Simrad EK80
Unit. You can therefore easily move the EK80 software from one computer to another, just
remember to take a copy of the license string.
Note
If you have purchased a complete EK80 system from Kongsberg Maritime with transducer(s)
and a Processor Unit, the software license has already been installed.
Once you receive your software license string(s), do not loose them.
Procedure
1 Obtain the software license.
a Check your transceiver(s), and write down the serial number(s).
b For each transceiver, write down how many transducers you have connected.
c For each transducer, write down:
• The center frequency
• The Q-value
• The maximum nominal power rating for the transducer
2 Send the necessary information to one of Simrad's dealers or distributors.
You can also use the request form on http://www.simrad.com/support, or contact our
support department directly.
You can use the following e-mail address:
• purchase.order@simrad.com
Once the software license string(s) have been returned to you (most likely by e-mail), you
can install the licenses into the EK80 software.
3 Observe the
Main
Its default location is on the right side of the EK80 presentation.
4 Click the
Setup
The icon is located under the
5 On the menu, click
Setup
Observe that the
pages selected by the menu on the left side.
160
menu.
icon.
menu. It is used to open the
Main
Installation
dialog box opens. This dialog box contains a number of
Installation
.
menu.
Setup
