Technical Reference Guide
Product Overview
Describes features of the product.
Setup
Describes setup and instrallation of the product and
peripherals.
Setting/Checking Modes
Describes the modes to set and check settings.
Application Development Information
Describes how to control the printer and necessary
information when you develop applications.
Handling
Describes how to handle the product.
Replacement of the TM-T70
Describes precautions for replacement.
Appendix
Describes general specifications and character codes.
M00063503
Rev.D

Advertisement

Table of Contents
loading

Related Manuals for Epson TM-T70II

Summary of Contents for Epson TM-T70II

  • Page 1 Technical Reference Guide Product Overview Describes features of the product. Setup Describes setup and instrallation of the product and peripherals. Setting/Checking Modes Describes the modes to set and check settings. Application Development Information Describes how to control the printer and necessary information when you develop applications.
  • Page 2 Seiko Epson Corporation’s operating and maintenance instructions. • Seiko Epson Corporation shall not be liable against any damages or problems arising from the use of any options or any consumable products other than those designated as Original Epson Products or Epson Approved Products by Seiko Epson Corporation.

  • Page 3: For Safety

    For Safety Key to Symbols The symbols in this manual are identified by their level of importance, as defined below. Read the following carefully before handling the product. You must follow warnings carefully to avoid serious bodily injury. WARNING Provides information that must be observed to prevent damage to the equipment or loss of data. •...

  • Page 4: Warnings

    Warnings • To avoid risk of electric shock, do not set up this product or handle cables during a thunderstorm. • Never insert or disconnect the power plug with wet hands. WARNING Doing so may result in severe shock. • Handle the power cable with care. Improper handling may lead to fire or electric shock.

  • Page 5: Restriction Of Use

    Restriction of Use When this product is used for applications requiring high reliability/safety, such as transportation devices related to aviation, rail, marine, automotive, etc.; disaster prevention devices; various safety devices, etc.; or functional/precision devices, etc., you should use this product only after giving consideration to including fail- safes and redundancies into your design to maintain safety and total system reliability.

  • Page 6: About This Manual

    About this Manual Aim of the Manual This manual was created to provide information on development, design, and installation of POS systems and development and design of printer applications for developers. Manual Content The manual is made up of the following sections: Chapter 1 Product Overview Chapter 2...

  • Page 7: Table Of Contents

    Contents ■ For Safety............................3 Key to Symbols......................................3 Warnings........................................4 Cautions........................................4 ■ Restriction of Use..........................5 ■ About this Manual ...........................6 Aim of the Manual ....................................6 Manual Content ......................................6 ■ Contents ............................7 Product Overview ................11 ■ Features ............................11 ■...
  • Page 8 Setup ....................21 ■ Flow of Setup..........................21 ■ Installing the Printer ........................22 Important Notes on Installation............................... 23 Affixing Position of DF-10................................... 23 ■ Connecting the Printer to the Host Computer................24 For Serial Interface ....................................24 For Parallel Interface ..................................... 26 For USB Interface ....................................
  • Page 9 Utilities........................................65 Download........................................66 Handling ....................67 ■ Installing and Replacing Roll Paper .....................67 ■ Removing Jammed Paper ......................69 ■ Cleaning the Thermal Head ......................69 ■ Preparing for Transport.........................70 Replacement of the TM-T70..............71 ■ Compatibility ..........................71 Printing........................................71 Print Density......................................71 Number of Head Energizing Parts..............................71 Printable Area (for 80 mm Width Paper/58 mm Width Paper) ....................71 Cutting Method.......................................72 Manual Paper Feed ....................................72...
  • Page 10 Printing and Cutting Positions................................88 Paper Specifications....................................88 Electrical Characteristics ..................................90 Environmental Conditions ................................. 91 External Dimensions and Mass................................. 92 ■ Option Specifications ........................93 AC Adapter (PS-180) ..................................... 93 ■ Specifications of Interface and Connector.................. 94 RS-232 Serial Interface..................................94 IEEE 1284 Parallel Interface ................................

