  • Page 1 TABLE PULSEOXIMETER INSTRUCTION MANUAL...
  • Page 2 ▒▓ Monitor Series Vital signs Monitor instruction Manual Copyright Our company owns all rights to this unpublished work and intends to maintain this work as confidential. We may also seek to maintain this work as an unpublished copyright. This publication is to be used solely for the purpose of reference, operation, maintenance, or repair of our equipment.

  • Page 3: Table Of Contents

    ▒▓ Monitor Series Vital signs Monitor instruction Manual CONTENT CHAPTER 1 Introduction ....................5 1.1 About the Manual ....................5 1.3 Safety Information ....................5 1.4 Explanation of Symbols ..................7 1.5 Description of Abbreviation ................. 8 1.6 Intended Use ......................8 CHAPTER 2 Overview Of Monitor ..................
  • Page 4 ▒▓ Monitor Series Vital signs Monitor instruction Manual 8.6 Erase Data ......................28 CHAPTER 9 NIBP Measurement Set ................29 CHAPTER 10 Alarm Set ....................30 10.1 Alarm priority ..................... 30 10.2 Alarm set ......................31 CHAPTER 11 Real Print Set(Optional) ................32 CHAPTER 12 Network Set(Optional) ................

  • Page 5: Chapter 1 Introduction

    ▒▓ Monitor Series Vital signs Monitor instruction Manual CHAPTER 1 Introduction 1.1 About the Manual Before using the vital signs monitor, the user must carefully read this manual so that the user can operate the monitor properly and make it reach the specific safety standard and performance index.
  • Page 6 ▒▓ Monitor Series Vital signs Monitor instruction Manual as an adjunct in patient assessment. It must be used in conjunction with clinical signs and symptoms. Prolonged use or the patient’s condition may require changing the sensor site periodically. The site must be checked at least every four hours to ensure adequate adhesion, circulation, skin integrity and correct optical alignment.

  • Page 7: Explanation Of Symbols

    ▒▓ Monitor Series Vital signs Monitor instruction Manual signs by alternate means and then check the monitor for proper functioning. For proper equipment maintenance, perform the service procedures at the recommended intervals as described in the manual. If the monitor needs to be used continuously long-term, please note to connect the monitor with the main power supply by the alarm of battery, otherwise, the monitor will automatically shut down, which leads to the break-off of the monitoring.

  • Page 8: Description Of Abbreviation

    ▒▓ Monitor Series Vital signs Monitor instruction Manual 1.5 Description of Abbreviation Arterial oxygen saturation Pulse rate NIBP: Non-invasive measurement of blood pressure SYS: Systolic pressure DIA: Diastolic pressure Mean arterial pressure 1.6 Intended Use The vital signs monitor is a portable device indicated for use in non-invasively measuring and displaying functional oxygen saturation of arterial haemoglobin (SpO ), pulse rate(PR), Non-invasive measurement of blood pressure(NIBP) of adult and pediatric patients in...

  • Page 9: Appearance Of Monitor

    ▒▓ Monitor Series Vital signs Monitor instruction Manual 2.2 Appearance of Monitor 2.2.1 Front panel Fig. 1 Description of Fig.1: 1. LCD displaying screen: Display SpO waveform, Pulse rate, Pulse amplitude indicator (blip bar), NIBP status indicator, USB indicator, the date & time, alarm limits, system icon and ID number.
  • Page 10 ▒▓ Monitor Series Vital signs Monitor instruction Manual over 2 seconds to turn off the audio alarm and repress it for over 2 seconds to restore the alarm. In main menu or submenu, press this button to return to the previous screen. 2.2.2 Rear panel Fig.
  • Page 11 ▒▓ Monitor Series Vital signs Monitor instruction Manual Make sure that the poles of the battery are playing as the following position: 2 to 2’, 3 to 3’;4 to 4’, 5 to 5’. Fig. 4 Notes: " Make sure that the polarity of the battery is correctly inserted. Otherwise the unit cannot operate normally.
  • Page 12 ▒▓ Monitor Series Vital signs Monitor instruction Manual 2.2.5 Printer (Optional) The monitor can print the stored records and SpO waveforms with the configured SP-B6J printer. Fig.8 Description of Fig.8: 1—Open button, pull the jut of cassette door, you can open the paper cassette door. 2—No paper indicator, the lamp will be lighted when there is no paper.

  • Page 13: Specification

    ▒▓ Monitor Series Vital signs Monitor instruction Manual NOTE " When the recorder is working, the record paper goes out steadily. Do not pull the paper, or the recorder may be damaged. " Do not operate the recorder without record paper. "...
  • Page 14 ▒▓ Monitor Series Vital signs Monitor instruction Manual Pulse Rate Measurement Range 30 to 235bpm Display Range 0 to 254bpm Resolution 1bpm 30-100, ±2bpm; 101-235±2%;0-29 Unspecified Accuracy NIBP measurement Measurement Range Infant Adult 30-135 30 -255 15 -110 15 - 220 20 -125 20 -235 overvoltage protection of...

