SRX5800 Services Gateway Getting Started
Guide
December 2013
Part Number: 530-055498
Revision 01
This document describes how to install the SRX5800 Services Gateway.
Contents
1

Advertisement

Table of Contents
loading

Related Manuals for Juniper SRX5800

Summary of Contents for Juniper SRX5800

  • Page 1: Table Of Contents

    Step 1: Prepare the Site for SRX5800 Services Gateway Installation | 4 Rack-Mounting Requirements | 4 Tools Required to Unpack and Prepare the SRX5800 Services Gateway for Installation | 6 Step 2: Install the Mounting Hardware | 6 Install the Mounting Hardware in a Four-Post Rack or Cabinet | 6...
  • Page 2 Configure User Accounts and Passwords | 26 Configure System Attributes | 27 Commit the Configuration | 28 Safety Warnings | 31 SRX5800 Services Gateway Compliance Statements for EMC Requirements | 34 Canada | 34 European Community | 35 Japan | 35...

  • Page 3: About This Guide

    About This Guide This guide contains information that you need to install and configure the SRX5800 Services Gateway quickly. For complete installation instructions, see the SRX5800 Services Gateway Hardware Documentation at www.juniper.net/documentation/. WARNING: This guide contains a summary of safety warnings in “Safety Warnings”...

  • Page 4: Step 1: Prepare The Site For Srx5800 Services Gateway Installation

    Gateway Installation IN THIS SECTION Rack-Mounting Requirements | 4 Tools Required to Unpack and Prepare the SRX5800 Services Gateway for Installation | 6 Rack-Mounting Requirements You can install the services gateway in a four-post rack or cabinet or an open-frame rack.
  • Page 5 Figure 1: SRX5800 Services Gateway Rack Clearance and Chassis Dimensions The rack must be strong enough to support the weight of the fully configured services gateway, up to 400 lb (180 kg). If you stack three fully configured services gateways in one rack, it must be capable of supporting about 1,200 lb (542 kg).

  • Page 6: Tools Required To Unpack And Prepare The Srx5800 Services Gateway For Installation

    To install the mounting shelf as shown in Figure 2 on page 1. On the front rack rails, install cage nuts in the holes specified in the SRX5800 Services Gateway Hardware Guide for the large shelf. 2. On the front of each front rack rail, partially insert a mounting screw into the hole containing the lowest cage nut.
  • Page 7 4. Partially insert a mounting screw into the top hole in each ear of the large shelf. 5. Tighten all the screws completely. 6. On the rear rack rails, install cage nuts in the holes specified in the SRX5800 Services Gateway Hardware Guide for the small shelf.

  • Page 8: Install The Mounting Hardware In An Open-Frame Rack

    1. On the rear of each rack rail, partially insert a mounting screw into the highest hole specified in the SRX5800 Services Gateway Hardware Guide for the large shelf. 2. Install the large shelf on the rack. Hang the shelf over the mounting screws using the keyhole slots located near the top of the large shelf flanges.

  • Page 9: Step 3: Install The Services Gateway

    Step 3: Install the Services Gateway IN THIS SECTION Remove Components | 9 Install the Services Gateway | 11 Reinstall Components | 12 Because of the services gateway’s size and weight, you must use a mechanical lift to install the services gateway in the rack.
  • Page 10 3. Immediately store each removed component in an electrostatic bag. 4. Do not stack removed components. Lay each one on a flat surface. NOTE: For complete instructions on removing services gateway components, see the SRX5800 Services Gateway Hardware Documentation at www.juniper.net/documentation/.

  • Page 11: Install The Services Gateway

    1. Ensure that the rack is in its permanent location and is secured to the building. Ensure that the installation site allows adequate clearance for both airflow and maintenance. For details, see the SRX5800 Services Gateway Hardware Documentation at www.juniper.net/documentation/.

  • Page 12: Reinstall Components

    To reinstall the components in the services gateway: 1. Attach an electrostatic discharge (ESD) grounding strap to your bare wrist, and connect the strap to one of the ESD points on the chassis. For more information about ESD, see the SRX5800 Services Gateway Hardware Documentation at www.juniper.net/documentation/.

