CIO-DDA06/16 User's Guide

Analog output range switch

The analog output voltage range of each channel can be set with a set of five-position DIP switches. The switch
blocks are located on the board below the calibration potentiometers. The switch blocks are labeled
and individual switches are labeled
Figure 4 .
Figure 4. Analog output range switch — one per DAC — configured for ±5 V
To set a channel to a particular range, read the switch positions as UP or DN (down) from left to right in the
row beside the range you want to set. The switch shown in Fi
settings DN>UP>DN>DN>UP).

Installing the CIO-DDA06/16

After you configure the board's switches and jumpers, you can install the CIO-DDA06/16 into your computer.
To install your board, follow the steps below.
Install the MCC DAQ software before you install your board
The driver needed to run your board is installed with the MCC DAQ software. Therefore, you need to install
the MCC DAQ software before you install your board. Refer to the Quick Start Guide for instructions on
installing the software.
Turn your computer off, open it up, and insert your board into an available ISA slot.
1.
Close your computer and turn it on.
2.
To test your installation and configure your board, run the InstaCal utility you installed in the previous
3.
section. Refer to the Quick Start Guide that came with your board
Software-Quick-Start.pdf
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
through . Set the switches for each individual channel as shown in
1 5
Sx
Range 1 2
±
10 V DN UP
±
DN UP
5.0 V
UP DN
0-10 V
UP DN
0-5 V
for information on how to initially set up and load InstaCal.
1
Installing the CIO-DDA06/16
4 5
UP DN
DN UP (Shown)
UP DN
DN UP
gure 4 is configured for ±5V range (switch
www.mccdaq.com/PDFmanuals/DAQ-
to ,
S1 S6