  • Page 11: Product Overview

    Features The TM-T70II is a receipt printer with high speed printing and a small footprint. With its compact design, it can be placed in a narrow space, such as under a counter, and it also has full front access for easy operability.

  • Page 12: Product Configuration

    • Model with the buzzer function • Model without the buzzer function The optional external buzzer and the internal buzzer cannot be used together at the same time. Color • ECW (Epson Cool White) • EDG (Epson Dark Gray) Accessories Included •...
  • Page 13 Chapter 1 Product Overview • Locking wire saddle* • The TM-T70II Software & Documents Disc (drivers, utility software, and manuals)* • Setup Guide • Warranty certificate* * May not be included depending on the model. Options • AC adapter • AC cable •...

  • Page 14: Parts Name And Function

    For detailed information about ESC/POS commands, see the ESC/POS Command Reference. Power Switch Cover Install the power switch cover that comes with the TM-T70II onto the printer to prevent inadvertent changing of the power switch, to prevent tampering, and to improve the appearance of the printer.

  • Page 15: Control Panel

    Chapter 1 Product Overview Control Panel Feed button Paper LED Error LED (Power) LED Feed button Pressing this button once feeds the roll paper by one line. Holding this button down feeds the roll paper continuously. LEDs Paper LED (orange) •...

  • Page 16: Connectors

    Connectors All cables are connected to the connector panel on the lower rear of the printer. USB interface Drawer kick connector Serial interface Parallel interface Power supply connector LAN interface • Drawer kick connector: Connects the cash drawer or the optional external buzzer. •...

  • Page 17: Error Status

    Chapter 1 Product Overview Error Status There are three possible error types: automatically recoverable errors, recoverable errors, and unrecoverable errors. Automatically Recoverable Errors Printing is no longer possible when automatically recoverable errors occur. They can be recovered easily, as described below. Error LED flash code Error Error description...

  • Page 18: Unrecoverable Errors

    Unrecoverable Errors Printing is no longer possible when unrecoverable errors occur. The printer must be repaired. Turn off the power immediately when unrecoverable errors occur. CAUTION Error LED flash code Error Error description Approx. 160 ms Memory R/W error After R/W checking, the printer does not work correctly.

  • Page 19: Nv Memory (Non-Volatile Memory)

    Graphics, such as shop logos to be printed on receipts, can be stored. Even with a serial interface model whose communication speed is low, high speed graphics printing is possible. Use the TM-T70II Utility to register graphics. You can also use the TM-T70II Utility or the NV graphics information print mode to confirm the registered graphics.

  • Page 20: R/E (Receipt Enhancement)

    NV memory. You can read the information with the Status API of the APD or OPOS ADK to use it for periodical checks or part replacement. Maintenance Counter can be checked with the TM-T70II Utility or in a self-test.

  • Page 21: Setup

    Chapter 2 Setup Setup This chapter describes setup and installation of the product and peripherals. Flow of Setup This chapter consists of the following sections along with the setup flow of the product and peripherals. Installing the Printer (page 22) Connecting the Printer to the Host Computer (page 24) Connecting the AC Adapter (page 31) Setting the Memory Switches/Receipt Enhancement (page 32)

  • Page 22: Installing The Printer

    Installing the Printer You can install this printer only horizontally. Fix the printer so that it does not move around when you open the roll paper cover and cut roll paper. A tape for fixing the printer is available as an option. (See "Affixing Position of DF-10"...

  • Page 23: Important Notes On Installation

    Chapter 2 Setup Important Notes on Installation • The printer must be installed horizontally. • Do not place the printer in dusty locations. • Do not catch cables or foreign matter under the printer. • Do not put anything that has a force of more than 32.7 N {3 kgf} on the top of the printer. Affixing Position of DF-10 When you use the affixing tapes for fixing the printer (Model: DF-10), paste them as shown in the figure below.

