- Page 1 BYT70 User Manual MITX-BYT70 Motherboard User Manual V2.1 Edition Statement: Version Version Description Release date V2.0 Initial version 2017/03/27 V2.1 Delete description of Wake On Lan. 2018/03/01...
-
Page 2: Chapter 1 Product Introduction
BYT70 User Manual Chapter 1 Product Introduction 1.1 Parameters Platform: Onboard Intel Bay Trail-D Celeron J1800(2.41GHz, dual-core, TDP10W) Onboard Intel Bay Trail-D Celeron J1900(2.0GHz, quad-core , TDP10W) System memory: Single channel DDR3L-1333MHz slot up to 8GB GPU: Integrated Intel HD Graphics. Storage: 1 x SATA2.0, 1 x mSATA. -
Page 3: Chapter 2 Hardware
BYT70 User Manual Chapter 2 Hardware 2.1 Graphic description F-AUDIO Speaker USB2.0 SIM CARD JGPIO Mini-PCIE JCOM2 ATX Power JCOM36 mSATA DIMM SATA JPOWER USB2.0 CLR_MOS Please read this manual carefully before you connect an external connector, so as to avoid damage to the board. - Page 4 BYT70 User Manual 2.1.1 Jumper Function Setting Set jumpers according to your needs before installing hardware. Tips about how to identify the first header of jumpers and interfaces: 1. Observe the mark beside plugs, the first header is usually marked by “1” or bold line or triangular symbol; 2. The first header is the square pad of pads on the back;...
- Page 5 BYT70 User Manual VGA_R_R CRT_HSYNC1 CRT_VSYNC1 VGA_DVI_5V 2.1.4 Internal USB (USB1, USB2) Internal USB pin is USB2.0 Port USB1, USB2: Signal Signal USB DATA- USB DATA- USB DATA+ USB DATA+ 2.1.5 LAN With gigabit Ethernet chip RTL8111F, the board can support 1 x RJ45. it supports Wake On LAN. RJ45 LAN LED Description: LILED(green) Function...
-
Page 6: Spdif Out
BYT70 User Manual Signal Signal MIC2-L AGND MIC2-R AVCC FRO-R MIC2-JD F-IO-SEN(AGNG) FRO-L LIN2-JD JAUD: Signal JSPIF: Signal SPDIF Out 2.1.7 COM (COM1 , JCOM2, JCOM36, JCOM1_P, JCOM2_P) 6 x RS232. COM1 is a standard interface at rear panel(DB-9). JCOM1_P and JCOM_2 provide voltage (5V/12V optional) for COM1 and JCOM2. - Page 7 BYT70 User Manual RTS# CTS# （blank） JCOM36: Signal Signal DCD# DTR# DSR# RTS# CTS# （NC） DCD# DTR# DSR# RTS# CTS# （NC） DCD# DTR# DSR# RTS# CTS# （NC） DCD# DTR# DSR# RTS# CTS# （NC） JCOM1_P/JCOM2_P:...
- Page 8 BYT70 User Manual Interface Setting Function Close Close Close Do not connect three sets of COM at the same time or the board will be damaged. 2.1.8 LPT 1 x LPT. Customers can connect it to equipment like printer. 2.1.9 JGPIO One 2×5-Pin JGPI0, 8 programmable I/O interfaces Signal Signal...
-
Page 9: Auto Start
BYT70 User Manual Signal KB_DATA KB_CLK MS_ DATA MS_CLK 2.1.13 Front Panel Control Interface (JPOWER1) Front panel control interface is to connect function buttons and indication lights on the front panel. JPOWER1: Signal Signal HDD_LED+ PWR_LED+ HDD_LED- PWR_LED- RSTBTN+ PWR_ON+ RSTBTN- PWR_ON- 2.1.14 Auto Power On (JAT) - Page 10 BYT70 User Manual latter is set to be “power on”, the function will automatically work. 2.1.15 JCMOS CMOS is powered by the button battery on the board. Clearing CMOS will permanently clear previous system setting and restore it to factory setting. Steps: 1.
