- Page 1 S / S HE ® Manual for the specialised craftsman Installation Operation Commissioning Thank you for buying this RESOL product. Manual Please read this manual carefully to get the best performance from this unit. Please keep this manual carefully. www.resol.com...
-
Page 2: Table Of Contents
CE mark. The Declaration of Conformity is available • Dispose of old appliances in an environmentally sound manner. Upon request we upon request, please contact RESOL. will take back your old appliances bought from us and guarantee an environmen- tally sound disposal of the devices. -
Page 3: Overview
Overview Pump characteristics / pressure loss characteristics • Pre-assembled pump station FlowSol ® S standard pumps • Integrated controller from the DeltaSol BS or DeltaSol ® ® series • Safety assembly with connection for the diaphragm-type expansion vessel, safety valve and pressure gauge FlowSol ®... -
Page 4: Mounting The Station
Mounting the station Note All connections are already tightened such that they usually do not have to be tightened again. However, during commissioning of the system all connections have to be checked for leaks (pressure test). Flushing and filling the solar system WARNING! Scald danger! Pressure surge damage! If the medium enters strongly heated, empty collectors, pressure surges caused by evaporation can occur. -
Page 5: Ball Valve Positions
Î Connect the flushing hose of the filling and flushing station to the drain valve Î Check the system pressure at the pressure gauge. (3) of the pump station. Î Close the ball valve of the pump station (4). Î Open the fill valve (5) and the drain valve (3). Î... -
Page 6: Flowmeter
Flowmeter Safety devices The flowmeter measures and indicates the flow rate with a range of 1-13 l/min. The pump station is equipped with a diaphragm safety valve which corresponds to For the device to function faultlessly, the system must be flushed and free of grit. the relevant directives and regulations. -
Page 7: Accessories
ALS15 discharge hose www.wilointec.com. 1.5 m hose for connection to the safety valve of the Upon request we will provide you with further information. FlowSol S / S HE pump station. ® See our full range of accessories on our website: www.resol.com... - Page 8 - they only represent use outside the copyright requires the approval of RESOL – Elektronische Rege- some examples. They can only be used at your own risk. No liability is assumed for lungen GmbH.