  • Page 24: Connecting The Printer To The Host Computer

    USB port. AC adapter + AC cable DM-D (Serial I/F model) Extension cable for power supply Serial cable Cash drawer TM-T70II Modular cable Serial cable DM-D (USB I/F model) AC adapter + AC cable USB cable Cash drawer...
  • Page 25 ∗ Baud rate: 19200 bps ∗ Bit length: 8-bit ∗ Parity: no parity ∗ Stop bit: 1 Modular cable DM-D TM-T70II Modular cable Serial cable Cash drawer AC adapter + AC cable Connecting the serial interface (RS-232) cable Be sure to turn off the power supply for both the printer and host computer before connecting the cables.

  • Page 26: For Parallel Interface

    • Use the extension cable for power supply bundled with the customer display. AC adapter + AC cable DM-D (Serial I/F model) Extension cable for power supply Serial cable Cash drawer TM-T70II Modular cable Parallel cable DM-D (USB I/F model) AC adapter + AC cable USB cable Cash drawer...

  • Page 27: For Usb Interface

    USB port. AC adapter + AC cable DM-D (Serial I/F model) Extension cable for power supply Serial cable TM-T70II Cash drawer USB cable Modular cable DM-D (USB I/F model) AC adapter + AC cable...
  • Page 28 ∗ Baud rate: 19200 bps ∗ Bit length: 8-bit ∗ Parity: no parity ∗ Stop bit: 1 Modular cable DM-D TM-T70II USB cable Modular cable Cash drawer AC adapter + AC cable Connecting the USB interface cable Attach the locking wire saddle at the location shown in the figure below.

  • Page 29: For Lan Interface

    DM-D 10BASE-T/100BASE-TX Modular cable Cash drawer TM-T70II TM-T70II A customer display (DM-D series) cannot be connected to the printer when the printer is connected to the host computer. To connect the customer display, connect the printer to the host computer via the serial interface or the USB interface.

  • Page 30: For Wireless Lan Interface

    ® connecting to iOS devices. Connecting to Windows PCs You can connect quickly and easily by using the EPSON TM Connector utility. Start the utility, select ® the search method, and then click [Search]. Select the printer you want to pair with, and then click [Connect]. If a passkey entry screen is displayed, enter the Passkey, and then click [OK].

  • Page 31: Connecting The Ac Adapter

    Chapter 2 Setup Connecting the AC Adapter Use the PS-180 or an equivalent product as the AC adapter. • Always use the PS-180 or an equivalent product as the AC adapter. Using a nonstandard power supply can result in electric shock and fire. •...

  • Page 32: Setting The Memory Switches/Receipt Enhancement

    For an outline of the functions, see the following section. Use the methods shown in the table below; TM-T70II Utility, Memory Switch Setting Mode, or ESC/POS commands, to set the memory switches and R/E functions.

  • Page 33: Functions

    Chapter 2 Setup *3: Enabled only for ANK models *4: Excluding some functions. • For information about the TM-T70II Utility, see the TM-T70II Utility User’s Manual. • For information about how to use the memory switch setting mode, see "Memory Switch Setting Mode"...
  • Page 34 USB power-saving function • Disabled • Enabled (initial setting) The USB power-saving function is valid only when the USB interface communication condition is set to the vendor-defined class and the system configuration is set so that the USB driver can support the USB power-saving function.
  • Page 35 Chapter 2 Setup Multi-tone print density Selectable from levels 1 to 13 (70% ~ 130%) Initial setting for ANK models: level 7 (100%) Initial setting for Simplified Chinese models, Traditional Chinese models, and South Asia font models: level 11 (120%) •...
  • Page 36 International character default Selectable from 18 sets Initial setting for Simplified Chinese models: China Initial setting for ANK models, Traditional Chinese models, and South Asia font models: USA For the character code table, see "Character Code Tables" on page 101. Interface selection Selectable from: automatic selection (initial setting), fixed to UIB interface, or fixed to built-in USB.
  • Page 37 Chapter 2 Setup Extra lower space reduction • Disabled (initial setting) • Enabled Line space reduction rate • Not reduced (initial setting) • 25% • 50% • 75% Line feed reduction rate • Not reduced (initial setting) • 25% • 50% •...
  • Page 38 Buzzer • For models without the internal buzzer function, the optional external buzzer (OT-BZ20) needs to be connected to use the buzzer function. For information about how to connect the optional external buzzer, see "Connecting the Optional External Buzzer" on page •...
  • Page 39 • 4800 bps • 9600 bps • 19200 bps • 38400 bps (initial setting for ANK models (with TM-T70II command-compatible mode enabled)) • 57600 bps • 115200 bps (initial setting for ANK models (with TM-T70II command-compatible mode disabled), South Asia font models, Simplified Chinese models and Traditional Chinese models)
  • Page 40 Auto top logo TM-T70II Utility does not support the function for Number of lines to be deleted below top logo. Key-code Selectable from key-codes of registered logos Alignment • Left (initial setting) • Center • Right Number of lines to be deleted below top logo...
  • Page 41 Chapter 2 Setup Top logo print while clearing the buffer to recover from a recoverable error • Disabled • Enabled (initial setting) Top logo print after paper feeding with the Feed button has finished • Disabled (initial setting) • Enabled...

