Assembly View
Page 1 of 5
Installation Instructions
Challengers
Centerline Pipe Wall Barrier
Installation Preparation
Recommended Crew: ........................... One (1) adult
Installation Time: ................................... 0.5 installation-hours
Use Zone: .............................................. Refer to Master Drawing
User Group Age (years): ....................... ASTM/CSA: 2-12, EN: 2-14
ICON KEY
Fully Tighten
Hardware
Do Not Fully Tighten
Hardware
Drill
Hammer
Model CH4095
®
Add 1 Drop of
Thread Locking Adhesive
Pour Concrete
Dig Footing Holes
Critical Fall Height
Model CH4095
PA 835
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Playworld Challengers CH4095
Summary of Contents for Playworld Challengers CH4095
- Page 1 Installation Instructions Installation Instructions Challengers Model CH4095 ® Centerline Pipe Wall Barrier Installation Preparation Recommended Crew: ......One (1) adult Installation Time: ........0.5 installation-hours Use Zone: ..........Refer to Master Drawing User Group Age (years): ....... ASTM/CSA: 2-12, EN: 2-14 ICON KEY Fully Tighten Add 1 Drop of...
- Page 2 Installation Instructions 36" (914 mm) Top View 18" (457 mm) Diameter Footing Diagram 2" (50 mm) 38.2" (970 mm) 1.4" (37 mm) Elevation View Page 2 of 5 Model CH4095 PA 835...
- Page 3 Installation Instructions Barrier Follow the details in alphabetical order. For clarifi cation, each detail references the step description. The step descriptions start on page 4. 3/8" Flat Washer Barrier BAE0595 AEN0224 (2) Total (1) Total 3/8" x 1" Button Head Bolt BAE0664 (2) Total Centerline Clamp...
- Page 4 Installation Instructions __Notes Before You Begin: Do not over tighten bolts during assembly, only snug Final Details. tighten them until assembly is complete. Step 6: Plumb and level the component. Tighten all fasteners. Fully tighten all fasteners according to tightening torque specifi cations. Carefully read and understand these installation instructions before you Torque Specifi...
- Page 5 Installation Instructions Bill of Materials CH4095 - CENTERLINE PIPE WALL BARRIER PART NO. DESCRIPTION QTY. AAU0556 CLAMP - 3-1/2" CENTERLINE DIE CAST AEN0224 BARRIER - 30-1/2" x 41-7/8" CENTERLINE PIPEWALL BAD0085 THREAD LOCKING ADHESIVE BAE0020 RIVET - 1/4" x 11/16" DRIVE BAE0595 WASHER - 3/8"...