  • Page 13: Step 4: Connect The Grounding Cable

    5. Disconnect the ESD grounding strap from the site ESD grounding point, and connect it to one of the ESD points on the chassis. For more information about ESD, see the SRX5800 Services Gateway Hardware Documentation at www.juniper.net/documentation/.

  • Page 14: Step 5: Connect External Devices And Network Cables

    Figure 7: Connecting the Grounding Cable M6 (Metric) Grounding Point 1/4-20 Grounding Point 8. Verify that the grounding cabling is correct, that the grounding cable does not touch or block access to services gateway components, and that it does not drape where people could trip over it. Proceed to “Step 5: Connect External Devices and Network Cables”...

  • Page 15: Connect To A Network For Out-Of-Band Management

    2. Plug the female DB-9 end into the device’s serial port. Connect the Network Cables 1. Have ready a length of the type of cable used by the interface. For cable specifications, see the SRX5800 Services Gateway Hardware Documentation at www.juniper.net/documentation/.
  • Page 16 Figure 8: Connect Network Cables 4. Arrange the cable in the cable management system to prevent it from dislodging or developing stress points. Secure the cable so that it is not supporting its own weight as it hangs to the floor. Place excess cable out of the way in a neatly coiled loop in the cable management system.

  • Page 17: Step 6: Connect Power Cables

    Step 6: Connect Power Cables IN THIS SECTION Connect Power to an AC-Powered Services Gateway | 17 Connect Power to a DC-Powered Services Gateway | 21 Depending on its configuration, the services gateway uses either AC or DC power supplies. Perform the appropriate procedures for each power supply in the services gateway.
  • Page 18 1. Locate the power cords you will use to connect the device to AC power. See the SRX5800 Services Gateway Hardware Documentation at www.juniper.net/documentation/ for specifications. 2. Attach an electrostatic discharge (ESD) grounding strap to your bare wrist, and connect the strap to one of the ESD points on the chassis.
  • Page 19 3. For high-capacity AC power supplies, check the setting of the input mode switch: a. Move or remove the metal plate that covers the input mode switch. On some power supply versions, the cover pivots at one end, and you can simply swing it up out of the way. On other versions, the cover is secured with two captive screws that you must loosen.
  • Page 20 c. Insert each power cord plug into an external AC power source receptacle (Figure 10 on page 20 Figure 11 on page NOTE: Each power supply must be connected to a dedicated AC power feed and a dedicated customer site circuit breaker. We recommend using a 15-A (250-VAC), circuit breaker minimum, or as permitted by local code.

  • Page 21: Connect Power To A Dc-Powered Services Gateway

    Figure 11: Connecting AC Power to the Services Gateway (High-Capacity Power Supplies ) d. Dress each power cord appropriately. Verify that the power cord does not block the air exhaust or access to services gateway components, and that it does not drape where people could trip over Connect Power to a DC-Powered Services Gateway WARNING: To meet safety and electromagnetic interference (EMI) requirements and...
  • Page 22 Table 2 on page 22 describes the services gateway input voltage requirements. Table 2: SRX5800 Services Gateway DC Power System Input Voltage Item Specification DC input voltage Operating range: –40 to –72 VDC 1. Ensure that the voltage across the DC power source cable leads is 0 V and that there is no chance that the cable leads might become active during installation.
  • Page 23 DC power supply terminal studs. NOTE: For information about connecting to external DC power sources, see the SRX5800 Services Gateway Hardware Documentation at www.juniper.net/documentation/. 4. For high-capacity DC power supplies, secure the power cable lugs to the terminal studs, first with the...
  • Page 24 and 25 lb-in. (2.8 Nm) of torque to each nut. Do not overtighten the nut. (Use a 7/16-in. torque-controlled driver or socket wrench.) a. Attach the positive (+) DC source power cable lugs to the RTN (return) terminals for the INP0 and INP1 connector pairs.

