6. Install amplifier and supplementary wiring harness (mounting system at I beam, only
vehicles without on-board monitor radio with battery in the engine compartment )
40
41
17
16
Retrofit/Installation Kit no. 82 83 0 022 122
Installation Instructions no. 01 29 0 022 772
Install power cable (40), cable colour red, to
connection point and cut off excessive length.
Crimp on blade terminal contact (17) to the
power cable (40) and insert at the supply line
with fuse (8).
Screw cable lug ø8mm (41) coming from the
supply line with fuse (8) to the positive terminal
16
of the battery.
Then fasten supply line with fuse (8) and power
cable (40) with cable straps (16).
8
F 46 0731 B
Date: 04.2000
EN/47
