- Page 1 Pioneering for You Wilo-VeroLine-IPH-O, IPH-W en Installation and operating instructions 2 140 983-Ed.01 / 2013-10-Wilo...
- Page 2 Fig. 1: Fig. 2: Fig. 3:...
- Page 3 Fig. 4: 6.3 6.2 2.2 2.3 3.3 3.4...
- Page 5 Einbau- und Betriebsanleitung Installation and operating instructions Notice de montage et de mise en service Inbouw- en bedieningsvoorschriften...
-
Page 6: Table Of Contents
General..............................19 Safety ..............................19 Indication of instructions in the operating instructions .................19 Personnel qualifications ............................20 Danger in the event of non-observance of the safety instructions ..............20 Safety consciousness on the job ........................20 Safety instructions for the operator .........................20 Safety instructions for inspection and installation work ................21 Unauthorised modification and manufacture of spare parts ................21 Improper use ................................21 Transport and interim storage ...................... -
Page 7: General
There is a risk of damaging the product/unit. “Caution” implies that damage to the product is likely if this information is disregarded. NOTE Useful information on handling the product. It draws attention to possible problems. Installation and operating instructions Wilo-VeroLine-IPH-O, IPH-W... -
Page 8: Personnel Qualifications
This book does not discuss all details or frequent deviations. Additional information can be requested from the manufacturer, if necessary. • If there are any doubts about the function or setting of parts of the product, contact the manufacturer immediately. WILO SE 10/2013... -
Page 9: Safety Instructions For Inspection And Installation Work
Place loops around the pump which tighten from the pump's own weight. • If transport eyes are attached to the motor, they are only approved for transporting the motor, not the complete pump (fig. 6). Fig. 5: Attaching the transport ropes Installation and operating instructions Wilo-VeroLine-IPH-O, IPH-W... -
Page 10: Intended Use
IPH-O 65/125-2.2/2 example: Flange-end pump as In-line Pump ...H-O Heat transfer media (heat transfer oil) ...H-W Superheated water Nominal diameter DN of the pipe connection Nominal impeller diameter [mm] Rated power P [kW] Number of motor poles WILO SE 10/2013... -
Page 11: Technical Data
• Only use mixtures with corrosion inhibitors. The respective manufac- turer's instructions are to be observed. • The fluid must be sediment-free. • Wilo's approval must be obtained for the use of other fluids. NOTE Always read and follow the material safety data sheet for the fluid being pumped. -
Page 12: Description And Function
(IPH-W) or +350 °C (IPH-O). It is cooled by means of the housing cover's cooling fins. In conjunction with a control device (Wilo-VR system or Wilo-CC system), the power of the pumps can be continuously controlled. This allows optimisation of the pump output for the demands of the installation and economically efficient pump operation. - Page 13 • Two opposite holes (fig. 1, Item 365u) on the flange on the motor side of the lantern make it possible (depending on the installation method) to identify leakages in the mechanical seal. These holes must not be blocked (remove plugs); provide a visible outlet for pipework. Installation and operating instructions Wilo-VeroLine-IPH-O, IPH-W...
-
Page 14: Electrical Connection
• Fuse protection on mains side: depending on the motor's rated cur- rent and the activation type. • Earth the pump/installation in accordance with the regulations. WILO SE 10/2013... -
Page 15: Commissioning/Decommissioning
• When rotating the "lantern and motor" unit, take care not to damage the housing's flat gasket. CAUTION! Risk of damaging the pump! • Protect the terminal box from any water escaping when venting. • Close the stop valve on the pressure side. Installation and operating instructions Wilo-VeroLine-IPH-O, IPH-W... -
Page 16: Decommissioning
Safety Have maintenance and repair work carried out by qualified skilled personnel only! It is recommended to have the pump serviced and checked by Wilo after-sales service. DANGER! Risk of fatal injury! There is risk of fatal injury from electrical shock when working on electrical equipment. -
Page 17: Mechanical Seal
Once in a while, however, a visual inspection is required. If there is clearly detectable leakage, the seal is to be changed. Wilo offers a repair kit which con- tains the necessary parts for replacement. -
Page 18: 9.2.2 Installation
Nm ± 10 % instructions Heat sink — pump housing M6x25 M8x30 Lantern — heat sink M6x20 Lantern — motor M8x40 M8-8 nut Washer M12x50 M12-8 nut Washer Impeller — shaft M8 nut M12x1.25 nut M8 screw WILO SE 10/2013... -
Page 19: Faults, Causes And Remedies
Have the pump checked by Wilo after-sales service or a spe- cialised service centre and repaired if necessary Spare parts Spare parts may be ordered via a local specialist and/or Wilo after- sales service. To avoid queries and incorrect orders, all data of the rating plate should be submitted for each order. - Page 20 Locking disc Flat gasket Disc Circlip Retaining ring O-ring O-ring Plug Lantern Fastening screw for pump housing/heat sink Fastening screw for motor/lantern Contact disc for motor/lantern Nut for motor/lantern Counter flange (set) with: Weld neck flange Flat gasket WILO SE 10/2013...
-
Page 21: Disposal
2. For more information on proper disposal, please contact your local council or waste disposal office or the supplier from whom you obtained the product. Subject to change without prior notice! Installation and operating instructions Wilo-VeroLine-IPH-O, IPH-W... - Page 23 Olaf Kuhnt Authorized representative for the completion of the technical documentation: Nortkirchenstraße 100 Mandataire pour le complément de la documentation technique est : 44263 Dortmund Germany Dortmund, 30.10.2009 WILO SE Erwin Prieß Nortkirchenstraße 100 Quality Manager 44263 Dortmund Germany Document: 2105098.1...
- Page 24 EG-verklaring van overeenstemming Dichiarazione di conformità CE Declaración de conformidad CE Hiermede verklaren wij dat dit aggregaat in de geleverde uitvoering voldoet aan de volgende Con la presente si dichiara che i presenti prodotti sono conformi alle seguenti disposizioni e Por la presente declaramos la conformidad del producto en su estado de suministro con las bepalingen: direttive rilevanti:...
- Page 25 :,/2 3XPSV /WG 3RUWXJDO /GD $OFDO– GH +HQDUHV =,3 &RGH Burton Upon Trent :,/2 9LHWQDP &R /WG T +55 11 2923 (WILO) DE14 2WJ *DQJVHR %XVDQ 4050-040 Porto (Madrid) +R &KL 0LQK &LW\ 9LHWQDP T +44 1283 523000...
- Page 26 WILO SE Nortkirchenstraße 100 D-44263 Dortmund Germany T +49(0)231 4102-0 F +49(0)231 4102-7363 wilo@wilo.com Pioneering for You www.wilo.com...