  • Page 15: Chapter 3 Patient Safety

    ▒▓ Monitor Series Vital signs Monitor instruction Manual CHAPTER 3 Patient Safety The vital signs monitor is designed to comply with the International Safety requirements for medical electrical equipment. 3.1 Environment Follow the instructions below to ensure a completely safe electrical installation. The environment where the Monitor will be used should be reasonably free from vibration, dust, corrosive or explosive gases, extremes of temperature, humidity, and so on.

  • Page 16: Connect The Power Cables

    ▒▓ Monitor Series Vital signs Monitor instruction Manual 4.2 Connect the Power Cables Connection procedure of the AC power cable: Make sure the AC power supply complies with following specification: 100-230 (VAC), 50/60 (Hz). Ensure that the AC outlet is properly grounded. ⑴...

  • Page 17: Chapter 5 Measuring Screen And Main Menu

    ▒▓ Monitor Series Vital signs Monitor instruction Manual CHAPTER 5 Measuring screen and Main menu 5.1 measuring screens 5.1.1 Press the button for about 3 seconds to turn the monitor on, one of the following measuring screens will display. Fig.11(1) Fig.11(2) Description of Fig.11(1) &(2)：...

  • Page 18: Main Menu

    ▒▓ Monitor Series Vital signs Monitor instruction Manual Patient type：Infant and the initial pressure is 70 mmHg. Remaining time for next pressure measurement in Auto mode：50 minutes NIBP measuring mode：Auto Patient type：Infant Remaining time for next pressure measurement in Auto mode：50 minutes 4: The trend graphic of SpO in Fig.11(1)；...

  • Page 19: Chapter 6 Date & Time, Id Settings

    ▒▓ Monitor Series Vital signs Monitor instruction Manual CHAPTER 6 Date & Time, ID Settings The Monitor features flexible configurations. You can configure various aspects of the monitor, including TIME, ID number, printer and so on. Always set the date and time before using the unit for the first time.

  • Page 20: Chapter 7 Take A Measurement

    ▒▓ Monitor Series Vital signs Monitor instruction Manual Fig.15 Press the button to set the suitable ID number, and confirm your selection by pressing button. Press the button to return to the previous screen. The setting range of the ID number is 1~99. CHAPTER 7 Take a Measurement 7.1 SpO and PR measurement...
  • Page 21 ▒▓ Monitor Series Vital signs Monitor instruction Manual Measuring display " In standard measurement condition, the monitor will display “ Searching for pulse” and “SpO measuring…” successively on information column. Review the measuring result displayed on the measuring screen when taking a measurement. "...

  • Page 22: Nibp Monitoring And Precautions

    ▒▓ Monitor Series Vital signs Monitor instruction Manual " Placement of a sensor on an extremity with a blood pressure cuff, arterial catheter, or intravascular line " The patient has hypotension, severe vasoconstriction, severe anemia, or hypothermia " There is arterial occlusion proximal to the sensor "...
  • Page 23 ▒▓ Monitor Series Vital signs Monitor instruction Manual has caused an irregular heart beat. The measuring time thus will be prolonged. ! Heart-lung Machine Measurements may not be possible if the patient is connected to a heart-lung machine. ! Pressure changes Measurements will be unreliable or may not be possible if the patient’s blood pressure is changing rapidly over the period of time during which the arterial pressure pulses are being analyzed to obtain the measurement.
  • Page 24 ▒▓ Monitor Series Vital signs Monitor instruction Manual different. ALARM: Please ensure not to inadvertently connect the extended tube to intravascular fluid systems, which allows air to be pumped into a blood vessel and threaten the patient’s life. 4. Check whether the patient mode is appropriately selected. For the detailed operation please refer to CHAPTER 9 NIBP Measurement set.
  • Page 25 ▒▓ Monitor Series Vital signs Monitor instruction Manual associated with purpuric, ischemia and neuropathy in the limb wearing the cuff. When monitoring a patient, examine the extremities of the limb frequently for normal color, warmth and sensitivity. If any abnormality is observed, stop the blood pressure measurements.

  • Page 26: Chapter 8 Data Management

    ▒▓ Monitor Series Vital signs Monitor instruction Manual dry-cleaned. The cuff can also be machine-washed or hand-washed, the latter method may prolong the service life of the cuff. Before washing, remove the latex rubber sleeve, and for machine-washing, close the Velcro fastening. Allow the cuff to dry thoroughly after washing, and then reinsert the rubber sleeve.