  • Page 42: Connecting The Optional External Buzzer

    Connecting the Optional External Buzzer When using the optional external buzzer (OT-BZ20), install the optional external buzzer. If your printer is not equipped with a buzzer, you can use the optional external buzzer (OT-BZ20) by connecting it to the drawer. •...

  • Page 43: Installation Procedures

    Chapter 2 Setup Installation Procedures Turn off the printer. Connect and disconnect the optional external buzzer while the printer is turned off. If you connect it while the printer is turned on, the buzzer does not function correctly. Clean and dry the printer case where the optional external buzzer will be installed. With 2 pieces of the affixing tape combined, peel off the sticker on one side, and paste it around the center of the attaching surface of the optional external buzzer.

  • Page 44: Adjusting The Buzzer Volume

    Peel off the sticker on the other side of the affixing tape, and attach and fix the optional external buzzer to the printer case. Printer case Turn on the printer. Make settings for the optional external buzzer on the printer. •...

  • Page 45: Connecting The Cash Drawer

    Chapter 2 Setup Connecting the Cash Drawer Use the cash drawer handled by EPSON or your dealer. Connecting the Drawer Kick-out Cable • Specifications of drawers differ depending on makers or models. When you use a drawer other than specified, make sure its specification meets the following conditions.

  • Page 46: Setting The Internal Buzzer (For Models With An Internal Buzzer)

    Drawer connection diagram Drawer kick connector With shielded Drawer kick-out solenoid Control device Drawer open/close switch User side [Drawer kick-out side] Printer side Setting the Internal Buzzer (for Models with an Internal Buzzer) Models with the buzzer function can beep the buzzer when the drawer is opened, by setting the properties of the driver or outputting a pulse signal by a command.

  • Page 47: Setting/Checking Modes

    • Thai character print mode (only for South Asia font models) • Auto line feed (with a parallel interface) • Print density • TM-T70II command-compatible mode (only for ANK models) • Maintenance counter information (head running length, number of times of autocutting) • Memory switch settings Follow the steps below to run this mode.
  • Page 48 Mode Selection : 1 second or more” Press the Feed button while the printer is in the self-test wait mode. If you select the SELF-TEST, the printer prints a rolling pattern using only the built-in character set. If you select the mode selection, follow the instructions printed by the printer. After printing the following message, the printer is initialized and returned to the normal mode.

  • Page 49: Hexadecimal Dumping Mode

    Chapter 3 Setting/Checking Modes Hexadecimal Dumping Mode In the hexadecimal dumping mode, the printer prints the data transmitted from a host computer in hexadecimal numbers and their corresponding characters. Follow the steps below to run this mode. • If there is no character corresponding to print data, “. ” is printed. •...

  • Page 50: Nv Graphics Information Print Mode

    NV Graphics Information Print Mode You can confirm the following information by running the NV graphics information print mode: • Capacity of the NV graphics • Used capacity of the NV graphics • Unused capacity of the NV graphics • Number of NV graphics that are registered •...

