Figure 12 shows the System 450 UI Main screens, System Status screens, and
System Setup screens for the control system shown in Figure 11.
C
Sn1
C
Sn3
C
Sn2
L1
L2
Room
Sensor
Sn3
Room
Heating
Loop
C1
Room Heating
Circulation Pump
Figure 11: Solar Water Space Heating Control System Example That Uses
30 System 450™ Series Modular Control Systems with Standard Control Modules Technical Bulletin
C450CCN-x
C450YNN-1C
Control Module
Power Module
OUTR1, OUTR2
WIRING
24V Sn2
C
C
Sn1 Sn3
5V
C
240 120
VAC VAC
C2
Solar Water
Storage
Tank Storage
Sensor
Sn2
the Differential Control Feature
Solar Panel
Sensor
Sn1
C450SBN-x
Expansion
Module
OUTR3
C1
C2
Solar Panel
Circulation Pump