  • Page 27: Pr Trend Review

    ▒▓ Monitor Series Vital signs Monitor instruction Manual previous screen. Fig.19(1) Fig.19(2) Select ID: with 1-99 IDs selectable for data reviewing. Delete: Delete the trend data of the selected ID. A prompt will appear for enquiring your confirmation. Review: Return to the trend review screen of the selected ID. 8.3 PR Trend Review You can review the PR trend of the current ID or a different ID’...

  • Page 28: Nibp Trend Review

    ▒▓ Monitor Series Vital signs Monitor instruction Manual Fig.21(1) Fig.21(2) 8.5 NIBP Trend Review You can review the NIBP trend chart of the current ID or other ID by setting manually. In menu 1, Press the button to select the “ NIBP Trend Review” item and then press button to enter into the submenu.

  • Page 29: Chapter 9 Nibp Measurement Set

    ▒▓ Monitor Series Vital signs Monitor instruction Manual CHAPTER 9 NIBP Measurement Set Select “ NIBP Measurement Set” item in menu 1 and then press the button to enter into submenu. Refer to the following figure. Press the button to select item to set and press to pitch on the item (the background color of the selected item will be reversed color).

  • Page 30: Chapter 10 Alarm Set

    ▒▓ Monitor Series Vital signs Monitor instruction Manual CHAPTER 10 Alarm Set 10.1 Alarm priority There are there-level priorities for alarm. High priority: the highest level alarm, indicate the patient is in the very dangerous situation. Medium priority: indicate the warning should be paid attention. Low priority: indicate the finger off or finger sensor off.

  • Page 31: Alarm Set

    ▒▓ Monitor Series Vital signs Monitor instruction Manual 10.2 Alarm set In menu 1 screen, press the or the button to select the “ Alarm Set” item, and then press the button to enter into the submenu. Refer to the Fig.25. Press the or the button to select the item and press the to pitch on the item (the background color...

  • Page 32: Chapter 11 Real Print Set(Optional)

    ▒▓ Monitor Series Vital signs Monitor instruction Manual CHAPTER 11 Real Print Set(Optional) The monitor can print data by configured printer such as B6 printer. In the menu 2 screen, press the or the button to select the “ Real Print Set” item, and then press the button to enter into the item.

  • Page 33: Chapter 13 System Set

    ▒▓ Monitor Series Vital signs Monitor instruction Manual CHAPTER 13 System Set In the menu 2 screen, press the or the button to select the “ System Set” item, and then press the button to enter into the submenu. Fig.27 Brightness Press the button to pick the “...

  • Page 34: Chapter 14 System Configuration

    ▒▓ Monitor Series Vital signs Monitor instruction Manual CHAPTER 14 System Configuration In menu 2 screen, pick and enter “ System Configuration” item. Two listed options are shown as Fig.28. Press the or the button to choose and then press to confirm.

  • Page 35: Chapter 17 Trouble Shooting

    ▒▓ Monitor Series Vital signs Monitor instruction Manual CHAPTER 17 Trouble shooting Problems Possible reason Solution 1. Retry by plugging the finger % or pulse rate 1. Finger is not plugged correctly 2. Measure more times, If you can can not be shown 2.

  • Page 36: Chapter 18 Maintenance And Cleaning

    ▒▓ Monitor Series Vital signs Monitor instruction Manual CHAPTER 18 Maintenance And Cleaning 18.1 Maintenance Customers should be responsible for periodic maintaining of the product and its accessories. It is very important for our company to warrant the service and repairs. We reserve the rights to change the time limit of warranty and replacement if the following steps are non-implemented: ⑴An effective maintenance plan should be designed for the product and its reusable...

  • Page 37: Warranty And Repair

    ▒▓ Monitor Series Vital signs Monitor instruction Manual Please hold the product in package if the product would not work for a long time. ● Do not make the product contact with chemical medicine and reagent. ● Battery Maintenance ● "...
  • Page 38 ▒▓ Monitor Series Vital signs Monitor instruction Manual 18.2.3 Customer guarantees: ⑴ Read the user manual carefully before operation. ⑵ Operation and maintenance according to the user manual, and guarantee the requests of power and environment. 18.2.4 Non-warranty and Non-replacement Policy The work environment is not eligible.

  • Page 39: Appendix

    Thermal array recorder (including one roll paper for recorder) Model：SP-B6J 1 group Distrib. Moretti S.p.A. Via Bruxelles, 3 Meleto - 52022 Cavriglia (Arezzo) Tel. +39 055 96 21 11 - Fax. +39 055 96 21 200 info@morettispa.com - www.morettispa.com - 39 -...
  • Page 40 Via Bruxelles, 3 - Meleto Fax. +39 055 96 21 200 52022 Cavriglia (Arezzo) www.morettispa.com Tel. +39 055 96 21 11 info@morettispa.com...