  • Page 51: R/E (Receipt Enhancement) Information Print Mode

    Chapter 3 Setting/Checking Modes R/E (Receipt Enhancement) Information Print Mode You can confirm the following information by running the R/E information mode: • Automatic top logo setting • Automatic bottom logo setting • Extended settings for automatic top/bottom logo Follow the steps below to run this mode. Close the roll paper cover.

  • Page 52: Memory Switch Setting Mode

    • Auto paper reduction • Font auto replacement • Buzzer control • Communication condition of serial interface • Communication condition of USB interface • TM-T70II command-compatible mode (only for ANK models) For detailed information about memory switches, see "Setting the Memory Switches/Receipt Enhancement"...
  • Page 53 Chapter 3 Setting/Checking Modes After the printing has been completed, press the Feed button three times. Then press the Feed button for more than one second. The printer starts printing instructions for settings. Follow the instructions. After one setting has been completed, the printer stores the setting and then starts initializing. After that, the printer returns to the normal mode.
  • Page 54 Setting the memory switch Follow the steps below to run this mode. Enter the memory switch setting mode. 1. Check that the roll paper is set and that the printer is turned off. 2. While pressing the Feed button, turn on the printer. Keep pressing the Feed button until the printer starts printing.
  • Page 55 Chapter 3 Setting/Checking Modes Setting conditions • Print Density Number of times to press the Feed button Settings No change Monochrome Multi-Tone • Serial Interface Settings Number of times to press the Feed button Settings No change Baud Rate Parity Handshaking Data Bits Data Receive Error...
  • Page 56 • Default Character Number of times to press the Feed button Settings No change Code Page International Character Set • Embedded Font Replacement Number of times to press the Feed button Settings No change Font A Replacement Font B Replacement •...
  • Page 57 Level 5 Level 6 Level 7 Level 8 Level 9 Level 10 Level 11 Level 12 Level 13 (Fast) • Other Settings Number of times to press the Feed button Settings No change TM-T70II Compatible Mode Buzzer Control Interface Settings...

  • Page 59: Application Development Information

    • ePOS-Print SDK (for Android/iOS/Windows Store Apps/JavaScript) ESC/POS ESC/POS is the Epson original printer command system for POS printers and customer display. With ESC/POS commands, you can directly control all the printer functions, but detailed knowledge of printer specifications or combination of commands is required, compared to using drivers and applications.

  • Page 60: Controlling The Cash Drawer

    Register a cash drawer using the SetupPOS Utility, and control using the OpenDrawer method or the DirectIO function. For details, see the "EPSON OPOS ADK for .NET MANUAL Application Development Guide Cash Drawer (EPSON Standard)" and the "UnifiedPOS Specification". ePOS-Print SDK The output command for the drawer kick pulse and the status transmission command are provided in each SDK library.

  • Page 61: Controlling The Built-In Buzzer

    (TM Series)". OPOS for .NET Register a POS printer using the SetupPOS Utility and control using the DirectIO function. For details, see the "EPSON OPOS ADK for .NET MANUAL Application Development Guide POSPrinter (TM-T70II)". ePOS-Print SDK Use the output command for the drawer kick pulse provided in each SDK library. For details, see the user's manuals provided with each SDK.

  • Page 62: Controlling The Optional External Buzzer

    (TM Series)". OPOS for .NET Register a POS printer using the SetupPOS Utility and control using the DirectIO function. For details, see the "EPSON OPOS ADK for .NET MANUAL Application Development Guide POSPrinter (TM-T70II)". ePOS-Print SDK The command for the buzzer function is provided in each SDK library. For details, see the user's manuals provided with each SDK.

  • Page 63: Software And Manuals

    . Because controlling POS peripherals with original commands is not required on the application side, efficient system development is possible. EPSON OPOS ADK for .NET The OPOS ADK for .NET is a POS industry standard printer driver Windows compatible with Microsoft POS for .NET.

  • Page 64: Drivers

    TM-T70II Mac Printer Driver Mac printer driver allows you to control the TM-T70II using Common UNIX Printing System (CUPS) on Mac OS X. This is a full raster printer driver. It is able to print images, text, and vector graphics etc., that an application displays.

