.2003 - 732.29.140...
- Page 10 The inner knob is now fully installed. 13. Function test: press the white button on the panel. The LED panel flashes green 5 times and then red 5 times (first use only). Dialock Cylinder DC - Status: 09.2003 - 732.29.140...
-
Page 11: Commissioning
Dialock agent. Important: Avoid misuse of the programming, cancelling and user keys by unau- thorised persons. Always keep the programming, cancelling and user keys in a safe place. Dialock Cylinder DC - Status: 09.2003 - 732.29.140... -
Page 12: Brief Operating Instructions
3. Hold the user key to be cancelled in front of the panel. The red LED lights up for a moment. Locking rights have now been withdrawn. The Dialock DC Cylinder switches off automatically. Dialock Cylinder DC - Status: 09.2003 - 732.29.140... -
Page 13: Operation
Dialock DC Cylinder. If the LEDs still do not switch from red to green: => user key has no authorisation. Important: The cylinder does not lock automatically. The door has to be locked manually from the inside or the outside. Dialock Cylinder DC - Status: 09.2003 - 732.29.140... -
Page 14: Replacement Of Batteries
5. Place the inner knob (10) in position and using the Allen key, screw the three grub screws (7) hand tight. 6. Function test: Press the white button on the panel. The red LED must light up briefly. Dialock Cylinder DC - Status: 09.2003 - 732.29.140... -
Page 15: Emergency Opening
4. The Dialock DC Cylinder is ready. Turn the outer knob to open the lock. 5. Disconnect the emergency power supply and replace the cover. Important: Take care not to damage the connection cable (5)! 6. Replace the batteries immediately (see "Replacing batteries", page 25). Dialock Cylinder DC - Status: 09.2003 - 732.29.140... -
Page 16: Reset
If the bridge is closed for more than 1 sec. but less than 4 secs. a simple reset is carried out. Only the project code is reset. - Release the bridge before red LED stops flashing. Dialock Cylinder DC - Status: 09.2003 - 732.29.140...
