- Page 1 2MP 30x PTZ Camera User’s Manual V1.0.0...
-
Page 2: Cybersecurity Recommendations
Cybersecurity Recommendations Mandatory actions to be taken towards cybersecurity 1. Change Passwords and Use Strong Passwords: The number one reason systems get “hacked” is due to having weak or default passwords. It is recommended to change default passwords immediately and choose a strong password whenever possible. - Page 3 ● Only forward the HTTP and TCP ports that you need to use. Do not forward a huge range of numbers to the device. Do not DMZ the device's IP address. ● You do not need to forward any ports for individual cameras if they are all connected to a recorder on site;...
- Page 4 Ideally, you want to prevent any unauthorized physical access to your system. The best way to achieve this is to install the recorder in a lockbox, locking server rack, or in a room that is behind a lock and key. 15.
-
Page 5: Foreword
Foreword General This document elaborates on product profile, structure, operation, device upgrade and technical parameters. Models UAV-GA-V-2030U UAV-GA-V-2045U Safety Instructions The following categorized signal words with defined meaning might appear in the Manual. Symbol Note It means highly potential danger. It will cause severe injury or casualties if it fails to avoid. - Page 6 area and providing related contact. About the Manual The Manual is for reference only. If there is inconsistency between the Manual and the actual product, the actual product shall prevail. We are not liable for any loss caused by the operations that do not comply with the Manual. ...
-
Page 7: Important Safeguards And Warnings
Important Safeguards and Warnings The following description is the correct application method of the device. Please read the manual carefully before use, in order to prevent danger and property loss. Strictly conform to the manual during application and keep it properly after reading. Don’t touch the lens of PTZ camera directly. -
Page 8: Table Of Contents
Table of Contents Cybersecurity Recommendations ........................2 Foreword ................................V Important Safeguards and Warnings ......................VII 1 Product Profile ..............................1 1.1 Product Overview ............................1 1.2 Product Function ............................1 2 Device Structure ............................. 3 2.1 Product Dimensions ..........................3 2.2 Structural Component .......................... -
Page 9: Product Profile
Product Profile Product Overview As the core of unmanned aircraft system, airborne PTZ adopts oriented vector control technology of permanent magnet motor rotor field, high-precision triaxial servo autostability technology and compact portable design. With pitch, roll and course triaxial autostability function, this product is mounted on the aircraft to shoot videos. - Page 10 Draw a circle on the remote control or click any zone in the surveillance image, within the allowed rotation angle range, the aircraft will keep this zone at the center of the screen, zoom in or zoom out this zone. Storage Function ...
-
Page 11: Device Structure
Device Structure Product Dimensions Figure 2-1 UAV-GA-V-2030U Front View (unit: mm) Device Structure 3... - Page 12 Figure 2-2 UAV-GA-V-2030U Side View (unit: mm) Figure 2-3 UAV-GA-V-2045U Front View (unit: mm) Device Structure 4...
-
Page 13: Structural Component
Figure 2-4 UAV-GA-V-2045U Side View (unit: mm) Structural Component Introduce structural component of the device, taking UAV-GA-V-2030U for example. Schematic diagram is just for your reference. Please refer to actual device. Device Structure 5... - Page 14 Figure 2-5 Name Function Shock absorber ball Reduce jitter of PTZ camera during flight; obtain clearer pictures. Shock absorber board Installation screw Fix PTZ camera onto the aircraft. Yaw motor Control horizontal rotation direction of the camera. Yaw rotation arm Roll motor Control rotation angle of roll axis.
-
Page 15: Device Operation
Device Operation Device Installation This chapter explains device installation by taking NAVIGATOR X820 for example. Please refer to actual product. Insert data cable interface at the bottom of aircraft into the interface at the top of shock absorber board, as shown in Figure 3-1. Figure 3-1 Align 4 installation screws with bottom holes of the aircraft, and tighten them. -
Page 16: Picture Acquisition Mode
This chapter mainly introduces how to acquire pictures from SD card and ground control station. 3.2.1 SD Card This chapter explains SD card by taking UAV-GA-V-2030U for example. SD card positions of different devices vary. Please refer to actual product. - Page 17 again. If several devices are mixed and cannot be distinguished, please pair them before operation. For details, please refer to drone user’s manual. Turn on power supply of ground control station, remote control and aircraft. Wireless module of the aircraft connects wireless module of ground control station and remote control automatically.
-
Page 18: Device Upgrade
Device Upgrade This chapter only applies to camera upgrade. Only one device can be upgraded each time. In case of device disconnection during upgrade, as long as ConfigTool stays at the upgrade interface, the device will continue the last upgrade when it is connected with network again. Precondition: Upgrade package has been obtained. - Page 19 Figure 4-2 Click “Open” corresponding to the device that shall be upgraded. Select upgrade file, as shown in Figure 4-3. Figure 4-3 Click “Upgrade”. The system starts upgrading and displays the progress. Device Upgrade 11...
-
Page 20: Technical Parameters
Technical Parameters Parameter Description Product Model UAV-GA-V-2030U UAV-GA-V-2045U Max. optical zoom of PTZ camera Max. electronic zoom of PTZ camera Pixel of PTZ camera Field angle Horizontal: 67.8°～2.77° Horizontal: 66.55°～1.95° Focal length 4.5mm～135mm 4.38mm～177.9mm Image resolution 1920×1080 Digital noise reduction Color: 0.005Lux/F1.5... -
Page 21: Faq
Points for Attention Countermeasures In order to guarantee data integrity, please stop recording and snapshotting; Hot plugging of SD wait for about 15s before pulling out the SD card. Otherwise, all data in SD card card may be lost. Read-write time Please don’t set SD card to be storage medium of recording at fixed time.