  • Page 65: Utilities

    In the case of this printer, you can use this tool to check and/or set network parameters by connecting the Wireless LAN model to a computer for setup via the USB interface. Monitoring Tool Use to check a list of status for the Epson printers connected to Windows the network. Deployment Tool...

  • Page 66: Download

    Download You can obtain software and manuals from one of the following URLs. For customers in North America, go to the following web site: www.epson.com/support/ For customers in other countries, go to the following web site: www.epson-biz.com/...

  • Page 67: Handling

    Chapter 5 Handling Handling This chapter describes basic handling of the printer. Installing and Replacing Roll Paper • Do not open the roll paper cover during printing. The printer may be damaged. • Do not touch the manual cutter with your hands when installing or replacing the roll WARNING paper.
  • Page 68 Pull out some roll paper, and make sure that the roll paper is set between the paper guides. Paper guides Close the roll paper cover. Tear off the roll paper.

  • Page 69: Removing Jammed Paper

    Remove the jammed paper, reinstall the roll, and close the roll paper cover. Cleaning the Thermal Head Epson recommends cleaning the thermal head periodically (generally every 3 months) to maintain receipt print quality. After printing, the thermal head can be very hot. Do not touch it and let it cool before you clean it.

  • Page 70: Preparing For Transport

    Preparing for Transport Follow the steps below to transport the printer. Turn off the printer. Confirm that LED is off. Remove the power supply connector. Remove the roll paper. Pack the printer upright.

  • Page 71: Replacement Of The Tm-T70

    Enhancement" on page Number of Head Energizing Parts For the TM-T70II, the initial setting of the number of head energizing parts is “One-part energizing. ” You can change the setting with the memory switch (See "Setting the Memory Switches/Receipt Enhancement" on page 32.);...

  • Page 72: Cutting Method

    Receive Buffer You can set the receive buffer of the TM-T70II to 4 KB or 45 bytes with the memory switch, while you can set the receive buffer of the TM-T70 with the DIP switch. The buffer full condition and buffer full release condition of the TM-T70II are the same as those of the TM-T70.

  • Page 73: Logo Registration

    For detailed information about the TM-T70II Utility, see the TM-T70II Utility User’s Manual. Driver Compatibility You can operate the TM-T70II with a driver for the TM-T70 (APD Ver.3xx or later or APD Ver.4.54 or later). You cannot operate the TM-T70 with a driver for the TM-T70II.

  • Page 74: Overall Dimensions

    Overall Dimensions You can place the TM-T70II in the same location as the TM-T70, since its overall dimensions and weight are about the same as or smaller than those of the TM-T70.

  • Page 75: Additional Functions And Functional Improvements

    Chapter 6 Replacement of the TM-T70 Additional Functions and Functional Improvements Print Speed The TM-T70II has increased its print speed up to a maximum of 250 mm/s (200 mm/s for some models). TM-T70II TM-T70 250 mm/s 170 mm/s Maximum print speed...

  • Page 76: Number Of Characters

    The TM-T70II allows you to specify tone of images (2 tones/Multi-tone). Interface The USB interface is added to the main unit of the TM-T70II as standard equipment. USB Class When using the built-in USB interface or USB Plus Power, USB printer class can be used beside the USB vendor-defined class.

  • Page 77: Memory Switches

    For detailed information about the memory switches, see "Setting the Memory Switches/Receipt Enhancement" on page R/E Information Print Mode The TM-T70II has a Receipt Enhancement (R/E) Information Print mode that lets you confirm the following information: • Automatic top logo setting • Automatic bottom logo setting...

  • Page 78: Reliability

    Reliability The TM-T70II has improved reliability. TM-T70II TM-T70 Printer mechanism 17 million lines 15 million lines Life Print head 120 million pulses, 120 km 100 million pulses, 100 km Autocutter 1.7 million cuts 1.5 million cuts MCBF 65 million lines...