  • Page 25: Step 7: Perform The Initial Software Configuration

    Use only a torque-controlled driver or socket wrench to tighten nuts on the DC power supply terminal studs. NOTE: For information about connecting to DC power sources, see the SRX5800 Services Gateway Hardware Documentation at www.juniper.net/documentation/. 5. Connect each DC power cable to the appropriate external DC power source.

  • Page 26: Enter Configuration Mode

    This procedure connects the services gateway to the network but does not enable it to forward traffic. For complete information about enabling the services gateway to forward traffic, including examples, see the appropriate Junos operating system (Junos OS) configuration guides at www.juniper.net/techpubs/. To configure the software: Enter Configuration Mode 1.

  • Page 27: Configure System Attributes

    2. Configure an administrator account on the device. When prompted, enter the password for the administrator account. [edit] root@# set system login user admin class super-user authentication plain-text-password New password: password Retype new password: password 3. Commit the configuration to activate it on the services gateway. [edit] root@# commit Configure System Attributes...

  • Page 28: Commit The Configuration

    5. Configure the default route. [edit] admin@# set routing-options static route 0.0.0.0/0 next-hop gateway 6. Configure basic security zones and bind them to traffic interfaces. [edit] admin@# set security zones security-zone trust interfaces ge-4/3/5 admin@# set security zones security-zone untrust interfaces ge-4/2/0 7.
  • Page 29 { user * { any emergency; file messages { any any; authorization info; file interactive-commands { interactive-commands any; license { autoupdate { url https://ae1.juniper.net/junos/key_retrieval; interfaces { ge-0/0/0 { unit 0; ge-2/0/0 { unit 0 { family inet { address 5.1.1.1/24;...
  • Page 30 ge-2/1/5 { unit 0 { family inet { address 192.1.1.1/24; fxp0 { unit 0 { family inet { address 192.168.10.2/24; routing-options { static { route 0.0.0.0/0 next-hop 5.1.1.2; security { zones { security-zone trust { interfaces { ge-2/1/5.0; security-zone untrust { interfaces { ge-2/0/0.0;...

  • Page 31: Safety Warnings

    Safety Warnings WARNING: See installation instructions before you connect the services gateway. This is a summary of safety warnings. For a complete list of warnings for the services gateway, including translations, see the SRX5800 Services Gateway Hardware Documentation at www.juniper.net/documentation/.
  • Page 32 Read the installation instructions before you connect the services gateway to a power source. Before you install the services gateway, read the guidelines for site preparation in the SRX5800 Services Gateway Hardware Guide to make sure that the site meets power, environmental, and clearance requirements for the services gateway.
  • Page 33 If the rack is provided with stabilizing devices, install the stabilizers before mounting or servicing the services gateway in the rack. When you are removing or installing an electrical component, always place it component-side up on a flat antistatic surface or in an electrostatic bag. When you are installing the services gateway, always make the ground connection first and disconnect it last.

  • Page 34: Srx5800 Services Gateway Compliance Statements For Emc Requirements

    AC power cable warning (Japan): WARNING: The attached power cable is only for this product. Do not use the cable for another product. SRX5800 Services Gateway Compliance Statements for EMC Requirements IN THIS SECTION Canada | 34 European Community | 35...

  • Page 35: European Community

    Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. SRX Series Documentation and Release Notes For a list of related SRX Series documentation, see https://www.juniper.net/documentation/hardware...

  • Page 36: Requesting Technical Support

    If the information in the latest release notes differs from the information in the documentation, follow the Junos Release Notes. To obtain the most current version of all Juniper Networks technical documentation, see the product documentation page on the Juniper Networks website at www.juniper.net/documentation/...

  • Page 37: Revision History

    Copyright © 2019 Juniper Networks, Inc. All rights reserved. Juniper Networks, the Juniper Networks logo, Juniper, and Junos are registered trademarks of Juniper Networks, Inc. and/or its affiliates in the United States and other countries. All other trademarks may be property of their respective owners.
