 Then, the system check screen will be displayed for several seconds.
Symbols are shown on the screen, including the working mode set-
ting, the target speed, the maximum rotation speed (rpm) and timer
maximum value etc. of the device.
Symbols Explanation
 Maximum rotation speed of the device (If "Turbo" function is
activated, the maximum rotation speed could reach 8000 rpm).
 Rotation symbol (The symbol will change into  or  if "Rev"
function is activated).
 Rotation speed setting.
 Operation mode.
 "Timer" maximum value of the device.
 "Timer" symbol.
 After the system check screen, the working screen will appear
and the device is ready for operation.
Note: Figure above shows specified values corresponding to the
default settings at delivery.
10

Factory setting

The device is supplied with following factory setting:
Menu Settings:

mode
max rpm

timer max

language

Working Setting:

target rpm

timer sec
rev sec
10.1
Resetting parameters to factory setting
To reset the parameters to the factory settings, proceed as following:
• Pull out main plug from the device.
• Hold the controller buttons "Menu/Back" and "Timer" simultane-
ously and re-insert main plug in power outlet.
• The unit is now reset to the factory settings.
A
6000 rpm
30 minute
English
400 rpm
off
off