  • Page 79: Appendix

    Appendix Appendix Product Specifications Printing method Thermal line printing Cutting method Partial cut (cutting with one point in left edge left uncut) Roll paper (single-ply) width 80 mm width paper printing: 79.5 ± 0.5 mm {3.13 ± 0.02"} 58 mm width paper printing: 57.5 ± 0.5 mm {2.26 ± 0.02"} Interface Serial (RS-232), Parallel (IEEE1284), LAN (10BASE-T/100BASE-TX), USB (Full-speed), Wireless LAN (IEEE802.11a/b/g/n), Bluetooth (Bluetooth...

  • Page 80: Printing Specifications

    Printing Specifications 80 mm width paper 58 mm width paper printing printing Printing method Thermal line printing Dot density ANK models 180 dpi Simplified Chinese models 203 dpi Traditional Chinese models 203 dpi South Asia font models 203 dpi Printing direction Unidirectional with friction feed (Reverse feed is not supported.) Maximum ANK models...
  • Page 81 Appendix • Printing speed may be slower, depending on the such items as the data transmission speed.

  • Page 82: Character Specifications

    Character Specifications Number of characters ANK models Font A (initial setting) Alphanumeric characters: 95 Font B Extended graphics: 128 × 43 pages (including user-defined page) International characters: 18 sets Simplified Chinese Font A (initial setting) Alphanumeric characters: 95 models Font B Extended graphics: 128 ×...
  • Page 83 Appendix Character structure 80 mm width paper 58 mm width paper printing printing Font A (initial setting) 12 × 24 (including 2-dot horizontal spacing) Font B 9 × 17 (including 2-dot horizontal spacing) Kanji font 24 × 24 Special font A 12 ×...
  • Page 84 -: Not supported Note: Space between characters is not included. Characters can be scaled up to 64 times as large as the standard size.
  • Page 85 Appendix Characters per line Standard/Double-height/Double-width/Double-width, double-height W × H (mm) 80 mm width paper 58 mm width paper printing printing Font A ANK models 42/42/21/21 Simplified Chinese 48/48/24/24 models Traditional Chinese 48/48/24/24 34/34/17/17 models South Asia font 48/48/24/24 models Font B ANK models 56/56/28/28 Simplified Chinese...

  • Page 86: Printable Area

    Printable Area 80 mm paper width printing 79.5 0.5 mm 79.5 0.5 mm 0.141 0.05 mm 0.125 0.05 mm 72.2 0.2 mm 0.2 mm (3.65 mm) (3.65 mm) (3.75 mm) (3.75 mm) <203 dpi model> <180 dpi model> <180 dpi model> In 2-divided energizing, the print position within the printable area of the thermal elements for dots 1 to 256 and 257 to 512 is shifted approximately 0.07 mm {0.0028"} as shown in the figure below in the paper feed direction.
  • Page 87 Appendix 58 mm paper width printing 57.5 0.5 mm 0.125 0.05 mm 0.2 mm (2.75 mm) (2.75 mm) In 2-divided energizing, the print position within the printable area of the thermal elements for dots 1 to 208 and 209 to 416 is shifted approximately 0.06 mm {0.0024"} as shown in the figure below in the paper feed direction.

  • Page 88: Printing And Cutting Positions

    Printing and Cutting Positions Manual-cutter position Approx. 30 Approx. 13 Autocutter blade position Center of the print dotline Paper feed direction [units: mm (All the numeric values are typical.)] The values above may vary slightly as a result of paper slack or variations in the paper. Take the notice into account when setting the cutting position of the autocutter.
  • Page 89 Appendix • Paper must not be pasted to the roll paper spool. • The remaining amount of the roll paper when a roll paper near-end is detected differs depending on the spool type. • For the best print quality for each paper type, it is recommended to set the print density. (See "Setting the Memory Switches/Receipt Enhancement"...

  • Page 90: Electrical Characteristics

    Electrical Characteristics Supply voltage DC 24 V ± 7% Current consumption Standby Mean: Approximately 0.1 A (at 24 V, 25°C, normal Maximum 1 A for drawer kick-out driving. print density) Operating Mean: Approximately 2.0 A (180 dpi model) (80 mm Mean: Approximately 1.5 A (203 dpi model) width paper Note: When print ratio is...

  • Page 91: Environmental Conditions

    Acoustic noise (Operating) Approximately 55 dB (Bystander position) Note: The values above are measured in the Epson evaluation condition. The acoustic noise differs depending on the paper used, printing contents, or the setting values such as print speed or print density.

  • Page 92: External Dimensions And Mass

    External Dimensions and Mass • Height: Approximately 114 mm {4.49"} • Width: Approximately 125 mm {4.92"} • Depth: Approximately 194 mm {7.64"} • Mass: Approximately 1.7 kg {3.75 lb} (except for roll paper) <When the Optional OT-CC702W/OT-CC702B is installed> 255.5 [Units: mm]...

  • Page 93: Option Specifications

    Appendix Option Specifications AC Adapter (PS-180) [Units: mm] Electric characteristics Input conditions input voltage (rating): AC 90 to 264 V (AC 100 V -10% to AC 230 V +15%) Frequency (rating): 50/60 Hz ± 3 Hz Power consumption (rating): 100 VA Output conditions Output voltage (rating): DC 24 V ±...

  • Page 94: Specifications Of Interface And Connector

    Specifications of Interface and Connector For detailed information about LAN or wireless LAN, see the Technical Reference Guide for the interface board. For detailed information about Bluetooth, see the iOS Bluetooth ® TM Printer Technical Reference Guide. RS-232 Serial Interface Interface board specifications (RS-232-compliant) Item Specifications...
  • Page 95 Appendix Pin no. Signal name Signal direction Function Input Reception data Output Equivalent to DTR signal (pin 20) Input This signal indicates whether the host computer can receive data. SPACE indicates that the host computer can receive data. MARK indicates that the host computer cannot receive data. When DTR/DSR control is selected, the printer transmits data after confirming this signal (except if transmitted using some ESC/POS commands).
  • Page 96 Memory switch 1-3 Signal Printer status 1 (ON) 0 (OFF) 1) When the printer goes online after turning on the power (or reset using Transmit Transmit the interface) 2) When the receive buffer is released from the buffer full state Transmit Transmit 3) When the printer switches from offline to online...

  • Page 97: Ieee 1284 Parallel Interface

    Appendix IEEE 1284 Parallel Interface Modes The IEEE 1284 parallel interface supports the following two modes. Mode Communication direction Other information Host → Printer communication Compatibility mode Centronics-compliant Printer → Host communication Reverse mode Assumes a data transfer from an asynchronous printer Compatibility Mode Compatibility mode allows data transmission from host to printer only: Centronics-compatible.
  • Page 98 Interface signals Source Compatibility Mode Nibble Mode Byte Mode Host Strobe HostClk HostClk Host/Ptr Data0 (LSB) Data0 (LSB) Data0 (LSB) Host/Ptr Data1 Data1 Data1 Host/Ptr Data2 Data2 Data2 Host/Ptr Data3 Data3 Data3 Host/Ptr Data4 Data4 Data4 Host/Ptr Data5 Data5 Data5 Host/Ptr Data6 Data6...
  • Page 99 Appendix Source Compatibility Mode Nibble Mode Byte Mode Host Init Init Init Printer Fault DataAvail/Data0,4 DataAvail Printer DK_STATUS Printer +5 V Host SelectIn 1284-Active 1284-Active NC: Not Connected ND: Not Defined • A signal name with a rule above it indicates an “L” active signal. •...

  • Page 100: Usb (Universal Serial Bus) Interface

    USB (Universal Serial Bus) Interface For printers on which the standard USB connector has a cap, you cannot use the standard USB interface. Outline • Full-speed transmission at 12 Mbps [bps: bits per second] • Plug & Play, Hot Insertion & Removable USB transmission specifications USB function Overall specifications...

  • Page 101: Character Code Tables

    Appendix Character Code Tables Refer to the following URL regarding the character code table. www.epson-biz.com/pos/reference/charcode/...
